Technical Specifications / Parameters Parameter Specification Manufacturer Order Code 2TAZ220203R4254 Product Family ABB Push Button & Indicator Light System (CP-S Series or similar) Device Type Emergency Stop Push Button Operator (Mushroom Head) Head Type Large, Mushroom Head for easy and reliable activation, even with a gloved hand or from an angle. Actuator Color Red Background Ring/Collar Yellow Operation Push-to-latch (lock), Pull-to-release (reset). The actuator remains in the depressed (tripped) position until manually rotated or pulled to reset. Mounting Hole Diameter 22.5 mm (Standard) Contact Configuration None (This is the operator only. It requires a separate Emergency Stop contact block, which typically has at least 1 NO and 1 NC contact with positive opening operation). Mechanical Life > 1,000,000 cycles Front Panel Protection Typically IP65 (Dust-tight and protected against water jets) when properly mounted. Material (Actuator) High-impact thermoplastic (e.g., Polyamide) Safety Standards Compliance IEC 60947-5-1, IEC 60204-1 (Safety of machinery), EN ISO 13850 (Emergency stop function principles). Features positive opening operation when used with a compatible contact block. Safety Integrity When paired with the appropriate contact block, it can be part of a Safety Function meeting performance levels (PL) per ISO 13849 or categories per IEC 62061. Compatibility Mounts onto standard ABB 22.5mm Emergency Stop contact blocks (e.g., with forced break contacts). Installation Snap-fit mounting from the front of the panel into a 22.5mm cutout.

Technical Specifications / Parameters Parameter Specification Manufacturer Order Code 2CTB803972R1200 Compatible Main Device ABB M102-M Motor Protection Relay Product Family Motor Protection & Condition Monitoring Accessories Device Type Digital Temperature Input Module (Expansion Module) Primary Function To acquire, condition, and transmit temperature data from embedded motor sensors to the main M102-M relay for processing, display, and tripping. Supported Sensor Types Pt100 Platinum Resistance Thermometers (3-wire connection typical) Number of Input Channels Typically 2 independent channels (for monitoring two separate temperature points, e.g., stator winding and bearing). Measurement Range Programmable via the M102-M relay, typically covering the full operational range of Pt100 sensors (e.g., -50°C to +250°C or wider). Accuracy High accuracy, conforming to standards such as IEC 60751 Class A or B for Pt100. Supply Voltage Powered directly from the M102-M base unit via the internal bus connection (e.g., 24 V DC). Communication Interface Proprietary digital bus to the M102-M relay. Connection Terminals Screw-clamp terminals for sensor wiring. Mounting DIN Rail Mounting (35mm). Modules snap together side-by-side with the M102-M relay to form a single cohesive unit. Module Width Typically 45mm (varies by specific accessory design; this module occupies additional space next to the main relay). Operating Temperature -25°C to +70°C (for the module itself, installed inside a control panel). Protection Degree IP20 (for installation in enclosures). Standards & Approvals IEC/EN 60255 (Measuring relays and protection equipment), IEC 61508 (Functional Safety - SIL capable as part of the system), CE, UL, cULus. Key Features • Individual channel configuration (sensor type, alarm, trip thresholds). • High noise immunity for reliable signal transmission. • Continuous self-monitoring and diagnostics.

Technical Specifications / Parameters Parameter Specification Manufacturer Order Code 1SBL281074R8010 Catalogue Type / Designation AX32-30-10-80 Brand / Series ABB AX Series (Accessories for Contactors & Relays) Product Type Auxiliary Contact Block (Accessory) Mounting Compatibility Designed to mechanically and electrically latch onto the side of specific ABB contactors and overload relays (e.g., from the A, AF, AX series, such as AF09-30-10-13). Verification with compatibility charts is essential. Number of Auxiliary Contacts 2 Contacts Contact Configuration 1 Normally Open (NO) + 1 Normally Closed (NC) (Form "a" + Form "b") Rated Operational Current (Ie) 10 A (at AC-15: 230V, DC-13: 24V - refer to ratings table) Rated Insulation Voltage (Ui) 690 V AC Rated Operational Voltage (Ue) Up to 690 V AC, 600 V DC Utilization Categories AC-15: Control of electromagnetic loads (e.g., contactor coils) DC-13: Control of electromagnetic loads with DC power Thermal Current (Ith) 10 A Mechanical Life Typically > 10 million operations Electrical Life Varies with load. Example: ~300k ops at AC-15 230V, 2.5A. Terminal Type Screw clamp terminals Wire Size Typically 0.5 - 2.5 mm² (AWG 20-14) Ambient Temperature Range -40°C to +70°C (for operation) Protection Degree IP20 when mounted on the main device. Standards Compliance IEC/EN 60947-5-1, UL 508, CSA C22.2 No. 14 Material (Housing) Thermoplastic (PA66) Mounting Position Side-mounting, specific sides depending on the main device. Function Provides remote electrical indication (e.g., "contactor ON", "motor running", "fault condition") for control, signaling, and interlocking circuits in automation panels.

