ey Technical Parameters General & Electrical Ratings Product / Model: ABB MS116‑20 Manual Motor Starter Series: MS116 Rated Operational Current (Ie): 16 – 20 A (adjustable) Number of Poles: 3 (three‑pole) Rated Operational Voltage: Up to 690 V AC Rated Short‑Circuit Breaking Capacity (Icu): ~16 kA at 400 V AC Rated Service Breaking Capacity (Ics): ~10 kA at 230/400 V AC Overload Trip Setting Range: 16–20 A (adjustable) Undelayed Short‑Circuit Setting: ~300 A Motor & Power Ratings AC‑3 Rated Operational Power (Pe): ~7.5 kW at 230 V and 400 V AC Typical Motor Ratings: ~5 HP at 220–240 V AC ~10 HP at 440–480 V AC ~15 HP at 500–600 V AC Protection Features Thermal Overload Protection: Yes (adjustable) Phase Failure / Loss Sensitivity: Yes Disconnect Switch Function: Yes Trip‑Free Mechanism: Yes Temperature Compensation: Yes Mechanical & Physical Actuator: Rotary handle with ON/OFF/TRIP positions Width: ~45 mm Height: ~97.8 mm Depth: ~85 mm Weight: ~0.31 kg Degree of Protection: IP20 (housing) Operating Temperature: –25 °C to +70 °C Mounting: DIN‑rail or panel mount compatible Typical Applications Motor control and protection in industrial panels Manual motor switching (start/stop) Overload and short‑circuit protection without external fuses Phase failure sensitive applications

Key Technical Parameters General & Electrical Ratings Product / Model: ABB AX12‑30‑10‑80 AC Contactor Main Contacts: 3 normally open (NO) Auxiliary Contact: 1 normally open (1 NO) Rated Insulation Voltage (Ui): 690 V AC Control / Coil Voltage (Uc): 220–230 V AC at 50 Hz 230–240 V AC at 60 Hz Rated Frequency: 50 Hz / 60 Hz Terminal Type: Screw terminals Degree of Protection: IP20 at terminals Current Ratings Conventional Free‑Air Thermal Current (Ith): ~26 A at 40 °C Rated Operational Current AC‑1 (Ie): ~22 A at 220–240 V AC (55 °C) ~25 A at 690 V AC (40 °C) ~18 A at 690 V AC (70 °C) Rated Operational Current AC‑3 (Ie): ~12 A at 220–240 V AC (55 °C) ~9 A at 440–500 V AC (55 °C) ~7 A at 690 V AC (55 °C) Power Ratings Rated Operational Power AC‑3 (Pe): ~3 kW at 220–240 V AC ~5.5 kW at 380–400 V AC ~5.5 kW at 440–690 V AC Switching Frequencies Maximum Electrical Switching Frequency: ~600 cycles/hour (AC‑1) ~1,200 cycles/hour (AC‑3 & AC‑15) ~900 cycles/hour (DC‑13) Maximum Mechanical Switching Frequency: ~3,600 cycles/hour Breaking / Withstand Values Estimated Maximum Breaking Capacity: ~250 A at 440 V AC ~90 A at 690 V AC Service Performance: Designed for reliable switching of moderate loads. Timing & Operation Coil Operate & Release Times: Coil energize to NO contact close: ~10–26 ms Coil de‑energize to NO contact open: ~4–11 ms Coil energize to NC contact open: ~7–21 ms Coil de‑energize to NC contact close: ~9–16 ms Mechanical & Physical Typical Dimensions: Approx. 74 mm (H) × 44 mm (W) × 74 mm (D) Weight: ~0.32 kg Mounting: Panel or DIN‑rail compatible block contactor style Applications Switching and control of three‑phase motors and power circuits Motor starters and control panels General industrial load switching Used where compact contactors with moderate current and power ratings are required

