Key Specifications Specification Details Model ABB AF40‑30‑00‑13 Product Type AC/DC Operated IEC Contactor Series AF40 Order Code 1SBL347001R1300 Number of Poles 3 (three‑phase) Main Contacts 3 NO (Normally Open) Rated Control Voltage (Uc) 100–250 V AC/DC Rated Operational Voltage up to 690 V AC (IEC) / 600 V AC (UL) Rated Operational Current AC‑1 up to 70 A (general use) Rated Operational Current AC‑3 (Motor) typically 42 A at 400 V (≈18.5 kW) Motor Power Ratings ~18.5 kW @ 400 V AC, ~30 hp @ 480 V AC Frequency 50/60 Hz Coil Type Electronic AC/DC coil (wide range) Connection Type Screw terminals Mounting DIN‑rail or panel mount Surge Protection Built‑in Mechanical Durability ~10,000,000 operations Protection Rating IP10/IP20 (depending on installation) Operating Temperature approx. −60 °C to +80 °C Dimensions ~125.5 mm H × 55 mm W × 111 mm D Weight ~0.95 kg Standards IEC 60947‑1 and IEC 60947‑4‑1 compliant

Key Specifications Specification Value / Description Product Name ABB AF65‑30‑00‑11 Product Type 3‑Pole AC Contactor Series AF Contactors Main Contact Configuration 3 NO (Normally Open) Rated Insulation Voltage (Ui) 690 V AC (IEC) / 600 V AC (UL/CSA) Rated Operational Voltage Up to 690 V AC Rated Current (AC‑1) 105 A @ 690 V (40 °C) Rated Operational Current (AC‑3) 65 A @ 220‑240 V, 65 A @ 380‑440 V, 55 A @ 500 V, 39 A @ 690 V Rated Operational Power (AC‑3) 18.5 kW @ 220‑240 V, 30 kW @ 380‑400 V, 37 kW @ 415‑690 V Control Voltage Range (Uc) 24–60 V AC (50/60 Hz), 20–60 V DC Frequency 50/60 Hz Coil Type Electronically controlled Auxiliary Contacts None (0 NO/0 NC) Terminals Screw type Mounting Panel / DIN rail compatible frame Protection Rating IP10/IP20 (depending on installation) Mechanical Durability ~10,000,000 operations Operating Temperature –40 °C to +70 °C Wire Connection Sizes Main: up to 35 mm² flexible / 1–2.5 mm² control Altitude Up to 3000 m (no derating) Standards IEC/EN 60947‑1, IEC/EN 60947‑4‑1 Typical Use Motor control, power circuit switching

Key Specifications Specification Value / Description Product Name ABB T6H 630 PR221DS‑I 3P MCCB Manufacturer ABB Series / Family SACE Tmax T6 Order Code 1SDA060247R1 Rated Current (In) 630 A Poles 3 (three‑phase) Trip Unit Type Electronic trip unit PR221DS‑I Rated Operational Voltage Up to 690 V AC Rated Insulation Voltage (Ui) 1000 V AC Rated Impulse Withstand Voltage (Uimp) 8 kV Rated Service Breaking Capacity (Ics) up to 70 kA @ 400 V AC (application dependent) Rated Ultimate Breaking Capacity (Icu) up to ~70 kA @ 400 V AC; lower at higher voltages Pole Connection Type Fixed with front terminals Connection Style Bolt connection Performance Level H (high breaking performance) Mechanical Durability ~20,000 cycles Electrical Durability ~7,000 cycles Power Loss per Pole ~20 W at rated conditions Protection Roles Overload, short‑circuit, instant fault protection Standards IEC / EN molded case circuit breaker standards Degree of Protection IP20 (typical enclosure)

Key Specifications Specification Value / Description Model Name MOD600ADI8MH (ABB digital input module) Module Type Digital input interface Number of Inputs 8 digital inputs Input Type Discrete/binary input channels Application Remote I/O expansion for automation or protection systems System Platform RIO600 / ABB modular I/O systems Mounting Fits into rack or base unit slot (system dependent) Status LEDs Typically present for input status indication Typical Use Case Monitoring discrete field signals (switches, contacts, alarms) Operating Environment Industrial control panels / switchgear rooms Country of Origin China (varies by supply)

