Key Specifications Parameter Category Specification Drive Series/Model ACS150-03U-04A1-4 Rated Output Current 4.1 A Rated Output Power 1.5 kW (2 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Must be installed inside a protective control cabinet (e.g., IP20, IP54). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Method Scalar Control (V/f) Key Standard Features • Ultra-Compact & Sealed Design: All-in-one unit with a durable keypad. • Easy Mounting: Snap-on design for DIN rail or screw mounting. • Application Macros: Pre-set configurations (e.g., Hand/Auto, 2-Wire, 3-Wire). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Digital Inputs: 3 channels. • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication via an optional external module. Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small pumps, fans, miniature conveyors, packaging machinery, and other basic material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Model ACQ580-01-073A-4 Rated Output Current 73 A Rated Output Power 37 kW (50 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Fan-cooled Topology Active Front End (AFE) / Regenerative Drive with IGBTs on both the input and output sides. Control Method ABB Direct Torque Control (DTC) Key Standard Features • Four-Quadrant Operation: Full motoring and regenerative braking capability. • Ultra-Low Harmonics: Input current THDi < 5% (meets IEEE 519-2014 without external filters). • Unity Power Factor: ~1.0 across the entire speed and load range. • Regeneration to Mains: Feeds braking energy back to the supply network, improving energy efficiency. • Intelligent Control Panel (IOP) with graphical display. • Common DC Bus Capable for multi-drive systems. Protection Features • Comprehensive motor and drive protection. • Mains phase loss and undervoltage protection. • Grid feedback protection (for reverse power conditions). Application Focus Applications with frequent braking or overhauling loads: Centrifuges, Cranes & Hoists, Downhill Conveyors, Test Benches, Wire Drawing Machines. Also for installations with strict harmonic limits.

Key Specifications Parameter Category Specification Drive Series/Model ACS150-03U-03A3-4 Rated Output Current 3.3 A Rated Output Power 0.75 kW (1 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Must be installed inside a protective control cabinet (e.g., IP20, IP54). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Method Scalar Control (V/f) Key Standard Features • Ultra-Compact & Sealed Design: All-in-one unit with a durable keypad. • Easy Mounting: Snap-on design for DIN rail or screw mounting. • Application Macros: Pre-set configurations (e.g., Hand/Auto, 2-Wire, 3-Wire). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Digital Inputs: 3 channels. • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication via an optional external module. Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small pumps, fans, miniature conveyors, packaging machinery, and other basic material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Model ACS150-03E-04A7-2 Rated Output Current 4.7 A Rated Output Power 1.1 kW (1.5 HP) Input Supply Voltage 200 - 240 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating NEMA 1 / IP20 Open Type (Chassis). Must be installed inside a protective control cabinet. Control Panel Standard removable keypad (non-sealed). Cooling Method Self-cooled (convection) Control Method Scalar Control (V/f) Key Standard Features • Removable Keypad: For flexible mounting on the cabinet door. • Flexible Mounting: DIN rail or screw mounting. • Application Macros: Pre-set parameter sets (Hand/Auto, 2-Wire, 3-Wire, etc.). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication available via an optional external module. Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small pumps, fans, conveyors, and basic material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Base Model ACS580-01-124A-4 Rated Output Current 124 A Rated Output Power 55 kW (75 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Fan-cooled Control Method ABB Direct Torque Control (DTC) Key Standard Features • Energy Optimizer: Automatically minimizes energy losses. • Intelligent Control Panel (IOP): Multilingual graphical display. • Embedded Application Macros: For pumps, fans, etc. • Advanced PID Controller with sleep/wake. • Built-in Modbus RTU (RS-485). • Built-in EMC Filter (Class A). Option +K475 Embedded EtherNet/IP Adapter Module • Protocol: EtherNet/IP™ (CIP) Scanner/Adapter. • Ports: 2 x RJ45 (10/100 Mbps), switchable, with integrated network diagnostics (LEDs). • Function: Enables direct integration into EtherNet/IP networks for real-time control (I/O messaging) and configuration (explicit messaging). Supports cyclic and acyclic data exchange for seamless connectivity with Rockwell Automation PLCs (e.g., ControlLogix, CompactLogix) and other EtherNet/IP masters. Protection Features • Comprehensive motor thermal and electrical protection. • Drive IGBT overtemperature protection. Application Focus Pumps, fans, compressors, conveyors, and mixers within EtherNet/IP networked industrial plants, particularly those using Allen-Bradley control systems.

