Key Technical Parameters Product / Model: ABB T5N630 TMA500/2500‑5000 FF 3P Device Type: Molded Case Circuit Breaker (MCCB) Series: SACE Tmax T5N Number of Poles: 3 (three‑pole) Mounting Style: Fixed Trip Unit Type: Thermal‑magnetic (TMA) Frame Rated Current: 630 A Rated Operational Current (In): 500 A (typical adjustment) Short‑Circuit Trip Adjustment Range: 2500–5000 A (adjustable magnetic short‑circuit trip setting) Operational Voltage: Up to 690 V AC Degree of Protection: IP20 Control / Connection: Front terminals for main circuit connections Performance Thermal‑Magnetic Protection: Provides combined overload (thermal) and short‑circuit (magnetic) protection suitable for load and fault currents. Interrupting Capacity: High breaking capacity for use in industrial power distribution systems. Application: Protection of feeders, motors, and distribution circuits in industrial or commercial installations requiring adjustable protection settings.

Key Technical Parameters Product / Model: ABB AX40‑30‑10‑80 AC Contactor Part Number: 1SBL321074R8010 Main Poles: 3 normally open (3 NO) Auxiliary Contact: 1 normally open (1 NO) Control / Coil Voltage: 220–230 V AC at 50 Hz; 230–240 V AC at 60 Hz Rated Insulation Voltage (Ui): 690 V AC Rated Operational Voltage (Main & Auxiliary): Up to 690 V AC Rated Frequency: 50 Hz / 60 Hz Conventional Free‑air Thermal Current (Ith): 65 A at 40 °C Current & Power Ratings Operational Current AC‑1 (Ie): ~60 A at 220–240 V AC, ~42 A at 690 V AC (70 °C) Operational Current AC‑3 (Ie): ~40 A at 220–240 V AC, ~37 A at 440 V AC, ~25 A at 690 V AC Operational Power AC‑3 (Pe): ~11 kW at 220–240 V, ~18.5 kW at 380–400 V, ~22 kW at 440–690 V Switching & Mechanical Rated Operational Current AC‑15: up to ~6 A at low control voltages Maximum Electrical Switching Frequency: ~600 cycles/hour (AC‑1), ~1200 cycles/hour (AC‑3 / AC‑15), ~900 cycles/hour (DC‑13) Maximum Mechanical Switching Frequency: ~3600 cycles/hour Physical & Environmental Dimensions (H × W × D): ~108.3 mm × 54 mm × 90 mm Weight: ~0.667 kg Degree of Protection: IP20 Terminal Type: Screw terminals Ambient Temperature (Operation): –40 °C to +70 °C Altitude Capability: up to ~3000 m without derating Applications Motor control starters Switching three‑phase power circuits Industrial control panels Lighting and auxiliary loads

Key Technical Parameters General & Electrical Ratings Product / Model: ABB A16‑30‑10 Contactor Part Number: 1SBL181001R8010 Main Poles: 3 normally open (3 NO) Auxiliary Contact: 1 normally open (1 NO) Control/Coil Voltage (Rated): 220 – 230 V AC at 50 Hz 230 – 240 V AC at 60 Hz Rated Operational Voltage (Main Circuit): Up to 690 V AC Rated Operational Current (AC‑3): ~17 A at ~220–240 V AC ~17 A at ~380–400 V AC ~16 A at ~440 V AC Lower currents at higher voltages (500–690 V) Performance & Power Rated Operational Power (AC‑3): ~4 kW at ~220–240 V AC ~7.5–9 kW at ~380–440 V AC ~9 kW up to 690 V AC Rated Operational Current (AC‑1): ~30 A at 690 V AC (at 40 °C) Rated Operational Current (AC‑15): Suitable for control and signaling loads (e.g., ~4 A at 220–240 V AC) Rated Operational Current (DC‑13): Suitable for DC control applications (various values depending on voltage) Rated Breaking & Making Capacity: Making: ~10 × Ie (AC‑3) Breaking: ~8 × Ie (AC‑3) Mechanical & Connection Mounting: DIN‑rail or screw mounting Connection Terminals: Screw terminals for both main and auxiliary circuits Dimensions: Approx. 44 mm (width) × 74 mm (height) × 74 mm (depth) Weight: Approx. 0.34 kg Switching Frequency: AC‑1: ~600 cycles/hour AC‑3: ~1200 cycles/hour Mechanical Switching Frequency: ~3600 cycles/hour Coil & Operating Coil Power Consumption: Holding: ~8 V·A Pull‑in: ~70–74 V·A Operate / Release Times: Operate: ~10–26 ms Release: ~4–11 ms Standards & Ratings Standards Compliance: IEC 60947‑1 and IEC 60947‑4‑1 (general industrial contactor standards) Insulation Voltage: ~1000 V (IEC rating) Impulse Withstand Voltage: ~8 kV Environmental: Ambient operation typically from ~‑40 °C to ~+55 … +70 °C depending on conditions Degree of Protection: IP20 on main, auxiliary, and coil terminals Typical Applications Motor control starters and reversing arrangements Switching of lighting, heating, and small industrial loads General power circuit control in machine panels Interlocking and auxiliary switching functions