Key Technical Parameters General & Electrical Ratings Product / Model: ABB MS165‑54 Manual Motor Starter Part Number: 1SAM451000R1016 Type: Manual motor starter / motor protection breaker Number of Poles: 3 (three‑pole) Rated Continuous Current (Iu): 54 A Overload Release Current Setting Range: 40 – 54 A Undelayed Short‑Circuit Release: ~810 A Rated Operational Voltage: 250 – 690 V AC Rated Operational Power (AC‑3): ~22 kW at 400 V AC Phase Sensitivity: Phase failure protection included Control / Mechanism: Thermomagnetic (thermal + magnetic) protection with trip‑free reset mechanism Mechanical & Connection Mounting: DIN‑rail installation Terminals: Screw‑type connections for main circuit Handle: Rotary ON/OFF/TRIP handle, lockable Enclosure Protection: IP20 Trip Class: Class 10 (typical timing behavior of the overload release) Performance & Protection Short‑Circuit Breaking Capacity: Typical rated service breaking capacity ~50 kA at 400 V AC Built‑In Disconnect: YES (visibly disconnects load when OFF) Phase Loss Detection: YES Temperature Compensation: Integrated to maintain trip accuracy over temperature change Dimensions & Physical Width: ~55 mm Height: ~142.6 mm Depth: ~122 mm Mounting Width: Standard DIN rail module width suitable for control cabinets Applications Motor Protection: Protection and manual control of three‑phase motors (up to ~22 kW @ 400 V) Control Panels: Industrial and commercial electrical control and protection systems Overload & Short‑Circuit Protection: Integrated load safeguarding without separate fuse requirement

Key Technical Parameters General & Protection Ratings Product / Model: ABB T5H 400 TMA 400‑4000 3P MCCB Part Number: 1SDA054445R1 Device Type: Molded Case Circuit Breaker (MCCB) Series: Tmax T5H Number of Poles: 3 (three‑pole) Mounting Style: Fixed with front terminals Trip Unit Type: Thermal‑Magnetic (TMA) Current & Voltage Ratings Rated Uninterrupted (Continuous) Current (In): 400 A Overload Trip Setting Range: Adjustable around 280–400 A Instantaneous Short‑Circuit Setting Range: ~2000 A to 4000 A Rated Operational Voltage (AC): Up to 690 V AC Rated Operational Voltage (DC): Up to 750 V DC Rated Frequency: 50 Hz / 60 Hz Rated Insulation Voltage (Ui): 1000 V Rated Impulse Withstand Voltage (Uimp): 8 kV Breaking Capacities Rated Ultimate Short‑Circuit Breaking Capacity (Icu): ~100 kA at 220–230 V AC ~70 kA at 380–440 V AC ~50 kA at 500 V AC ~40 kA at 690 V AC Rated Service Short‑Circuit Breaking Capacity (Ics): Matches Icu values at respective voltages (e.g., 100 kA at 220–230 V AC, 70 kA at 380–440 V AC) Durability & Performance Electrical Durability: ~7,000 operating cycles (at 60 cycles/hour) Mechanical Durability: ~20,000 cycles (at 120 cycles/hour) Per‑Pole Power Loss at Rated Conditions: ~19.5 W Mechanical & Physical Terminal Type: Fixed front terminals Dimensions: ~140 mm width × ~205 mm height × ~104 mm depth Weight: ~4.8 kg Protection Degree: Standard industrial MCCB housing suitable for enclosure use Typical Applications Protection of three‑phase distribution circuits in industrial and commercial installations Feeder and motor circuit protection in switchboards Overload and short‑circuit safeguarding in electrical distribution systems