Technical Specifications / Parameters Parameter Specification Manufacturer Type Code SH201-C25 Brand ABB Product Line System PRO M compact® Device Type Miniature Circuit Breaker (MCB) Number of Poles 1-Pole (1P) Rated Current (In) 25 A Rated Operational Voltage (Ue) 230/400V AC Rated Insulation Voltage (Ui) 500V AC Rated Impulse Withstand Voltage (Uimp) 4 kV Tripping Characteristic Curve C Curve (Standard magnetic setting. Instantaneous tripping range: 5In to 10In) Rated Breaking Capacity (Icn) 6 kA (According to IEC/EN 60898-1) Service Breaking Capacity (Ics) 6 kA (100% of Icn) Standards Compliance IEC/EN 60898-1 (Primary standard for household and similar installations) Terminal Type Cage Clamp Terminal (Screwless clamp technology) Connectable Conductors Rigid and Flexible Copper Conductors: 1 - 25 mm² Recommended Tightening Torque 2.0 - 2.5 Nm Electrical Endurance ≥ 20,000 making and breaking operations at rated current (In) Mechanical Endurance ≥ 20,000 operations Ambient Temperature Range (for calibration) -25°C to +55°C Mounting Snap-on mounting on 35 mm symmetrical top-hat DIN Rail (EN 60715) Module Width 18 mm (1 Pole = 1 module) Primary Protective Functions Overload (Thermal) Protection, Short-Circuit (Electromagnetic) Protection Auxiliary Functions Clear "ON" (I) and "OFF" (0) indication. Compatible with a range of System PRO M accessories such as auxiliary contacts (SH-AA) and alarm contacts (SH-AL). Common Approvals & Marks CE, CCC, IMQ, KEMA, etc. (Varies by target market) Housing Material Flame-retardant thermoplastic (Polycarbonate blend)

Technical Specifications / Parameters Parameter Specification Manufacturer Order Code 2CDS212001R0401 Catalogue Type S202-C40 Brand / Series ABB S200 Series (System PRO M) Device Type Miniature Circuit Breaker (MCB) Number of Poles 2-Pole (2P) Rated Current (In) 40 A Rated Operational Voltage (Ue) 230/400 V AC Rated Insulation Voltage (Ui) 500 V AC Rated Impulse Withstand Voltage (Uimp) 4 kV Tripping Characteristic C Curve (Standard magnetic setting. Instantaneous tripping range: 5In to 10In) Rated Breaking Capacity (Icn) 6 kA (at 400V AC, per IEC/EN 60898-1) Utilization Category A Standards Compliance IEC/EN 60898-1 (Primary, for final distribution). May also be assessed to IEC/EN 60947-2. Terminal Type Cage Clamp Terminal Connectable Conductors Solid/Fine-stranded Copper: 1 - 35 mm² Recommended Tightening Torque 3.0 - 3.5 Nm Electrical Endurance ≥ 20,000 cycles (at In) Mechanical Endurance ≥ 20,000 cycles Ambient Temperature Range -25°C to +55°C (for calibration) Mounting Snap-on mounting on 35 mm top-hat DIN Rail (EN 60715) Module Width 36 mm (2 Poles) Primary Functions Overload Protection, Short-Circuit Protection Protection Features Trip-free mechanism, clear "ON"/"OFF" visual indication. Accessory Compatibility Compatible with System PRO M accessories: auxiliary contacts (e.g., OF-A), alarm contacts (OF-AL), shunt trips (OF-SB), undervoltage releases (OF-SD), etc. Common Approvals CE, CCC, IMQ, etc.

