Technical Parameters Electrical Rated operational voltage: Up to 300 V AC/DC. Contacts: 2 normally open (2 NO). Mechanical Positions: Three fixed positions with return action from C to B. Panel cut‑out: 22 mm standard industrial diameter. Terminal type: Screw terminals. Handle type: Short handle for compact panel mounting. Environmental & Protection Operating temperature: –25 °C to +70 °C. Storage temperature: –40 °C to +85 °C. Front protection rating: IP66 / IP67 / IP69K (when properly installed). Terminal protection: IP20. Mechanical durability: Designed for long operational life. Physical Dimensions Width: ~30 mm Height: ~30 mm Depth: ~72 mm Weight: ~0.032 kg Typical Applications Mode selection in industrial control panels (e.g., Auto/Off/Manual). Operator interfaces for machinery and process equipment. Multi‑position control for system functions.

Technical Parameters Electrical Ratings Rated Operational Voltage: Suitable for control circuits up to typical industrial voltages (e.g., 24 to 240 V AC/DC). Current Ratings: ~1 A at 220–240 VAC ~1.5 A at 24–127 VAC ~0.2 A at 125 VDC ~0.3 A at 24 VDC Mechanical & Environmental Positions: 3 maintained fixed positions (A, B, C). Mechanical Durability: Designed for significant operation cycles (approx. hundreds of thousands of mechanical operations). Operating Temperature Range: Approximately –25 °C to +70 °C Storage Temperature Range: Approximately –40 °C to +85 °C Degree of Protection: Front panel protections rated IP66, IP67 and IP69K (when properly installed), terminals typically IP20. Physical & Installation Mounting Hole / Panel Cutout: Standard 22 mm panel cut‑out for industrial controls. Handle / Actuator: Short black rotary handle for easy selection. Bezel Material: Chrome metal front ring for durability and corrosion resistance. Connection Type: Terminals designed for screw connections. Typical Applications Operator control panels for industrial machines. Mode selectors (e.g., Auto/Manual/Off) in automation systems. Pilot devices in manufacturing control cabinets. Multi‑position control interfaces where a maintained selection is required.

Technical Parameters Physical & Mechanical Panel cut‑out: 22 mm standard mounting hole. Dimensions (approx.): 29 mm (W) × 29 mm (H) × 33 mm (D). Weight: ~0.012 kg. Mechanical durability: Up to 2 million operations. Bezel/housing: Black plastic. Environmental Operating temperature: –25 °C to +70 °C. Storage temperature: –40 °C to +85 °C. Protection & Standards Front protection rating: IP66 — dust tight and protected against powerful water jets (front panel). Terminal protection: Typically IP20 (terminals not protected without proper blocks). NEMA enclosure compatibility: Type 1, 3R, 4, 4X, 12, 13 (when assembled appropriately). Standards compliance: CE, RoHS.

Technical Parameters Electrical Ratings Rated insulation voltage (Ui): 300 V Rated impulse withstand voltage (Uimp): 6 kV Rated operational voltage: Up to 300 V AC/DC AC‑15 current rating: 1 A at 240 V DC‑13 current rating: 0.3 A @ 24 V DC, 0.2 A @ 125 V DC Maximum power loss: Approx. 5 W Mechanical & Environmental Operating temperature: –25 °C to +70 °C Storage temperature: –40 °C to +85 °C Mechanical durability: ~0.5 million operations Protection & Installation Front protection rating: IP66, IP67, IP69K (front only) Terminal protection: IP20 Connection type: Screw clamp terminals Wire stripping length: ~6 mm Tightening torque: ~0.8 N·m Connecting capacity: solid & ferrule‑terminated wires 0.5–1.5 mm² Physical Dimensions Width: ~30 mm Height: ~30 mm Depth / Length: ~55 mm Weight: ~22 g Typical Applications Industrial machine control panels PLC operator interfaces Equipment on/off or reset buttons Control circuits requiring a compact momentary push action