Key Technical Parameters General & Electrical Ratings Product / Model: ABB AX205‑30‑11‑80 Contactor Part Number: 1SFL501074R8011 Type: Three‑pole AC magnetic contactor Main Contacts: 3 normally open (3 NO) Auxiliary Contacts: 1 normally open + 1 normally closed (1 NO + 1 NC) Control/Coil Voltage: 220–230 V AC (50 Hz) or 230–240 V AC (60 Hz) Rated Insulation Voltage (Ui): ~690 V AC Rated Operational Voltage (Main Circuit): ~1000 V AC capacity (design) Current & Power Capabilities Conventional Free‑Air Thermal Current (Ith): ~250 A at 40 °C free air Rated Operational Current AC‑1 (Ie): ~275 A at 690 V AC (40 °C) ~250 A at 690 V AC (55 °C) ~180 A at 690 V AC (70 °C) Rated Operational Current AC‑3 (Ie): ~205 A at 220–240 V AC (55 °C) ~205 A at 380–400 V AC (55 °C) ~185 A at 440 V AC (55 °C) ~170 A at 500–690 V AC (55 °C) Rated Operational Power (AC‑3): ~59 kW at 220–240 V AC ~110 kW at 380–400 V AC ~90 kW at 440 V AC ~110 kW at 500 V AC ~132 kW at 690 V AC Switching Capacity & Durability Rated Making Capacity (AC‑3): ~10 × Ie Rated Breaking Capacity (AC‑3): ~8 × Ie Maximum Electrical Switching Frequency: ~300 cycles/hour Maximum Mechanical Switching Frequency: ~3600 cycles/hour Mechanical Durability: ~5 million operations Short‑Time Withstand Currents Short‑time withstand (cold state): ~1200 A for 10 s ~600 A for 1 min ~280 A for 15 min ~1800 A for 1 s ~800 A for 30 s Physical & Environmental Mounting & Connections: Front terminal bars for main circuit; screw terminals for control Degree of Protection: IP20 to terminals Ambient Operating Temperature: –40 °C to +70 °C (varies with installation and coil/load) Typical Dimensions: ~111.5 mm (W) × ~162.3 mm (D) × ~196 mm (H) Weight: ~3.2 kg Typical Applications Motor starters and reversing circuits for three‑phase motors Switching and control of three‑phase power circuits in industrial panels Isolation and by‑pass switching in automation systems General power distribution and control functions

Key Technical Parameters General & Electrical Ratings Product / Model: ABB AF09‑30‑10‑11 contactor Part Number: 1SBL137001R1110 Contact Configuration: 3 normally open main contacts (3NO) Auxiliary Contacts: 1 normally open (1NO) Rated Insulation Voltage: Up to 690 V AC Rated Frequency: 50 Hz / 60 Hz Control (Coil) Voltage Range: 24–60 V AC/DC (covers 20–60 V DC and 24–60 V AC) Connection Terminals: Screw type Mounting: DIN rail or panel mount compatible Current & Power Ratings Rated Operational Current (AC‑3): ~9 A (for motor and general load switching) Rated Operational Current (AC‑1): ~25 A Power Ratings: ~2.2 kW at 220–240 V AC ~4 kW at 380–440 V AC ~5.5 kW at 500–690 V AC Contact Voltage Rating: Up to 690 V AC Performance & Durability Mechanical Endurance: Over ~10 million operations Electrical Durability (AC‑3): Over ~1 million operations Operating Temperature Range: Approximately –60 °C to +80 °C Degree of Protection: IP20 housing Impulse Withstand Voltage: Designed for industrial environments Physical Dimensions (approx): Height: ~86 mm Width: ~45 mm Depth: ~77 mm Weight: ~0.27 kg Typical Applications Three‑phase motor control starters Industrial automation systems HVAC and pump control Lighting and general power circuits Control panels and relay assemblies

Key Technical Parameters Electrical & Safety Ratings Product / Model: ABB Sentry SSR10 24VDC Safety Relay Part Number: 2TLA010050R0000 Supply Voltage: 24 V DC Safety Output Contacts: 3 Normally Open (NO) + 1 Normally Closed (NC) Output Current Capacity: Up to ~6 A (typical maximum rated current per contact set) Reset Mode: Manual or Automatic selectable by front switch Monitored Inputs: Safety devices with contact inputs or OSSD outputs Reset Function: Selectable manual/automatic Safety Performance: Suitable for use in safety circuits requiring high integrity (e.g., PLe / SIL3 systems) Mechanical & Installation Mounting: DIN rail TH35‑15 or TH35‑7.5 (IEC standard) Terminals: Screw terminals for secure wiring Degree of Protection: IP20 (protects against solid objects) Construction Width: ~22.5 mm (1 module) Dimensions (approx): Height ~120 mm × Depth ~120 mm Weight: ~0.20 kg Typical Use & Applications Emergency stop monitoring Safety gate and interlock monitoring Safeguarding of machinery and automation systems Use with contact safety devices and OSSD output sensors Panel and control cabinet installation