Key Technical Parameters General & Electrical Ratings Product / Model: A9‑30‑10 Contactor Part Number: 1SBL141001R8010 Main Circuit Poles: 3 poles (3NO main contacts) Auxiliary Contacts: 1 normally open (NO) auxiliary contact Rated Operational Voltage (Main Circuit): Up to ~690 V AC Control/Coil Voltage: 220–230 V AC at 50 Hz 230–240 V AC at 60 Hz Control Voltage Type: AC coil operation Rated Operational Current (AC‑3): ~9 A at 400–440 V Rated Operational Power (AC‑3): ~4 kW at 400 V (lower at 230 V) General Use Rating (UL/CSA): ~21 A at 600 V AC Horsepower Rating (Typical): ~2 hp at 220–240 V AC ~5–7.5 hp at higher voltages (440–600 V) Mechanical / Physical Design Type: Block‑type magnetic contactor Mounting: Panel or DIN rail compatible Connection: Screw terminals Coil Operating Range: Accepts standard AC supply in specified voltage bands Use Category: Suitable for AC‑3 motor load duties and general switching Applications Motor Control: Starting and stopping three‑phase induction motors Switching Power Circuits: Control of lighting, resistive loads, and capacitor banks Industrial & Commercial Control Panels: Widely used in automation and machinery installations

Key Technical Parameters General & Electrical Ratings Product Type: Manual Motor Starter / Motor Protection Switch Series: MS165 Current Setting Range: 52 – 65 A Poles: 3‑pole (three phases) Rated Operational Current: 65 A Rated Operating Voltage (Main Circuit): Up to 690 V AC Rated Frequency: 50/60 Hz Rated Operational Power (AC‑3): ~30 kW at 230 V / ~30 kW at 400 V Overload Protection: Thermomagnetic (trip class 10) Phase Failure Sensitive: Yes Trip Free Mechanism: Yes Disconnect Function: Yes Setting Adjustability: Adjustable and sealable current setting Action / Handle: Rotary handle with clear ON / OFF / TRIP indication Short‑Circuit & Protection Short‑Circuit Interrupting Capacity: Typically high (design for safe interruption up to standards for motor starters) Phase Loss / Overload Protection: Built‑in sensitivity and thermal / magnetic protect Manual Operation: ON / OFF switching with automatic trip response Mechanical & Environmental Connection Type: Screw terminals Mounting Type: DIN‑rail or panel mount Enclosure / Protection: IP20 (housing) Operating Temperature: Approximately –25 °C to +60 °C Operating Cycles: Roughly 25,000 electrical, 50,000 mechanical Dimensions: Compact — approximate width ~55 mm Applications Protection and Control: Provides manual motor starting, overload protection, phase failure detection, and short‑circuit reaction without requiring separate fuses. Installation: Suitable for industrial control panels, motor starters, pump and compressor protections, HVAC systems, and general power circuits where motor protection is required.

Key Technical Parameters (English) General & Electrical Ratings Part Number: 1SFL497001R7011 Series / Type: AF185‑30‑11 contactor Configuration: 3‑pole, normally open main contacts (3 NO) Auxiliary Contacts: 1 normally open + 1 normally closed Control / Coil Voltage: 100–250 V AC and 100–250 V DC (50/60 Hz) Operating Voltage Type: AC/DC Rated Operational Voltage (Main Circuit): up to ~690 V Rated Operational Current (AC‑1 at 400 V): ~275 A Rated Operational Current (AC‑3 at 400 V): ~185 A Rated Operational Power (AC‑3 at 400 V): ~90 kW Number of Poles: 3P Mounting Type: Rail or panel mounting depending on application (standard industrial contactor). Mechanical & Physical Weight: ~2.9 kg Dimensions (approx.): • Width ~111.5 mm • Height ~196 mm • Depth ~160 mm Connection Type: Rail connection (busbar or terminal blocks typical) Suitable Max Voltage: Up to 1000 V nominal (application dependent) Main Contacts: 3 NO Auxiliary Contacts: 1 NO + 1 NC Application & Environment Designed for industrial control panels, motor starters, isolating circuits, and distribution systems. Compatible with both 50 Hz and 60 Hz systems. AC/DC coil allows flexible control supply installations. Suitable for general switching duties and moderate load applications typical of motors and industrial machinery.

