Parameters: Model Number: ABB 1SDA055824R1 Rated Voltage: 400 V AC (Three-phase) Rated Current: Typically used for protection within a range of 16 A to 630 A (depending on the specific circuit protection needs) Frequency: 50/60 Hz Protection Type: Long-Time Protection: Provides protection against prolonged overcurrents, adjustable based on the motor or system specifications. Short-Time Protection: Detects and isolates short-circuit conditions after a brief delay, adjustable based on the fault type. Instantaneous Protection: Provides immediate protection against very high short-circuit currents, tripping almost instantaneously to prevent equipment damage. Ground Fault Protection (G): Detects leakage currents or ground faults, isolating the circuit to prevent electrical hazards. Breaking Capacity (Icu): Typically 36 kA or 50 kA at 400 V (depending on the model and rating). Mounting Type: Designed for DIN rail mounting for ease of installation in electrical panels and distribution boards. Degree of Protection: IP20 (for indoor use; optional kits for outdoor or harsh environments) Weight: Approx. 2.5 kg (depending on configuration) Dimensions (H x W x D): Approx. 200 x 100 x 140 mm (varies depending on the configuration) Auxiliary Contacts (Optional): Available for signaling, monitoring, or integration with control systems. Communication Protocol (Optional): May support communication with PLCs or SCADA systems for remote monitoring and diagnostics.

Parameters: Model Number: ABB E3H1600 R1600 PR121/P-LSIG WHR 3P Rated Voltage: 400 V AC (Three-phase) Rated Current: 1600 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection against prolonged overcurrents. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay for protecting against short-circuit faults. Instantaneous Protection (I): Instantaneous tripping for severe short-circuit faults to prevent immediate damage to equipment. Ground Fault Protection (G): Detects leakage currents or ground faults and isolates the faulty section to prevent electrical hazards. Thermal Overload Protection: Protects against motor and system overheating, ensuring the longevity and reliability of the equipment. Breaking Capacity (Icu): 50 kA at 400 V, suitable for high-fault conditions and ensuring safe and reliable operation. Mounting Type: Designed for DIN rail mounting, making installation and integration into control panels straightforward. Degree of Protection: IP20 (suitable for indoor use; optional kits available for harsher environments or outdoor use). Weight: Approx. 15 kg (depends on configuration and additional options). Dimensions (H x W x D): Approx. 450 x 250 x 180 mm (varies depending on configuration). Modbus RTU Communication (Optional): For integration with PLC or SCADA systems, enabling remote monitoring, diagnostics, and fault detection. Auxiliary Contacts (Optional): Available for use with control systems to provide feedback or signal system faults.

Parameters: Model Number: ABB E3N2000 R2000 PR121/P PR122/P Rated Voltage: 400 V AC (Three-phase) Rated Current: 2000 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current to provide protection against overload conditions. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with time delay to protect against short-circuit faults without nuisance tripping. Instantaneous Protection (I): Provides immediate disconnection during severe short-circuit conditions, ensuring rapid protection of equipment. Ground Fault Protection (G): Detects leakage currents or ground faults, isolating faulty circuits and preventing electrical hazards. Thermal Overload Protection: Prevents overheating of motors and equipment by monitoring the temperature and load, ensuring the longevity of the equipment. Breaking Capacity (Icu): 50 kA at 400 V, suitable for handling high fault currents and ensuring safe disconnection in fault conditions. Control Voltage: 24 V DC (external supply required for communication and control features). Mounting Type: DIN rail or panel mount for easy integration into existing electrical panels and motor control centers. Degree of Protection: IP20 (indoor use; optional external protection kits for harsh environments). Weight: Approx. 15–20 kg (depending on configuration). Dimensions (H x W x D): Approx. 450 x 250 x 180 mm (subject to configuration). Modbus RTU Communication (Optional): For integration with PLC or SCADA systems, enabling remote monitoring and diagnostics. Auxiliary Contacts (Optional): Available for use in external control and signaling systems.