Key Specifications Parameter Category Specification Drive Series/Model ACS310-03U-17A2-4 Rated Output Current 17.2 A Rated Output Power 7.5 kW (10 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Methods • Scalar Control (V/f) • ABB Direct Torque Control (DTC) for superior performance. Key Standard Features • Intelligent Pump and Fan Control (IPF): Includes auto-tuning for energy optimization, multi-pump control logic, dry pump protection, and anti-jam. • Adaptive Program (AUP): Guides user through commissioning. • Built-in Communication Protocols: Modbus RTU (RS-485) and BACnet MS/TP are standard for building automation. • Integrated EMC Filter (Class A). • PID Controller: Advanced controller with sleep/wake and cascade control. • Embedded Application Programming: Basic function blocks for custom logic. Protection Features • Motor thermal overload protection (I²t) • Pump/Fan-specific protection (dry pump, overload, underload) • Short circuit, ground fault, overcurrent, overvoltage protection • IGBT overtemperature protection Application Focus HVAC systems (fans, pumps), pressure boosting, water supply, cooling towers

Key Specifications Parameter Category Specification Drive Series/Model ACS800-04M-0260-3+P901 Configuration Modular (IP00), for cabinet installation. Rated Output Current 260 A Rated Output Power 160 kW (215 HP) (at 400V, 3-phase) Input Supply Voltage 380 - 415 V AC (±10-15%), 3-phase, 50/60 Hz (Typical for "-3" voltage code). Output Voltage/Phases 3-phase, 0 - Input voltage. Control Platform ABB Direct Torque Control (DTC). Key Hardware Features • Modular Design: For flexible system integration. • Common DC Bus Ready: Can be connected to a shared DC bus system. • Built-in Diode Rectifier (in standard configuration). • Requires external cooling (fan/air duct) as per cabinet design. Option +P901 Standard Control Program with I/O Extension • Function: Provides the essential firmware and associated hardware (likely an I/O extension board) to make the drive operational. • Includes: Standard application software, extensive I/O capabilities (digital/analog inputs & outputs, relay outputs), and standard control features for speed and torque regulation. Communication Supports various fieldbus protocols (e.g., PROFIBUS DP, Modbus) via optional adapter modules . Protection Features • Motor thermal overload. • Short circuit, ground fault, over/undervoltage. • IGBT and heatsink overtemperature. Application Focus High-power industrial applications within multi-drive systems: Extruders, Conveyors, Large Pumps & Fans, Crushers, Test Benches.

Key Specifications) Parameter Category Specification Drive Series/Base Model ACS355-03E-08A8-4 Rated Output Current 8.0 A Rated Output Power 3.0 kW (4 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP20 / UL Open Type (Chassis). Control Panel Removable Control Panel (RCP) with backlit LCD. Cooling Method Self-cooled (with internal fan) Control Methods • Scalar Control (V/f) • ABB Direct Torque Control (DTC) Key Standard Features • Removable Control Panel (RCP). • Built-in EMC Filter (Class A). • Application Macros (Factory, Hand/Auto, Pump/Fan). • Built-in PID Controller. • Built-in Modbus RTU (RS-485). • Basic I/O: 2 analog inputs, 1 analog output; 3 digital inputs, 1 relay output. Option +B063 Embedded PROFIBUS DP-V1 Adapter Module • Protocol: PROFIBUS DP-V1 (符合 EN 50170). Protection Features • Motor thermal overload protection (I²t) • Short circuit, ground fault, overcurrent, overvoltage protection • IGBT overtemperature protection Application Focus General industrial machinery (Pumps, Fans, Conveyors) within PROFIBUS DP networked automation systems, commonly found with Siemens PLCs.

Key Specifications Parameter Category Specification Drive Series/Base Model ACS380-040C-12A6-4 Rated Output Current 12.6 A Rated Output Power 5.5 kW (7.5 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating NEMA 1 / IP20 Open Type (Chassis). Requires installation in a protective cabinet. Cooling Method Shaft-through fan cooling (indicated by 'C' in -040C) Control Method Sensorless Flux Vector Control (Magnetic Flux Control, MFC) Key Standard Features • Material Handling Macros: Pre-programmed for conveyors, hoists. • Dynamic Braking Control: Logic for external brake resistors. • Torque Control & Limits: For tension control and overload prevention. • S-curve Acceleration/Deceleration. • Removable Control Panel (RCP) with backlit display. • Integrated EMC Filter (Class A). • Built-in Modbus RTU (RS-485). Option +K475 Embedded EtherNet/IP Adapter Module • Protocol: EtherNet/IP™ (Scanner/Adapter). • Ports: 2 x RJ45 (10/100 Mbps), switchable. • Function: Enables direct, high-speed integration into EtherNet/IP networks for control (I/O messaging) and configuration (explicit messaging). Allows seamless connection to Rockwell Automation PLCs (ControlLogix, CompactLogix) and other EtherNet/IP masters. Protection Features • Motor thermal and electrical protection. • Drive IGBT overtemperature protection. • Motor stall/underload protection. Application Focus Conveyor systems, sorting lines, palletizers, small cranes/hoists, and other material handling equipment within EtherNet/IP networked factories.