Key Specifications Specification Value / Description Part Number OFAF000H80 ABB Order Code 1SCA022627R1470 Fuse Size NH000 Fuse Type gG (general purpose; full range protection) Rated Current (Iₙ) 80 A Rated Voltage (AC) 500 V AC Rated Voltage (DC) 500 V DC Rated Breaking Capacity Up to 120 kA (depends on system configuration) Standards Compliance IEC 60269 series Power Loss at Rated Current ~6.5 W Body Width ~21 mm Body Height ~79 mm Body Length / Depth ~53 mm Fuse System DIN NH fuse system Usage Type AC/DC circuit protection Environmental Compliance RoHS / REACH compliant Mounting Used with NH000 fuse holders and switchgear frames

Specifications Parameter Category Specification Module Type S800 I/O Station Interface & Power Supply Module Product Family S800 Remote I/O Primary Function • Station Communication Interface: Connects the remote station to a fieldbus network via a separate communication module. • Internal Bus Power Supply: Provides a stabilized 5.1 VDC, 1.5A internal bus for all connected I/O modules. • Isolation: Provides electrical isolation between the fieldbus network and the internal I/O circuits. Compatible Communication Modules Interfaces with fieldbus communication modules (e.g., CI873 for PROFIBUS DP, CI854 for PROFINET, CI851 for Ethernet/IP) which plug directly onto it. I/O Module Capacity Can power and manage up to 12 S800 I/O modules in a single station (mounted to its right). Field-side Power Supply Requires an external 24 VDC power source (typically from terminal X5) to power the module's internal electronics and the I/O modules. Output Voltage (Internal Bus) 5.1 VDC Output Current (Internal Bus) 1.5 A (max) Power Dissipation Approx. 6.5 W (typical) Electrical Isolation 1500 V AC (between fieldbus side and internal I/O circuits). Diagnostic Indicators (LEDs) • PS (Power Supply): Indicates 24V external power status. • 5V: Indicates 5.1V internal bus status. • COM: Indicates communication status with the connected fieldbus module. Mounting Mounts on a standard DIN rail. Must be placed as the left-most module in an S800 station. Ambient Temperature 0°C to +55°C (operating) Primary Application Building distributed, remote I/O stations in industrial automation systems to reduce wiring costs and centralize control via fieldbus networks. Certifications CE, UL, cUL, ATEX (for specific conditions and when used with certified I/O modules).

Key Specifications Specification Value / Description Product Name ABB AF09‑40‑00‑13 Product Type IEC Contactor (non‑reversing) Series AF09 Number of Poles 4 Main Contact Configuration 4 Normally Open (4 NO) Rated Operational Current (AC‑1) 25 A Rated Insulation Voltage (Ui) 690 V AC (IEC) / 600 V UL Coil Voltage Range 100–250 V AC/DC Rated Operational Current (AC‑3) ~9 A at 400 V AC Rated Motor Power (AC‑3) Up to ~4 kW @ 400 V AC Control Frequency 50/60 Hz Mounting Type DIN‑rail / Screw terminals Terminal Type Screw Temperature Range (Operation) ~‑40 °C to +70 °C Coil Types Supported Both AC and DC coils Surge Suppression Integrated Degrees of Protection IP20 (typical) Standards Compliance IEC 60947‑1, IEC 60947‑4‑1, UL/CUL, CE, RoHS certified Weight (approx.) ~0.27 kg Dimensions (H × W × D) ~86 × 45 × 77 mm

Key Specifications Specification Details Model ABB CP1‑10B‑10 Type Compact momentary pushbutton switch Contact Configuration Single normally open (SPST‑NO) Actuator Style Flush non‑illuminated button, black Mounting Panel mount (cutout Ø 22.3 mm) Terminals Screw clamp connections Rated Operating Current (AC) 1.5 A max. Rated Operating Voltage (AC) Up to ~127 VAC (rated example) Rated Operating Current (DC) Up to ~0.3 A @ 24 VDC Mechanical Duty ~0.5 million operations Protection / Enclosure Rating Front: IP66/IP67/IP69K (sealed front), Terminal area: IP20 Operating Temperature –25 °C to +70 °C Storage Temperature –40 °C to +85 °C Housing Material Black plastic bezel and body Standards Designed per IEC/EN 60947‑5‑1, EN 60529 environmental ratings Panel Cutout Diameter ~22.3 mm wide Typical Use Industrial control panels, machinery operator interfaces