Parameters: Model Number: ABB E3N2000 R2000 PR121/P PR122/P Rated Voltage: 400 V AC (Three-phase) Rated Current: 2000 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current to provide protection against overload conditions. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with time delay to protect against short-circuit faults without nuisance tripping. Instantaneous Protection (I): Provides immediate disconnection during severe short-circuit conditions, ensuring rapid protection of equipment. Ground Fault Protection (G): Detects leakage currents or ground faults, isolating faulty circuits and preventing electrical hazards. Thermal Overload Protection: Prevents overheating of motors and equipment by monitoring the temperature and load, ensuring the longevity of the equipment. Breaking Capacity (Icu): 50 kA at 400 V, suitable for handling high fault currents and ensuring safe disconnection in fault conditions. Control Voltage: 24 V DC (external supply required for communication and control features). Mounting Type: DIN rail or panel mount for easy integration into existing electrical panels and motor control centers. Degree of Protection: IP20 (indoor use; optional external protection kits for harsh environments). Weight: Approx. 15–20 kg (depending on configuration). Dimensions (H x W x D): Approx. 450 x 250 x 180 mm (subject to configuration). Modbus RTU Communication (Optional): For integration with PLC or SCADA systems, enabling remote monitoring and diagnostics. Auxiliary Contacts (Optional): Available for use in external control and signaling systems.

Parameters: Model Number: ABB E3N3200 R3200 PR121/P PR122/P Rated Voltage: 400 V AC (Three-phase) Rated Current: 3200 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection, ensuring protection against prolonged overcurrents. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay, to protect against short-circuit faults. Instantaneous Protection (I): Provides immediate disconnection during severe short-circuit conditions to protect sensitive equipment. Ground Fault Protection (G): Detects leakage currents or ground faults, isolating faulty circuits and enhancing safety. Thermal Overload Protection: Continuously monitors the temperature of the system and adjusts protection to prevent overheating, extending equipment life. Breaking Capacity (Icu): 50 kA at 400 V, ideal for high-fault conditions, ensuring quick and safe disconnection to protect equipment. Mounting Type: DIN rail or panel mount, allowing easy installation in electrical control panels or motor control centers (MCCs). Degree of Protection: IP20 (indoor use; optional external protection kits available for harsh environments). Weight: Approx. 25–30 kg (depending on configuration and options). Dimensions (H x W x D): Approx. 550 x 350 x 250 mm (varies depending on specific configuration). Control Voltage: 24 V DC (external supply required for control and communication functions). Modbus RTU Communication (Optional): Enables remote monitoring, diagnostics, and fault detection via PLC or SCADA systems. Auxiliary Contacts (Optional): Available for integration with control systems for feedback or signaling purposes.

Parameters: Model Number: ABB E3N2500 R2500 PR121/P-LSIG WHR 3P Rated Voltage: 400 V AC (Three-phase) Rated Current: 2500 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection, ensuring that the system is protected from prolonged overcurrents. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay, providing protection against short-circuit faults while preventing nuisance tripping. Instantaneous Protection (I): Instantaneous tripping for severe short-circuit conditions, ensuring the system is protected from high fault currents. Ground Fault Protection (G): Ground fault protection (LSIG) detects leakage currents or faults and isolates the faulty section, improving system safety. Thermal Overload Protection: Protects against overheating of motors by monitoring temperature and adjusting protection settings as needed to ensure the equipment operates within safe thermal limits. Wide Heat Range (WHR): Ensures adaptability to different environmental temperatures, allowing for use in diverse operational conditions. Breaking Capacity (Icu): 50 kA at 400 V, suitable for handling high fault currents and ensuring rapid and safe disconnection during fault conditions. Mounting Type: DIN rail or panel mount for easy installation in electrical panels, motor control centers (MCCs), and distribution boards. Degree of Protection: IP20 (suitable for indoor environments; optional external protection kits available for harsher environments). Weight: Approx. 20–25 kg (depending on configuration). Dimensions (H x W x D): Approx. 500 x 300 x 200 mm (subject to configuration). Control Voltage: 24 V DC (external supply for control and communication functions). Modbus RTU Communication (Optional): For integration with PLC or SCADA systems, enabling remote monitoring, fault detection, and diagnostics. Auxiliary Contacts (Optional): Available for use with control systems to signal faults or provide status information to external systems.