Technical Parameters Product Name: CP9‑1087 Pushbutton Device Type: Flush pushbutton switch (pilot operator) Series: CP9 compact pilot devices Actuator Color: Red Illumination: Non‑illuminated Actuator Style: Flush, low‑profile button Bezel / Housing Material: Black plastic Contact Configuration: Two changeover contacts (1 NO + 1 NC) Contact Operation: Momentary or maintained based on variant (most common is momentary) Mounting Hole Diameter: Standard 22 mm panel cutout Rated Insulation Voltage: Up to 300 V Rated Operational Voltage: Up to 300 V AC/DC (control circuits) Electrical Rating: Suitable for control and signaling circuits (low current) Connection Terminals: Screw clamp terminals or modular accessory blocks Protection Rating: Front panel rated to IP66/IP67 when correctly installed; terminals rated to industrial standard (IP20) Mechanical Durability: Designed for many actuation cycles typical of operator pushbuttons Operating Temperature Range: Standard industrial environments Typical Applications: Ideal for STOP or control command functions in industrial automation panels, operator control stations, and electrical enclosures

Technical Parameters Product Name: ABB S1‑M1‑25 Power Infeed / Feeder Block Device Type: 3‑phase feeder terminal block accessory Part / Model Number: S1‑M1‑25 Electrical Ratings: Rated Operational Voltage (AC): Up to 690 V Rated Operational Voltage (DC): Up to 250 V Rated Operational Current: 65 A for three‑phase connection Poles: Number of Poles: 3 (three phase) Connection & Terminals: Terminal Type: Screw terminals Cable Cross‑Section Capacity: • Rigid cables: up to 25 mm² • Flexible cables with ferrules: up to ~16 mm² Tightening Torque (typical): Appropriate torque for secure screw connection Wire Strip Length: Standard for feeder wiring Mechanical & Physical: Degree of Protection: IP20 (terminals and body) Mounting Form: Flat design for direct accessory connection Dimensions: Approx. 38 mm (height) × 44 mm (width) × 25.5 mm (depth) Weight: Approx. 0.038 kg (lightweight accessory) Standards & Suitability: Designed to interface with manual motor starters and compatible with standard industrial protection and distribution assemblies Suitable for solid core and stranded conductors with appropriate cable preparation Operates in typical industrial ambient conditions (panel enclosures and electrical cabinets)

Technical Parameters Product Name: CM‑MSS.13S Thermistor Motor Protection Relay Device Type: Motor protection monitoring relay (thermistor/PTC based) Supply Voltage (Control Supply): 110–130 V AC 220–240 V AC Rated Frequency: 50/60 Hz Sensor Circuit: 1 sensing circuit for PTC thermistor input Output Contacts: 1 change‑over (SPDT) contact Output Contact Rating: Up to 250 V AC, 4 A (general control load) Connection Terminals: Screw terminal connections Mounting Style: DIN‑rail mountable for control cabinets Automatic Reset: Yes — relay resets automatically once the fault condition (overtemperature) clears Operating Temperature Range: Standard industrial range for control equipment Dimensions: Compact relay width approx. 22.5 mm, height ~85.6 mm, depth ~103.7 mm Weight: Around 0.155 kg Typical Applications: Motor overtemperature protection via PTC sensors Overheat monitoring and alarm signaling Control panel motor protection integration Industrial motor starter circuits requiring thermistor monitoring

Technical Parameters Product Name: OXP6X430 operating shaft Manufacturer: ABB Part / Model Number: OXP6X430 Mechanical Dimensions Shaft Cross‑Section: Square, 6 mm × 6 mm Length: 430 mm Weight: Approximately 0.11–0.14 kg (varies slightly by manufacturing tolerances) Construction Material: Robust metal shaft suited for mechanical actuation of external handles Shape: Square profile for positive engagement with pistol handle and mechanism Finish: Industrial grade suitable for electrical accessory use Compatibility Designed for use with switch disconnectors and pistol handle assemblies in multi‑frame switchgear Suitable for models that accept a 6 mm square shaft and extended handle accessories Typically paired with pistol grip handles and auxiliary components for manual switching Mounting & Use Application: Acts as the extension shaft transmitting user motion from an external pistol handle to the internal switch mechanism Installation: Inserted through a handle/shaft assembly and engaged with the switch disconnect mechanism Use Cases: Manual operation of disconnect switches and safety switches where remote or extended control actuation is needed Environmental & Operating Designed for use in industrial electrical panels and enclosures