Key Technical Parameters General & Protection Product / Model: ABB XT3N250 TMD200/2000 FF 3P Device Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT Number of Poles: 3 Trip Unit Type: Thermal‑Magnetic (TMD) Mounting Style: Fixed with front terminals Current & Voltage Ratings Rated Continuous Current (In): 200 A Overload Trip Setting Range: ~140–200 A Instantaneous Short‑Circuit Setting: 2000 A Rated Operational Voltage: Up to 690 V AC or 500 V DC Rated Frequency: 50 Hz / 60 Hz Rated Insulation Voltage (Ui): ~800 V Rated Impulse Withstand Voltage (Uimp): ~8 kV Short‑Circuit & Breaking Capacity Ultimate Breaking Capacity (Icu): ~50 kA at 220–240 V AC ~36 kA at 380–415 V AC ~20 kA at 500 V AC ~5 kA at 690 V AC DC Breaking Capacity: ~36 kA at 250 V DC (2 poles in series) ~50 kA at 500 V DC (3 poles in series) Performance & Durability Electrical Durability: ~120 cycles/hour (up to ~8000 operations) Mechanical Durability: ~240 cycles/hour (up to ~25,000 operations) Power Loss: ~13 W per pole at rated conditions Terminal Type: Front, bolt connection (tightening torque ~8 N·m) Physical Dimensions (approx): ~150 mm (H) × 105 mm (W) × 70 mm (D) Weight: ~1.7 kg Degree of Protection: Standard industrial housing suitable for enclosure mounting Applications Main & feeder protection in distribution boards Motor feeder circuits protection Industrial and commercial electrical systems requiring robust overload and short‑circuit protection

Key Technical Parameters General & Protection Product / Model: ABB XT1N160 TMD160‑1600 FF 3P Device Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT Number of Poles: 3 (three‑pole) Trip Unit Type: Thermal‑Magnetic (TMD) Mounting Style: Fixed installation, front terminal connections Current & Voltage Ratings Rated Continuous Current (In): 160 A Adjustable Instantaneous Short‑Circuit Setting: 160–1600 A Rated Operational Voltage: Up to 690 V AC / 500 V DC Rated Frequency: 50 Hz / 60 Hz Rated Insulation Voltage (Ui): ~800 V Rated Impulse Withstand Voltage (Uimp): ~8 kV Short‑Circuit & Breaking Capacities Rated Ultimate Breaking Capacity (Icu): • ~65 kA at 220–240 V AC • ~36 kA at 380–415 V AC • ~30 kA at 500 V AC • ~6 kA at 690 V AC Rated Service Breaking Capacity (Ics): Slightly lower than Icu depending on voltage DC Breaking Capability: Up to ~36 kA at 250–500 V DC Performance & Durability Electrical Durability: ~120 cycles/hour (up to ~8000 operations) Mechanical Durability: ~240 cycles/hour (up to ~25,000 operations) Power Loss: ~15 W per pole at rated operating conditions Connection / Wiring: Front panel wiring with busbar or cable lug options Environmental & Applications Typical Operational Systems: Industrial switchboards, motor feeders, main and feeder protection in commercial or industrial electrical distribution Standards Compliance: IEC 60947‑2 Use Cases: Overload protection, short‑circuit interruption, isolation in three‑phase AC and DC systems

Key Technical Parameters General & Electrical Ratings Product / Model: ABB AF185‑30‑11 Device Type: 3‑pole AC Contactor Main Contacts: 3 normally open (NO) Auxiliary Contacts: 1 NO + 1 NC Control (Coil) Voltage Range: 100–250 V AC/DC Rated Insulation Voltage: Up to 690 V AC Rated Frequency: 50 Hz / 60 Hz Current & Power Ratings Conventional Free‑Air Thermal Current (Ith): ~275 A at 40 °C Rated Operational Current AC‑1 (Ie): ~275 A at 690 V AC (40 °C) ~250 A at 690 V AC (55 °C) ~180 A at 690 V AC (70 °C) Rated Operational Current AC‑3 (Ie): ~185 A at ~415–440 V AC (55 °C) ~170 A at ~500–690 V AC (55 °C) Rated Operational Power AC‑3 (Pe): ~55 kW at 220–240 V AC ~90 kW at 380–400 V AC ~110 kW at ~500 V AC ~132 kW at ~690 V AC Switching & Protection Rated Breaking Capacity (AC‑3): ~8 × Ie Rated Making Capacity (AC‑3): ~10 × Ie Rated Impulse Withstand Voltage: ~8 kV Short‑Circuit Protective Devices: gG type fuses (e.g., 355 A) Mechanical Durability: ~5 million operations Electrical Switching Frequency: ~300–1200 cycles/hour depending on duty Mechanical & Physical Mounting Type: Panel or DIN rail adapter Terminal Type: Screw terminals Degree of Protection: IP20 at coil terminals, IP00 at main terminals Operating Ambient Temperature: ~–40 °C to +70 °C (highest range when no auxiliary devices fitted) Connecting Capacity: Suitable for bar and cable connections (varied conductor sizes) Typical Applications Starting and stopping three‑phase motors Switching heavy industrial loads Control panels and motor starter assemblies Distribution and bypass circuits

