Typical Specifications Specification Value / Description Model Name ABB EKIP COM GPRS‑M Catalog / Product ID 1SDA074165R1 Function Wireless GPRS communication module Communication Standard GSM/GPRS (quad‑band) Frequency Bands 850 / 900 / 1800 / 1900 MHz Communication Modes SMS, TCP/UDP over GPRS Auxiliary Supply Voltage 24 V DC (±20%) Power Consumption ~6 W max typical Protocol Support Modbus RTU over system bus (connection to ABB device) Network Support GPRS mobile data network connections Mounting DIN‑rail mount Weight ~1 kg Dimensions ~250 × 250 × 300 mm (packaged product) Operating Temperature Typically −25 °C to +70 °C Relative Humidity Typical industrial range Application Remote monitoring and data communication for protection/energy devices

Specifications Specification Details Model Number 1SDA058273R1 Product Type Key Lock Accessory Intended Use Lock circuit breaker in OPEN (OFF) position Key Number 20007 Position Open (OFF) Mounting Style Panel / breaker handle accessory Construction Mechanical lock body with key slot Weight (approx.) 0.3 kg Application Industrial electrical distribution panels; maintenance safety interlock Functional Summary Locks the breaker handle to prevent accidental closing Keyed access for authorized operation only Ensures safe isolation for maintenance or extended OFF periods Fits ABB Emax breaker family

Typical Specifications Specification Typical Value / Feature Product Model ABB EMPLUS‑PRO Product Type Power / energy monitoring instrument Measurement Type Three‑phase (or single‑phase) AC network Measured Parameters Voltage (V), Current (A), Active Power (kW), Reactive Power (kvar), Apparent Power (kVA), Energy (kWh), Power Factor, Frequency (Hz) Display Digital / LCD with multi‑parameter view Input Voltage Range ~100–690 VAC (varies by model) Current Input Direct measurement or via external CTs (Current Transformers) Communication Protocols Optional Modbus RTU, Ethernet (depends on specific variant) Mounting DIN‑rail or panel mount Operating Temperature Typical industrial range (e.g., −10 °C to +55 °C) Accuracy Class Class 1 / Class B / varies by configuration Typical Uses Energy monitoring, load profiling, demand tracking, power quality analysis Standards Compliance IEC/EN standards for energy metering (model/pi specific)

Key Specifications Specification Value / Description Model ABB RLY‑DMJ45R‑01 Product Type Gas Density Sensor / Density Relay Application Insulating gas (e.g., SF₆) density monitoring in high‑voltage equipment Output Type Relay contact outputs (switching contacts) Contact Functions Density‑high, density‑low thresholds switch contacts Standard Operating Range Normal gas pressure/density ranges typical for rated equipment (factory configured) Contact Return / Action Values Specific alarm and release values for density thresholds (factory set) Variants RLY‑DMJ45R‑01 through ‑04 for different contact compatibility and altitude adjustments Mounting / Package Relay housing suitable for control panels or relay racks Typical Use Cases SF₆ circuit breaker/gas‑insulated switchgear gas monitoring, alarm systems

Key Specifications Specification Value / Description Model Name ABB PM564‑T‑ETH Product Type PLC CPU Module (AC500‑eCo) Input Power Supply 24 V DC (typical for AC500‑eCo modules) Memory (Program) ~128 kB Digital Inputs 6 digital inputs (24 V DC) Digital Outputs 6 transistor outputs Analog Inputs 2 analog inputs Analog Outputs 1 analog output Communication Interfaces 1x Industrial Ethernet, 1x RS‑485 serial Expandable Slots 2 option slots for additional modules Programming Standard IEC 61131‑3 compatible (via ABB programming tools) Operating Temperature Industrial range (e.g., −25 °C to +60 °C typical) Protection Rating IP20 (standard control cabinet environment) Dimensions (approx.) ~74 × 82 × 135 mm (module size) Weight (approx.) ~0.3 kg (compact CPU module) Typical Use Cases Machine control, process automation, material handling systems Industry Industrial automation / PLC systems

Key Specifications Specification Details Model ABB PSTX370‑600‑70 Type Soft Starter (Solid‑State Motor Starter) Operational Current Rating 370 A (max) Main Voltage Range 208–600 V AC (three‑phase) Control Supply Voltage 100–250 V AC, 50/60 Hz Compatible Motor Power (typical) Up to ~125 HP at ~230 VAC, ~300 HP at ~480 VAC, ~350 HP at ~575 VAC Control Mode Voltage/torque ramp start and stop Built‑in Bypass Yes (reduces heat loss and improves efficiency) Overload Relay Class Class 10 Communications Built‑in Modbus RTU; supports optional fieldbus modules Phase 3‑phase Protection Rating IP00 (main terminals) / IP20 (control area) Ambient Operating Temp. –25 °C to +60 °C Enclosure Options IP00 / IP20 / IP66 (depending on installation) Weight (approx.) ~18.5 kg Dimensions ~470 × 258 × 279 mm Special Functions Current limit, kickstart, jog, braking, emergency/fire pump mode, diagnostics, pump cleaning Approvals CE, UL/cUL (varies by market)