Parameters: Model Number: ABB SACE F2S2500 R2500 PR1/P-LSIG 3P Rated Voltage: 400 V AC (Three-phase) Rated Current: 2500 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection, preventing prolonged overcurrents that could damage equipment. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay, protecting against short-circuit conditions and ensuring the system's stability. Instantaneous Protection (I): Provides immediate disconnection for high fault currents during severe short-circuit events, protecting sensitive equipment. Ground Fault Protection (G): Ground fault protection (LSIG) detects leakage currents or ground faults, isolating the faulty circuit to prevent electrical hazards. Thermal Overload Protection: Protects motors from overheating by continuously monitoring the system's temperature and adjusting the protection accordingly. Breaking Capacity (Icu): 50 kA at 400 V, ensuring that the breaker can quickly interrupt high fault currents without causing damage to the system or components. Mounting Type: DIN rail or panel mount for easy integration into existing electrical systems, such as motor control centers (MCCs) or distribution boards. Degree of Protection: IP20 (suitable for indoor environments; optional external protection kits available for harsher, outdoor environments). Weight: Approx. 20–25 kg (depending on configuration and options). Dimensions (H x W x D): Approx. 500 x 300 x 200 mm (subject to configuration). Control Voltage: 24 V DC (external supply required for control and communication features). Modbus RTU Communication (Optional): Enables remote monitoring and diagnostics via PLC or SCADA systems, allowing for real-time system health tracking and fault detection. Auxiliary Contacts (Optional): Available for use with control systems for signaling faults, remote indication, or integration with safety systems

Parameters: Model Number: ABB E1N1250 R1250 PR121/P-LSI WMP 3P Rated Voltage: 400 V AC (Three-phase) Rated Current: 1250 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection, ensuring protection against sustained overcurrents. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay, for short-circuit protection, preventing damage from transient overcurrents. Instantaneous Protection (I): Provides immediate disconnection for severe short-circuit conditions to protect sensitive equipment from high fault currents. Ground Fault Protection (G): Detects leakage currents or ground faults and isolates the faulty section, improving electrical safety. Thermal Overload Protection: Protects motors from overheating by monitoring the system’s temperature and preventing extended overcurrent conditions. Wide Motor Protection (WMP): Ensures adaptive protection tailored to motor applications, optimizing protection parameters based on specific motor types and operational conditions. Breaking Capacity (Icu): 50 kA at 400 V, ensuring the breaker can safely handle high fault currents and disconnect the system in fault conditions. Mounting Type: DIN rail or panel mount for easy integration into electrical control systems, such as motor control centers (MCCs) or distribution panels. Degree of Protection: IP20 (suitable for indoor environments; optional external protection kits available for harsh environments). Weight: Approx. 15–20 kg (depending on configuration). Dimensions (H x W x D): Approx. 400 x 250 x 180 mm (subject to configuration). Control Voltage: 24 V DC (external supply required for control and communication features). Modbus RTU Communication (Optional): For remote monitoring and diagnostics, enabling real-time system health checks and fault detection via PLC or SCADA systems. Auxiliary Contacts (Optional): Available for use in control systems, providing feedback and fault signaling to external systems.

Parameters: Model Number: ABB E4S4000 R4000 PR122/P-LSIG 4P 4000A Rated Voltage: 400 V AC (Four-pole, Three-phase system) Rated Current: 4000 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection, preventing equipment damage from prolonged overcurrents. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay, to protect against short-circuit conditions and to avoid unnecessary trips. Instantaneous Protection (I): Provides instantaneous disconnection for high fault currents, ensuring fast protection against severe short-circuit conditions. Ground Fault Protection (G): Ground fault protection (LSIG) detects leakage currents or faults and isolates the faulty section, providing enhanced safety. Thermal Overload Protection: Continuously monitors the temperature of motors and equipment, adjusting protection to prevent overheating and ensure the longevity of the system. Breaking Capacity (Icu): 65 kA at 400 V, ensuring the breaker can interrupt high fault currents and safely clear faults without damaging the system. Mounting Type: DIN rail or panel mount, making it versatile for use in motor control centers (MCCs), distribution boards, and control panels. Degree of Protection: IP20 (suitable for indoor environments; external protection kits available for harsher, outdoor conditions). Weight: Approx. 50–60 kg (depending on configuration). Dimensions (H x W x D): Approx. 650 x 450 x 300 mm (varies with configuration). Control Voltage: 24 V DC (external supply for control and communication features). Modbus RTU Communication (Optional): Enables remote monitoring, diagnostics, and fault detection through PLC or SCADA systems, allowing real-time system status checks and fault tracking. Auxiliary Contacts (Optional): Available for use with control systems for signaling faults, status monitoring, or integration with safety systems.