Key Specifications Parameter Category Specification Drive Series/Model ACS320-03U-14A6-2 Rated Output Current 14.6 A Rated Output Power 4.0 kW (5 HP) Input Supply Voltage 200 - 240 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP00 (Open Chassis). Must be installed inside a protective control cabinet (e.g., IP20, IP54). Control Panel Integrated, Sealed Keypad (IP66 protection for the keypad). Potted and non-removable in standard form. Cooling Method Self-cooled (convection) Control Method Sensorless Vector Control Key Standard Features • Ultra-Compact & Sealed Design: All-in-one unit with a durable keypad for harsh environments. • Easy Mounting: Snap-on design for DIN rail or screw mounting. • Application Macros: Pre-set configurations for common tasks (e.g., Hand/Auto, 2-Wire, 3-Wire). • Analog Input: 1 channel (configurable for 0/4...20 mA or 0...10 V). • Digital Inputs: 3 channels. • Relay Output: 1 changeover contact. • Modbus RTU (RS-485) communication via an optional external module (e.g., NAMC-01). Protection Features • Motor thermal overload protection (I²t model) • Short circuit, ground fault, overcurrent, and overvoltage protection • IGBT overtemperature protection • Motor stall prevention Typical Applications Small conveyors, pumps, fans, packaging machines, and other general-purpose material handling equipment.

Key Specifications Parameter Category Specification Drive Series/Model ACS355-01E-07A5-2 Rated Output Current 7.5 A Rated Output Power 2.2 kW (3 HP) Input Supply Voltage 200 - 240 V AC (± 10%), 1-phase Input Supply Phases 1-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP20 / UL Open Type (Chassis). Must be installed inside a protective control cabinet. Control Panel Removable Control Panel (RCP) with backlit LCD. Cooling Method Self-cooled (convection) Control Methods • Scalar Control (V/f) for standard applications. • ABB Direct Torque Control (DTC) for high dynamic performance (precise torque control, fast response). Key Standard Features • Removable Control Panel (RCP): Allows for remote mounting and easy parameter copy. • Built-in EMC Filter (Class A). • Application Macros: Pre-programmed parameter sets for common tasks (Factory, Hand/Auto, Pump/Fan). • Built-in PID Controller with sleep/wake function. • Flying Start and DC Magnetization. • Built-in I/O: 2 analog inputs (0/4...20 mA, 0...10 V), 1 analog output; 3 digital inputs, 1 relay output. • Fieldbus Connectivity: Built-in Modbus RTU (RS-485); optional adapters for PROFIBUS DP, DeviceNet, CANopen, etc. Protection Features • Motor thermal overload protection (I²t) • Short circuit, ground fault, overcurrent, and overvoltage protection • Motor stall and underload protection • IGBT overtemperature protection • Power loss ride-through Application Focus General-purpose industrial machinery (Pumps, Fans, Conveyors, Mixers, Packaging machines).

Key Specifications Parameter Category Specification Product Type Digital Servo Drive / Servo Amplifier ABB Series / Model ACSM1-04AS-07A0-4 Rated Output Current 7.0 A RMS (Continuous) Peak Output Current Typically 14 A (for short durations, e.g., 100% overload). Rated Output Power 2.2 kW (with a compatible motor) Input Supply Voltage 380 - 480 V AC (±10%), 3-phase, 50/60 Hz DC Bus Voltage ~540 - 680 V DC Output Phases 3-phase to motor (U, V, W) Control Technology Field-Oriented Control (FOC) / Vector Control Feedback Interface Supports high-resolution encoders (e.g., EnDat 2.2, HIPERFACE®, Resolver, Sin/Cos). Key Standard Features • Integrated Motion Controller: Programmable via ABB's Motion Desktop software. • Integrated Safety: Safe Torque Off (STO) according to SIL 2/PL d (or SIL 3/PL e). • Fieldbus Connectivity: Built-in EtherCAT master/slave interface for high-speed network integration. PROFINET and others via optional modules. • Compact Design: High power density for cabinet mounting. • Extensive I/O: Digital and analog I/O for sensors and control signals. Protection Features • Overcurrent, short circuit, ground fault protection. • IGBT overtemperature protection. • Motor overload and overspeed protection. • Undervoltage and overvoltage protection on DC bus. Application Focus High-precision industrial automation: Robotics, Packaging Machinery, Material Handling, Printing, Machine Tools, Assembly Systems.