Technical Specifications / Parameters Parameter Specification Manufacturer Order Code 2CDS251001R0324 Catalogue Type S201-B32 Brand / Series ABB S200 Series (System PRO M) Device Type Miniature Circuit Breaker (MCB) Number of Poles 1-Pole (1P) Rated Current (In) 32 A Rated Operational Voltage (Ue) 230/400 V AC Rated Insulation Voltage (Ui) 440 V AC (Industrial standard) Rated Impulse Withstand Voltage (Uimp) 6 kV Tripping Characteristic B Curve (Fast magnetic response. Instantaneous tripping range: 3In to 5In). Rated Breaking Capacity (Icn) 10 kA (at 400V AC, per IEC/EN 60947-2) Utilization Category A (Instantaneous tripping with no intentional short-circuit delay) Standards Compliance IEC/EN 60947-2 (Primary standard, Industrial application). Terminal Type Cage Clamp Terminal Connectable Conductors Solid/Fine-stranded Copper: 1 - 35 mm² Recommended Tightening Torque 3.0 - 3.5 Nm Electrical Endurance ≥ 20,000 cycles (at In) Mechanical Endurance ≥ 20,000 cycles Ambient Temperature Range -25°C to +60°C (for calibration, derating above +40°C) Mounting Snap-on mounting on 35 mm top-hat DIN Rail (EN 60715) Module Width 18 mm (1 Pole, 1 Module) Primary Functions Overload Protection, Fast Short-Circuit Protection Protection Features Trip-free mechanism, clear "ON"/"OFF" visual indication. Accessory Compatibility Compatible with the full range of S200 Series System PRO M accessories: auxiliary contacts (OF, SD), alarm contacts (OF), shunt trips, undervoltage releases, etc. Common Approvals CE, UL 1077 (as a Supplementary Protector), CCC, etc.

Technical Specifications / Parameters Parameter Specification Manufacturer Part Number VF000037 Product Type Non-Metallic (Plastic) Enclosure / Wireway / Junction Box Material High-Impact, Fiberglass-Reinforced Polyester (FRP) or equivalent robust thermoplastic. Provides excellent corrosion resistance. Color Gray (Standard ABB industrial gray) Protection Rating NEMA 4X / IP66 • Dust-tight (No ingress of dust) • Protected against powerful water jets from any direction. • X indicates corrosion resistance. Dimensions (Approx.) Refer to official drawing for exact size. Typical for a 6x8x4 inch or similar medium-sized trough. (Example only: ~150mm x 200mm x 100mm [H x W x D]) This must be verified. Mounting Multiple mounting options: typically includes mounting feet or flange with pre-molded holes for wall, panel, or DIN rail mounting inside. Cover Transparent or opaque hinged cover with a robust latch and integral gasket for secure, watertight sealing. Sealing Continuous, compressible silicone or EPDM gasket between base and cover. Drilling / Entry Pre-marked, knock-out entries (KO’s) or drilled entry points for cable glands/conduit fittings on multiple sides (top, bottom, sides). Internal Mounting May include pre-molded bosses, DIN rail mounting points (35mm), or a drilled mounting plate. Ambient Temperature Range Typically -40°C to +120°C (Storage/Operation, material dependent). Flammability Rating UL 94 V-0 or equivalent (Self-extinguishing). UV Resistance Yes, suitable for outdoor use (Material is UV-stabilized). Chemical Resistance Resistant to a wide range of oils, fuels, dilute acids, and alkalis. Standards Compliance UL Listed, CSA Certified, CE marked (as applicable). Meets NEMA 250, IEC 60529, UL 50E. Typical Applications • Field wiring junction boxes for motors and sensors. • Housing for PLC remote I/O stations. • Protection of terminal blocks in harsh environments. • Enclosure for small drives or power supplies. • Outdoor lighting control enclosures.