Parameters: Model Number: ABB E1N1600 R400/800/1600 3/4P Rated Voltage: 400 V AC (Three-phase or Four-pole systems) Rated Current: 1600 A (adjustable, with different options for 400A, 800A, or 1600A) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay, for short-circuit protection. Instantaneous Protection (I): Provides instantaneous disconnection for severe short-circuit conditions. Ground Fault Protection (G): Ground fault protection (LSI) detects leakage currents and isolates the faulty section, providing enhanced safety for the system. Thermal Overload Protection: Protects motors from overheating by monitoring the system's temperature and adjusting protection parameters accordingly. Breaking Capacity (Icu): 50 kA at 400 V, ensuring the breaker can handle high fault currents and quickly disconnect during fault events. Mounting Type: DIN rail or panel mount, making it easy to install in motor control centers (MCCs), distribution panels, and control systems. Degree of Protection: IP20 (suitable for indoor environments; optional external protection kits for harsh, outdoor conditions). Weight: Approx. 20-25 kg (depending on configuration). Dimensions (H x W x D): Approx. 500 x 300 x 200 mm (subject to configuration). Control Voltage: 24 V DC (external supply required for control and communication features). Modbus RTU Communication (Optional): Allows for remote monitoring and fault diagnostics via PLC or SCADA systems. Auxiliary Contacts (Optional): Available for use in control systems, providing feedback, signaling faults, or integrating with safety systems.

Parameters: Model Number: ABB E3S1250 R1250 PR122/P-LSI WMP 3P Rated Voltage: 400 V AC (Three-phase) Rated Current: 1250 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection, preventing sustained overcurrents that could damage equipment. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with time delay, for short-circuit protection to handle fault conditions without unnecessary tripping. Instantaneous Protection (I): Provides instantaneous disconnection during severe short-circuit conditions to protect sensitive equipment. Ground Fault Protection (G): Ground fault protection (LSI) detects leakage currents or faults in the system and isolates the faulty section, improving safety. Thermal Overload Protection: Continuously monitors motor temperature to prevent overheating and ensure safe operation under various conditions. Wide Motor Protection (WMP): Provides enhanced protection against inrush currents and load fluctuations, optimizing the motor's protection under varying operational conditions. Breaking Capacity (Icu): 50 kA at 400 V, ensuring that the breaker can safely interrupt high fault currents and clear faults quickly without damage to the system. Mounting Type: DIN rail or panel mount, making it easy to integrate into motor control centers (MCCs), distribution boards, and electrical panels. Degree of Protection: IP20 (suitable for indoor environments; optional external protection kits for harsher conditions). Weight: Approx. 20–25 kg (depending on configuration). Dimensions (H x W x D): Approx. 500 x 300 x 200 mm (subject to configuration). Control Voltage: 24 V DC (external supply required for control and communication features). Modbus RTU Communication (Optional): Enables remote monitoring and diagnostics via PLC or SCADA systems, providing real-time system health tracking and fault detection. Auxiliary Contacts (Optional): Available for control systems, offering fault signaling and feedback to external systems.

Parameters: Model Number: ABB E3S2000 R2000 PR121/P-LSI 3P Rated Voltage: 400 V AC (Three-phase) Rated Current: 2000 A (adjustable) Frequency: 50/60 Hz Protection Type: Long-Time Protection (L): Adjustable from 0.7 to 1.0 times rated current for overload protection, ensuring that motors are not damaged by prolonged overcurrents. Short-Time Protection (S): Adjustable from 3 to 10 times rated current, with a time delay, for short-circuit protection to protect against fault conditions without causing unnecessary trips. Instantaneous Protection (I): Provides instantaneous disconnection in the event of severe short-circuit conditions, protecting sensitive equipment from high fault currents. Ground Fault Protection (G): Ground fault protection (LSI) detects leakage currents or faults in the system and isolates the faulty section to prevent damage and ensure safety. Thermal Overload Protection: The breaker monitors the temperature of the system and protects motors from overheating, reducing the risk of damage due to sustained overload conditions. Breaking Capacity (Icu): 65 kA at 400 V, ensuring the breaker can interrupt high fault currents and clear faults safely without damaging the system. Mounting Type: DIN rail or panel mount, making it easy to integrate into motor control centers (MCCs), distribution panels, and electrical control systems. Degree of Protection: IP20 (suitable for indoor environments; external protection kits available for harsh conditions). Weight: Approx. 45–50 kg (depending on configuration). Dimensions (H x W x D): Approx. 600 x 400 x 250 mm (subject to configuration). Control Voltage: 24 V DC (external supply required for control and communication features). Modbus RTU Communication (Optional): Enables remote monitoring and fault diagnostics via PLC or SCADA systems, providing real-time system health tracking. Auxiliary Contacts (Optional): Available for use in control systems to provide feedback, signaling faults, or integrating with safety systems.