Key Technical Parameters General & Electrical Ratings Product / Model: ABB AX50‑30‑11‑80 AC Contactor Part Number: 1SBL351074R8011 Main Contacts: 3 normally open (3 NO) Auxiliary Contacts: 1 NO + 1 NC Control / Coil Voltage (Rated): 220–230 V AC at 50 Hz 230–240 V AC at 60 Hz Rated Insulation Voltage (Ui): 690 V AC Rated Frequency: 50 Hz / 60 Hz Conventional Free‑Air Thermal Current (Ith): ~100 A Degree of Protection: IP20 (terminals) Operational Currents Rated Operational Current AC‑1 (Ie): ~85 A at 220–240 V AC, 55 °C ~100 A at 690 V AC, 40 °C ~70 A at 690 V AC, 70 °C Rated Operational Current AC‑3 (Ie): ~53 A at 220–240 V AC, 55 °C ~50 A at 380–400 V AC, 55 °C ~45 A at 440–500 V AC, 55 °C ~35 A at 690 V AC, 55 °C Power Ratings Rated Operational Power (AC‑3): ~15 kW at 220–240 V AC ~22 kW at 380–400 V AC ~25 kW at 415 V AC ~25–30 kW at 440–500 V AC ~30 kW at 690 V AC Switching Frequency Electrical: ~600 cycles/hour (AC‑1 and AC‑3) Mechanical: ~3600 cycles/hour Mechanical & Physical Dimensions (approx): 108 mm (H) × 82 mm (W) × 110 mm (D) Net Weight: ~1.05 kg Terminal Type: Screw terminals Operating Ambient Temperature: ~‑40 °C to +70 °C Typical Applications Control and switching of three‑phase motors Power circuit switching up to 690 V AC Industrial control panels and motor starter assemblies General industrial and commercial power control tasks

Key Technical Parameters General & Electrical Ratings Product / Model: ABB AF16Z‑30‑10‑23 Part Type: 3‑pole AC contactor Main Contact Configuration: 3 normally open (3 NO) Auxiliary Contacts: 1 normally open (1 NO) Rated Insulation Voltage: Up to 690 V AC Control (Coil) Voltage: Wide range 100 – 250 V AC/DC Rated Operational Voltage: Up to 690 V AC Rated Frequency: 50 Hz / 60 Hz Operational Current Ratings AC‑1 Load Current: ~30 A AC‑3 Motor Loads: • ~18 A at common voltages (220–440 V AC) • ~15 A at ~500 V AC • ~10.5 A at ~690 V AC Power Ratings Motor Power (AC‑3): • ~4 kW at 220–240 V AC • ~7.5 kW at 380–400 V AC • ~9 kW at 415–690 V AC Mechanical & Usage Enclosure / Protection: IP20 Terminal Type: Screw terminals Rated Insulation / Impulse Withstand: Suitable for industrial environments Switching Frequency: • ~600 cycles/hour (AC‑1) • ~1200 cycles/hour (AC‑3 / AC‑15) • ~900 cycles/hour (DC‑13) Mounting Style: Standard industrial mounting (panel or DIN rail adaptor, if required) Weight & Size: Compact design (~86 mm H × 45 mm W × 77 mm D) Applications Control and switching of motors, lighting, heating, and general power circuits Use in motor starters and control panels Suitable where wide control voltage flexibility is needed