Technical Specifications / Parameters Parameter Specification Manufacturer Order Code 2CDS214001R0251 Catalogue Type S204-C25 Brand / Series ABB S200 Series (System PRO M) Device Type Miniature Circuit Breaker (MCB) Number of Poles 4-Pole (4P) (Breaks all three phases and the neutral) Rated Current (In) 25 A Rated Operational Voltage (Ue) 400 V AC (3P+N~) Rated Insulation Voltage (Ui) 500 V AC Rated Impulse Withstand Voltage (Uimp) 4 kV Tripping Characteristic C Curve (Standard magnetic setting. Instantaneous tripping range: 5In to 10In) Rated Breaking Capacity (Icn) 10 kA (at 400V AC, per IEC/EN 60947-2) Utilization Category A Standards Compliance IEC/EN 60947-2 (Primary, for industrial applications). May also comply with relevant sections of IEC/EN 60898-1 for final distribution. Terminal Type Cage Clamp Terminal (Screwless clamp) Connectable Conductors Solid/Fine-stranded Copper: 1 - 25 mm² Recommended Tightening Torque 2.0 - 2.5 Nm Electrical Endurance ≥ 20,000 cycles (at In) Mechanical Endurance ≥ 20,000 cycles Ambient Temperature Range -25°C to +60°C (for calibration, derating above +40°C) Mounting Snap-on mounting on 35 mm top-hat DIN Rail (EN 60715) Module Width 72 mm (4 Poles) Primary Functions Overload Protection, Short-Circuit Protection Protection Features Trip-free mechanism, clear "ON"/"OFF" visual indication. All poles switch simultaneously. Accessory Compatibility Compatible with the full range of S200 Series System PRO M accessories: auxiliary contacts (OF, SD), alarm contacts (OF), shunt trips, undervoltage releases, etc. Common Approvals CE, CCC, KEMA, etc.

Technical Specifications / Parameters Parameter Specification Manufacturer Order Code 2CDS252001R0487 Catalogue Type S202-K20 Brand / Series ABB S200 Series (System PRO M) Device Type Miniature Circuit Breaker (MCB) Number of Poles 2-Pole (2P) Rated Current (In) 20 A Rated Operational Voltage (Ue) 230/400 V AC Rated Insulation Voltage (Ui) 440 V AC Rated Impulse Withstand Voltage (Uimp) 6 kV Tripping Characteristic K Curve (Specifically designed for high inrush loads. Instantaneous tripping range: ~8In to 12In). Rated Breaking Capacity (Icn) 10 kA (at 400V AC, per IEC/EN 60947-2) Utilization Category A (Instantaneous tripping with no intentional delay for short-circuit) Standards Compliance IEC/EN 60947-2 (Industrial circuit-breaker standard) Terminal Type Cage Clamp Terminal Connectable Conductors Solid/Fine-stranded Copper: 0.75 - 35 mm² (Torque: 3.0 - 3.5 Nm) Electrical Endurance ≥ 20,000 cycles (at In) Mechanical Endurance ≥ 20,000 cycles Ambient Temperature -25°C to +60°C (for calibration, derating above +40°C) Mounting DIN Rail (35 mm, EN 60715) Module Width 36 mm (2 Poles) Primary Functions Overload Protection, Short-Circuit Protection (High Inrush Immune) Protection Features Trip-free mechanism, "ON"/"OFF" visual indication. Accessory Compatibility Compatible with the full range of S200 Series System PRO M accessories: auxiliary contacts (OF, SD), alarm contacts (OF), shunt trips, undervoltage releases, etc. Common Approvals CE, UL 1077 (Supplemental Protector), CCC, etc.