Technical Parameters Product Name: AC Contactor Model / Type: C3SS1‑30R‑11 Number of Poles: • 3 main poles for switching the three‑phase load Auxiliary Contacts: • 1 auxiliary contact configured as 1 normally open (1 NO) Rated Operational Current: • Approximately 30 A for AC‑3 duty (typical motor control application) Rated Operational Voltage: • Up to 690 V AC Control Coil Voltage: • Designed for a specific coil voltage (e.g., 110 V AC, 220 V AC, 230 V AC, 440 V AC — depending on variant) Contact Configuration: • 3 main power contacts + 1 auxiliary contact Electrical Life: • Designed for high switching cycles in industrial duty applications Mechanical Life: • High durability for frequent operation Control Frequency: • Suitable for 50 / 60 Hz AC control circuits Connection / Terminals: • Screw terminals for line, load, auxiliary, and coil connections Mounting: • DIN‑rail or panel mounting in control cabinets Application Areas: • Motor control circuits • General AC load switching • Control panels, starters, and distribution boards • Automation and machinery control systems

Technical Parameters Product Name: ABB MT‑110B Modular Potentiometer Device Type: Potentiometer control operator Mounting Style: Panel mount (22 mm cutout) Actuator: Knob, black, non‑illuminated Bezel / Housing: Black plastic Resistance Value: 10 kΩ (10,000 ohms) Power Rating: 2 W (watts) Rotational Angle / Travel: Standard potentiometer rotational travel Contact Type: Variable resistor (potentiometer) Connection Style: Screw terminal or flat connector type for modular backblocks Series: MT series modular pilot device Operating Temperature Range: Typical industrial environmental range Environmental Protection: Suitable for use in industrial control panels; degree of protection depending on assembly and panel sealing Typical Use: Adjusting control signal levels in automated machinery, operator interfaces, and variable setpoint inputs Typical Applications Manual control of analog input signal setpoints Speed reference adjustment on motor drives with external potentiometer inputs Intensity or level adjustments in analog control circuits Part of modular pilot device assemblies in industrial control panels

Technical Parameters Product Name: MJS6‑40B Joystick actuator Device Type: Modular joystick actuator for industrial control panels Function: Directional control input (momentary) Control Action: Momentary / self-return to neutral when released Directional Positions: 4 directional commands (up, down, left, right) Mounting Hole Diameter: 22 mm panel cutout Actuator Collar / Bezel Material: Plastic bezel with frame for mounting support Operating Protection Rating: IP66/IP67/IP69K when correctly assembled with sealing accessories Color: Typically black actuator and bezel Contact Blocks: Not included; requires separate modular contact blocks to complete the switch function Electrical Ratings: Depends on installed contact blocks; suitable for industrial control circuits Mechanical Life: High durability for frequent actuation Typical Panel Use: Machinery control panels, operator interfaces, conveyor controls, manual directional inputs Typical Applications Manual directional control for motors and actuators Operator interface in industrial automation systems Panel-mounted joystick input for machine operation Custom control functions requiring momentary directional input

Technical Parameters Product Name: RC5‑2/440 surge suppressor Manufacturer: ABB Type: RC‑type surge suppressor accessory for contactor coils Operating Voltage Range: Designed for control circuits with AC supply between 250 V and 440 V AC, 50/60 Hz Function: Limits and attenuates overvoltage peaks and high‑frequency transient voltage spikes generated when contactor coils open Mounting Method: Clip‑on attachment to the contactor or contactor relay base (top or side depending on design) Typical Use Case: Installed with conventional AC contactors to protect control coil circuits and nearby electronics from inductive surges Suitable For Use With: Medium‑sized contactor ranges (e.g., A45 through A110 series and similar ABB contactors) Operating Temperature Range: Approximately –20 °C to +70 °C Construction: Compact module for direct attachment without increasing overall contactor dimensions Weight: Very light, suitable for auxiliary and control circuit applications Application Field: Industrial motor control panels, automation systems, control cabinets — wherever contactor coils are used under AC control conditions