Key Technical Parameters Part Number: 1SBL411001R8011 Model / Type: A75‑30‑11 AC Contactor Control/Coil Voltage: 220‑230 V AC at 50 Hz / 230‑240 V AC at 60 Hz Number of Poles (Main Contacts): 3 poles (NO) Auxiliary Contacts: 1 NO + 1 NC Current & Power Rated Operational Current: Up to ~75 A depending on voltage and application Rated Operational Power (AC‑3 duty): ~22 kW at ~230 V ~40 kW at ~415‑440 V Application & Standards Application: Controlling three-phase motors and industrial loads; general power switching Frequency: Compatible with both 50 Hz and 60 Hz power systems Standards: IEC/EN contactor standards for industrial use Other Characteristics Typical Uses: Motor starters, lighting contactors, capacitor switching, general industrial control panels Series: ABB A‑series contactor (block-type electromagnetic design)

Key Technical Parameters Electrical Characteristics Surge Protection Class: Type 2 (IEC 61643‑11) Configuration: 3 phase + Neutral (3N) Nominal System AC Voltage: 400 V / 690 V AC Maximum Continuous Operating Voltage (Uc): L–PE: 440 V L–L: ~760 V L–N: 440 V N–PE: 440 V Nominal Discharge Current (8/20 µs): 20 kA Maximum Discharge Current (8/20 µs): 40 kA Impulse Current (10/350 µs): ~2 kA Voltage Protection Level (Up): L–N: ~1.8 kV N–PE: ~1.4 kV Short Circuit Withstand (Icc): 100 kA Mechanical / Functional Features Auxiliary Contact (“TS”): Potential-free NO/NC contact for remote monitoring Status Indicator: Visual indication of operation or failure Mounting: DIN rail IP Rating: IP20 Operating Temperature: −40 °C to +80 °C Modular Width: 4 modules Standards / Compliance IEC 61643‑11 (EN 61643‑11) Usage / Application Protects electrical systems against transient overvoltages in 3-phase networks (TN‑S, TT) Suitable for main distribution boards and subpanels in commercial and industrial installations TS auxiliary contact allows integration with remote alarm or building management systems

Key Specifications General Manufacturer: ABB Model / Part Number: 1SDA104885R1 (MOE XT5 220–250 V AC/DC) Product Type: Motor Operator / Motorized Circuit Breaker Actuator Series Compatibility: SACE Tmax XT series (XT5 family) Function: Provides motorized operation to open/close a compatible circuit breaker with automatic reset Control / Drive Voltage Rated Control Supply Voltage (Us): 220–250 V AC (50/60 Hz) or 220–250 V DC Drive Type: Electric motor drive for circuit breaker operation Auto‑Reset: Yes Physical / Mechanical Accessory Type: Motor operator for molded case breaker Weight: ~1.357 kg Mounting / Use: Integrated with XT5 frame breakers in distribution or control panels Approvals Standards: IEC certified, UL listed for use with suitable circuit breakers

Key Specifications General Manufacturer: ABB Model / Part Number: S203‑C1 Product Type: 3‑pole miniature circuit breaker (MCB) Series: S200 series Trip Curve: C‑characteristic (general purpose) Poles: 3 poles (3P) Rated Current (In): 1 A (per pole) Modular Width: 3 modules (3 × 18 mm) Electrical Ratings Rated Operational Voltage (AC): 230/400 V AC (three‑phase system) Rated Insulation Voltage (Ui): ~440 V Rated Frequency: 50–60 Hz Thermal‑Magnetic Protection: Combined thermal overload and magnetic short‑circuit trip Breaking / Interrupting Capacity: Icu (ultimate): up to ~25 kA (IEC) at 230/400 V AC Ics (service): ~7.5–12.5 kA depending on test standards Current Limiting Class: 3 (limits let‑through energy during short bursts) Mechanical & Installation Mounting: DIN rail (TH35) mountable in distribution panels Terminal Type: Screw terminals suitable for solid and ferruled conductors Actuator/Handle: Black, sealable with ON/OFF indication Mechanical Endurance: ~20,000 cycles Electrical Endurance: ~20,000 AC cycles Operating Temperature: Approx. −25 °C to +55 °C Protection & Compliance Standards: IEC/EN 60898‑1, IEC/EN 60947‑2 (MCB isolation/protection standards) UL/CSA: Compliant versions applicable to regional markets