Technical Specifications / Parameters Parameter Specification Manufacturer Type Code SH201-C10 Brand ABB Product Line System PRO M compact® Device Type Miniature Circuit Breaker (MCB) Number of Poles 1-Pole (1P) Rated Current (In) 10 A Rated Operational Voltage (Ue) 230/400V AC Rated Insulation Voltage (Ui) 500V AC Rated Impulse Withstand Voltage (Uimp) 4 kV Tripping Characteristic Curve C Curve (Standard magnetic setting. Instantaneous tripping range: 5In to 10In) Rated Breaking Capacity (Icn) 6 kA (According to IEC/EN 60898-1) Service Breaking Capacity (Ics) 6 kA (100% of Icn) Standards Compliance IEC/EN 60898-1 (Primary standard for household and similar installations) Terminal Type Cage Clamp Terminal (Screwless clamp technology for quick, secure wiring) Connectable Conductors Rigid and Flexible Copper Conductors: 1 - 25 mm² Recommended Tightening Torque 2.0 - 2.5 Nm Electrical Endurance ≥ 20,000 making and breaking operations at rated current (In) Mechanical Endurance ≥ 20,000 operations Ambient Temperature Range (for calibration) -25°C to +55°C Mounting Snap-on mounting on 35 mm symmetrical top-hat DIN Rail (EN 60715) Module Width 18 mm (1 Pole = 1 module) Primary Protective Functions Overload (Thermal) Protection, Short-Circuit (Electromagnetic) Protection Auxiliary Functions Clear "ON" (I) and "OFF" (0) indication. Compatible with a range of System PRO M accessories such as auxiliary contacts (SH-AA) and alarm contacts (SH-AL). Common Approvals & Marks CE, CCC, IMQ, KEMA, etc. (Varies by target market) Housing Material Flame-retardant thermoplastic (Polycarbonate blend)

Technical Specifications / Parameters Parameter Specification Manufacturer P/N (Order Code) 2CDS212001R0321 Catalogue Type SH202-D32 Brand ABB Product Line System PRO M compact® Device Type Miniature Circuit Breaker (MCB) Number of Poles 2-Pole (2P) Rated Current (In) 32 A Rated Operational Voltage (Ue) 230/400 V AC Rated Insulation Voltage (Ui) 500 V AC Rated Impulse Withstand Voltage (Uimp) 4 kV Tripping Characteristic Curve D Curve (Instantaneous tripping range: 10In to 14In). High magnetic setting for inrush tolerance. Rated Breaking Capacity (Icn) 6 kA (IEC/EN 60898-1) Service Breaking Capacity (Ics) 6 kA (100% of Icn) Standards Compliance IEC/EN 60898-1, IEC/EN 60947-2 Terminals Cage Clamp Terminal Connectable Conductors Rigid/Flexible Copper: 1 - 25 mm² Tightening Torque 2.0 - 2.5 Nm Electrical Endurance ≥ 20,000 operations (at In) Mechanical Endurance ≥ 20,000 operations Ambient Temperature -25°C to +55°C (for calibration) Mounting DIN Rail (35 mm symmetrical rail, EN 60715) Module Width 36 mm (2 Poles) Primary Functions Overload Protection, Short-Circuit Protection (High Inrush Type). Auxiliary Functions Clear "OFF" (0) indication. Compatible with System PRO M accessories: auxiliary switches (SH-AA), alarm switches (SH-AL), etc. Markings & Approvals CE, CCC, KEMA, etc. (Market dependent)

Technical Specifications / Parameters Parameter Specification Manufacturer P/N SH202-C3 Brand ABB Product Line System PRO M compact® Device Type Miniature Circuit Breaker (MCB) Number of Poles 3-Pole (3P) Rated Current (In) 2 A Rated Operational Voltage (Ue) 230/400 V AC Rated Insulation Voltage (Ui) 500 V AC Rated Impulse Withstand Voltage (Uimp) 4 kV Tripping Characteristic Curve C Curve (Instantaneous tripping range: 5In to 10In) Rated Breaking Capacity (Icn) 6 kA (IEC/EN 60898-1) Service Breaking Capacity (Ics) 6 kA (100% of Icn) Standards Compliance IEC/EN 60898-1 (Primary), IEC/EN 60947-2 (for certain declarations) Terminals Cage Clamp Terminal Connectable Conductors Rigid/Flexible Copper: 1 - 25 mm² Tightening Torque 2.0 - 2.5 Nm Electrical Endurance ≥ 20,000 operations (at In) Mechanical Endurance ≥ 20,000 operations Ambient Temperature -25°C to +55°C (for calibration) Mounting DIN Rail (35 mm symmetrical rail, EN 60715) Module Width 54 mm (3 Poles) Primary Functions Overload Protection, Short-Circuit Protection Auxiliary Functions Clear "OFF" (0) indication. Compatible with a wide range of accessories: auxiliary switches (SH-AA), alarm switches (SH-AL), undervoltage releases (SH-SD), shunt trips (SH-SB), etc. Markings & Approvals CE, IMQ, CCC, KEMA, etc. (Market dependent)