Specifications Specification Value / Description Model ABB 83330‑500 Product Type Switch actuator (door/light control) System Platform ABB‑Welcome / Busch‑Welcome door communication Bus Voltage (2‑wire bus) ~28 V DC ± 2 V Operating Temperature −5 °C to +45 °C Protection Rating IP20 Output (Door Opener) Max 3 A Output (Light Switch) Loads such as: Neon: 350 W, 230 V halogen: 300 W, Low‑voltage halogen w/ conventional transformer: 350 VA, Low‑voltage halogen w/ electronic transformer: 300 VA Wire Clamps (Single‑wire) 2 × 0.6 mm² – 2 × 1 mm² Wire Clamps (Fine‑wire) 2 × 0.6 mm² – 2 × 0.75 mm² Module Width (MW) ~4 MW (modular width unit in DIN system) Typical Use Control of door openers and entrance lighting in an ABB‑Welcome door entry system

Specifications Specification Value / Description Model TVOC‑2‑H1 HMI display ABB Order Code 1SFA664002R1005 Product Type Additional HMI display for arc guard system Used With TVOC‑2 Arc Guard System (main arc monitor) Mounting Mounted on main unit or switchgear door Connection Interface RJ45 cable (included, typically 3 m) Display / Interface Type HMI (visual status display for arc monitoring) Auxiliary Contacts None (no NO/NC contacts) Power Loss ~1 W Weight ~0.115 kg Dimensions (H × W × D) ~82 × 130 × 27 mm Terminal Type Screw terminals Operating Temperature Range −25 °C to +55 °C Certifications UL listed (e.g., UL_20110511‑E155370) RoHS Compliance Yes (RoHS directive compliant) Typical Use Case Arc fault status display extension for TVOC‑2 system Environmental Rating Front panel suitable for switchgear environment

Key Parameters Specification Value / Description Product Name OFD500EA Electronic Fuse Monitor ABB Order Code 1SCA121776R1001 Function Status monitoring of DC fuses (detects blown fuse) Rated Supply Voltage 110–500 V DC (for fuse status detection) Output(s) Auxiliary contact output indicating fuse open/closed Contact Configuration Typically 1 NO + 1 NC (change‑of‑state on fuse condition) Mounting Panel / switchgear accessory mounting Mounting Options DIN‑rail or accessory plate (depending on system) Net Weight ~0.155 kg Housing Dimensions ~95 mm × 55 mm × 115 mm (approx.) Application Low‑voltage switchgear, fuse switch accessories Environmental Class Industrial control environment

Specifications Parameter Category Specification Product Type Communication Interface Module (Fieldbus Master) Target PLC System ABB AC500 Programmable Logic Controller Compatible CPU Rack PM5xx series (e.g., PM571, PM581, etc.) Fieldbus Protocol PROFIBUS DP compliant with EN 50170 and IEC 61158 Protocol Version DP-V1 (supports standard cyclic data exchange and acyclic communication for parameterization, diagnostics, and alarms) Master Function Class Class 1 Master (Active Station) Data Transfer Rates Automatically detects and sets from 9.6 kbps up to 12 Mbps Physical Interface 9-pin D-Sub female connector (sub-miniature D), RS-485 standard Maximum Number of Slaves Configurable, typically up to 125 slaves per network segment. Diagnostic Indicators (LEDs) • RUN: Green, indicates module operational status. • COM: Green/yellow/red, indicates communication activity and status. • ERROR: Red, indicates a fault condition. Power Supply Powered directly from the PM5xx CPU rack via the backplane bus (5 VDC). Isolation Galvanic isolation between the PROFIBUS network and the PLC backplane. Configuration Configured using ABB Automation Builder engineering suite. Requires the matching GSD file (Hardware Support Package) for slave devices. Primary Application Integrating the AC500 PLC into factory automation and process control systems using the widespread PROFIBUS DP network for centralized control and data acquisition. Certifications CE, UL, cUL, ATEX (for specific versions/conditions). Please refer to the official manual for exact certification details.