Key Specifications General / Construction Manufacturer: ABB Model / Part Number: A50‑30‑11 / 1SBL351001R8011 Product Type: 3‑Phase AC Power Contactor Series: A50 series block contactors Poles: 3 main poles (3NO) Auxiliary Contacts Built‑in: 1 Normally Open (NO) 1 Normally Closed (NC) Control Type: AC coil magnetic contactor Connection Type: Screw terminals Coil / Control Circuit Rated Control Coil Voltage (Uc): 220–230 V AC @ 50 Hz 230–240 V AC @ 60 Hz Main Circuit Ratings Rated Operational Current (AC‑3, Ie) @ 50 °C: ~50 A @ 380/400 V AC ~50–53 A @ 220–240 V AC ~45 A @ 440–500 V AC ~35 A @ 690 V AC ~23 A @ 1000 V AC Rated Operational Power (AC‑3): ~15 kW @ 220–240 V AC ~22 kW @ 380/400 V AC ~25–30 kW @ 440–500 V AC ~30 kW @ 690 V AC ~30 kW @ 1000 V AC Rated Operational Current (AC‑1, Ie): ~100 A @ 400 V AC UL/CSA General Use Rating: ~80 A @ 600 V AC Horsepower Ratings (UL/CSA): ~20 hp @ 220–240 V AC (3‑phase) ~40 hp @ 440–480 V AC (3‑phase) ~50 hp @ 550–600 V AC (3‑phase) Performance & Switching Rated Breaking Capacity (AC‑3): 8 × Ie Rated Making Capacity (AC‑3): 10 × Ie Maximum Electrical Switching Frequency: See contactor series typical industrial rates Operate / Release Times: Typical instant electromagnetic response suitable for AC control Mechanical / Environmental Impulse Withstand Voltage (Uimp): ~8 kV Mechanical Durability: Up to 10 million operations Maximum Mechanical Switching Frequency: ~3600 operations/hour Rated Insulation Voltage (Ui): ~690 V Protection Class: IP20 on enclosure/terminals Operating Temperature Range: approx. −25 °C to +60 °C (ambient) Storage Temperature Range: approx. −40 °C to +80 °C

Key Specifications General Manufacturer: ABB Model / Part Number: CT‑ARE / 1SVR550127R4100 Product Type: Electronic time delay relay (OFF‑delay) Timing Function: True OFF‑delay (delay on break) Series: CT‑E timer series Mounting: DIN rail mount (TH35‑7.5 or TH35‑15) Terminal Type: Screw terminals Housing Width: ~22.5 mm Dimensions (approx): 22.5 mm (W) × 78 mm (H) × 78.5 mm (D) Weight: ~0.07 kg Operating Temperature: –20 °C to +60 °C (typical) Protection Rating: ~IP20 (front and terminals) LED Controls +1 Control / Supply Rated Control Supply Voltage (Us): 24 V AC/DC 220 – 240 V AC (50/60 Hz) The device supports multiple supply ranges so it can be used in lower voltage DC/AC circuits or mains AC control circuits. LED Controls Timing Adjustable Time Range: 0.3 s to 30 s (adjustable via front‑panel dial) Timing Function Description: When supply voltage is removed, the relay remains energized and delays switching off for the set time period. LED Controls Output Contact Configuration: 1 change‑over contact (SPDT / 1 c/o) Rated Operational Current: AC‑12: 4 A @ 230 V AC AC‑15: 3 A @ 230 V AC DC‑12: 4 A @ 24 V DC DC‑13: 2 A @ 24 V DC Contact Voltage Rating: up to 250 V AC These ratings make it suitable for controlling small contactor coils, indicator lights, and control circuits. LED Controls +1 Standards & Compliance Designed to comply with relevant IEC/EN timer relay standards (e.g., IEC/EN 61812‑1) UL 508, CAN/CSA C22.2 and other regional safety certifications RoHS compliant environmental standards