Key Specifications Specification Value / Description Model Number DCS550‑S01‑0135‑05‑00‑00 Drive Series ABB DCS550 Standard DC Drives Drive Type Non‑reversing DC Drive (2‑Quadrant) Rated DC Armature Current 135 A DC (continuous) Rated Field Current ~18 A DC (integrated field exciter) Input Voltage Range 3‑phase AC, 400–525 V (typical) DC Bus Voltage Range ~525 V DC Control Type Digital DC motor control with built‑in PID Control Quadrant Forward + braking (2‑quadrant) Enclosure / Mounting Panel or cabinet mount Series Features Integrated field exciter, adaptive programming, communication interfaces Typical Uses Industrial DC motor speed/torque control Ambient Operating Conditions Industrial environments (temperature range varies with installation)

Key Specifications Specification Value / Description Model Number DCS550‑S01‑0180‑05‑00‑00 Drive Series ABB DCS550 Standard DC Drives Drive Type DC Drive / DC Rectifier Module Control Quadrant 2‑quadrant (forward + braking control) DC Bus Voltage Rating ~525 V DC Rated DC Armature Current 180 A DC Rectifier Configuration Single bridge / rectifier assembly Integrated Field Supply/Excitation Supports field excitation Installation Panel‑mounted module Application Class DC motor speed control for industrial machines Series Features Compact design, built‑in control software options Approx. Weight ~16 kg (typical for F2 frame size) Dimensions (approx.) ~370 × 264 × 270 mm

Key Specifications Specification Value / Description Model Name ABB DCS550‑S01‑0900‑05 Drive Category DC Motor Drive / DC Converter Drive Quadrant 2‑Quadrant (forward + braking) Input Voltage Range ~400–525 VAC three‑phase Rated DC Armature Current ~900 A DC Field Current ~35 A (integrated field exciter) Control Type Digital control with PID and adaptive programming Communication Interfaces Optional fieldbus support (e.g., EtherCAT, PROFINET) Commissioning Tools Startup assistants / built‑in diagnostic aids Typical Uses Extruders, printing machines, presses, plastics and rubber lines Design Features Compact size, rugged construction, easy integration User Interface Large control panel for settings and diagnostics

Key Specifications Specification Value Model Number DCS800‑S01‑0180‑05 Drive Type DC Drive / DC Converter Module Input Voltage Range 3‑phase AC 200–240 VAC or 400–480 VAC Output Type DC output (up to ~500 VDC) Rated Output Current ~175 A DC Control Type Non‑regenerative (2‑quadrant, non‑reversing) Phase (Input) 3‑phase Duty Rating ~50 HP (at 240 V AC input); ~100 HP (at 480 VAC) Enclosure / Mounting Open / Module style (IP00) Weight (approx.) 30–46 lbs (≈14–21 kg) Operating Frequency 50/60 Hz Control Features Digital I/O, relay outputs, encoder/digital feedback available Typical Applications Metals, pulp & paper, printing, mining, material handling, magnets, battery charging

Key Specifications Specification Value Model: ACS355‑03E‑08A8‑4 Drive Type: Variable Frequency Drive (AC Inverter) Input Voltage: 380–480 V AC, 3‑phase Rated Output Power: 4.0 kW (~5 HP) Rated Output Current: 8.8 A Frequency Range: 50/60 Hz (48–63 Hz operating) Enclosure Rating: IP20 / Open type Mounting Type: Wall‑mounted module Compatible Motor Type: 3‑phase AC induction and PM motors EMC Filtering: Built‑in C3 (typical) Safety Feature: Safe Torque Off (STO) Typical Use Case: Industrial machinery motor control

Specifications Specification Value Input Voltage 380–480 VAC three‑phase Frequency 50/60 Hz Output Power / Motor Size ~25 HP (18.5 kW) Current Rating 38 A Phase 3‑Phase Drive Type Variable Frequency Drive (AC motor drive) Typical Use Case HVAC motor control, pumps, fans Manufacturer Warranty Often discontinued / no original warranty Weight (approx.) ~54 lbs (≈24.5 kg)
