Technical Parameters Specification Details Product Shunt Closing Release for Circuit Breaker Model / Part Number YC‑1SDA038296R1 Manufacturer ABB Accessory Type Shunt Closing Release (Remote Closing Coil) Intended For Use With SACE Emax and Tmax T series circuit breakers (E1, E2, E3, E4, E6, T8 frames) Control/Coil Voltage (Rated) 24 V AC/DC Voltage Type for Actuating AC and DC Rated Control Supply Voltage (50/60 Hz) 24 V Rated Control Supply Voltage (DC) 24 V Function Provides remote electrical closing of the circuit breaker when energized Mounting / Installation Mounted as an accessory on compatible breaker frames Standards Compliance IEC standard accessory compliance Operating Conditions Industrial environments requiring remote breaker control Typical Applications Remote closing of MCCBs in automation, safety interlock systems, control panels Weight (approx.) ~1 kg Connection Type Screw terminals for control wiring

Technical Parameters Specification Details Product Type Shunt Trip / Shunt Opening Release Model / Part Number YO‑1SDA038286R1 Manufacturer ABB Intended Use With EMax / E‑series / Tmax series circuit breakers Function Electrical remote trip / shunt opening release Control Voltage 24 V DC Operating Current Designed for reliable activation at rated control voltage Rated Coil Voltage 24 V DC (nominal) Frequency DC (no frequency dependency) Actuation Mode Electrical remote release of circuit breaker contacts Mounting Accessory mounted onto compatible breaker frame Compatibility Suitable for various breaker frames including E1, E2, E3, E4, E6, T8 types Standards Compliance IEC and industry electrical accessory standards (typical for breaker accessories) Connection Type Screw / terminal block suitable for control wiring Weight Approx. ~0.7–1 kg depending on assembly type Typical Applications Remote breaker tripping, safety shutdown systems, automation control, interlocks

Technical Parameters Specification Details Product Type 3‑Phase AC Magnetic Contactor Series / Model A185‑30 (e.g., A185‑30‑11‑80) Number of Main Contacts 3 Normally Open (3NO) Auxiliary Contacts 1 Normally Open (1NO) + 1 Normally Closed (1NC) Contactor Type Non‑reversing across‑the‑line contactor Rated Operational Current (AC‑1) ~250–275 A (general switching) Rated Motor (AC‑3) Current ~156 A at 440–480 V AC Rated Operational Voltage (Main Circuit) Up to ~690 V AC Rated Operational Power ~55–132 kW depending on voltage Coil Voltage (Example) 230–240 V AC (for A185‑30‑11‑80 variant) Coil Frequency 50/60 Hz Control Type AC magnetic coil Rated Insulation Voltage (Ui) ~1000 V (IEC) / ~600 V (UL/CSA) Rated Impulse Withstand Voltage (Uimp) ~8 kV Maximum Switching Capacity ~1600–2000 A (short‑circuit break capacity) Connections Screw terminals Mounting Panel / DIN‑rail compatible / snap‑on styles Degree of Protection IP00 (main terminals), IP20 (coil terminals) Operating Temperature Range ~−40 °C to +70 °C Mechanical Durability ~5 million cycles Typical Applications Motor starters, industrial power circuits, HVAC, pumps

Technical Parameters Specification Details Product Type AC Magnetic Contactor Model / Order Code AX25‑30‑10‑80 Series AX Series Number of Poles 3 Main Contact Type Normally Open (NO) Auxiliary Contacts 1 Normally Open (1NO) Rated Operational Current (AC‑3) ~25 A at 220–240 V AC Rated Operational Power (AC‑3) up to ~11 kW @ 380–400 V AC; ~6.5 kW @ 220–240 V AC Rated Operational Current (AC‑1) ~32 A at 690 V AC Rated Operational Voltage (Main Circuit) up to 690 V AC Control/Coil Voltage 220–230 V AC (50 Hz) / 230–240 V AC (60 Hz) Rated Insulation Voltage (Ui) 690 V AC Rated Impulse Withstand Voltage (Uimp) 6 kV Rated Frequency 50/60 Hz Maximum Electrical Switching Frequency AC‑1: 600 cycles/hr; AC‑3: 1200 cycles/hr Maximum Mechanical Switching Frequency ~3600 cycles/hr Operating Ambient Temp. −40 °C to +70 °C (typical) Mounting Panel or DIN‑rail compatible with screw terminals Terminal Type Screw terminals Degree of Protection IP20 for terminals and housing UL/CSA General‑Use Rating ~30 A at 600 V AC

Technical Parameters Specification Details (Typical) Product Type Three‑pole AC Contactor Series / Model A2X38‑30‑10‑22 Number of Main Contacts 3 Normally Open (3NO) Auxiliary Contacts 1 Normally Closed or 1NO+1NC variation (‑10‑22 suffix typically denotes 1NO+1NC) Rated Operational Current (AC‑3) ~38–40 A at 400 V AC (motor control) inferred Rated Operational Current (AC‑1) ~45–50 A at 690 V AC (general load switching) inferred Rated Operational Voltage Up to 690 V AC Control/Coil Voltage Options Depends on variant (e.g., 24 V AC/DC, 48–130 V AC/DC, 100–250 V AC/DC, etc.) Frequency 50/60 Hz Mounting DIN‑rail or panel mount Terminal Type Screw terminals Degree of Protection IP20 (standard for contactors) Standards Compliance IEC/EN 60947 series Typical Applications Motor starters, power switching, industrial automation

Technical Parameters Specification Details Product Type Industrial AC Contactor Model / Order Code AF65‑30‑11‑11 Series AF Series Number of Poles 3 main poles (3-phase) Main Contact Configuration 3 Normally Open (3NO) Auxiliary Contacts 1 Normally Open (1NO) + 1 Normally Closed (1NC) Control / Coil Voltage Range 24–60 V AC or 20–60 V DC (wide-range electronic coil) Rated Operational Current AC‑1 (Ie) ~105 A at 690 V AC Rated Operational Current AC‑3 (Ie) ~65 A at 220–480 V AC Rated Operational Voltage (Main Circuit) Up to 690 V AC Rated Insulation Voltage (Ui) 690 V (IEC); 600 V (UL/CSA) Rated Impulse Withstand Voltage (Uimp) ~6 kV Frequency 50/60 Hz Mechanical Operating Frequency Up to ~3600 cycles/hour Control Frequency Range 50/60 Hz AC / DC control Rated Thermal Current (Ith) ~105 A Typical Motor Ratings (AC‑3) ~25 HP @ 220–240 V; ~50 HP @ 440–480 V; ~60 HP @ 550–600 V Typical Power Ratings ~18.5 kW @ 230 V; ~30 kW @ 380–400 V; ~37 kW @ 415–690 V Standards Compliance IEC/EN 60947‑1; IEC/EN 60947‑4‑1; UL/CSA standards Dimensions (approx.) 67 mm W × 125.5 mm H × 111 mm D Weight ~1.01 kg Mounting DIN-rail or panel mounting with screw terminals Operating Temperature Range −40 °C to +70 °C Typical Applications Motor control, industrial automation, HVAC, pumps, compressors, general load control

Technical Parameters Specification Details Product Type Industrial AC Contactor Series / Model AF96‑30‑00‑13 Number of Poles 3 (three main poles) Contact Configuration 3 Normally Open (3NO) main contacts Control/Coil Voltage 100–250 V AC/DC wide‑range electronic coil Rated Operational Current AC‑1 Up to 130 A at 690 V AC (general switching) Rated Operational Current AC‑3 (Motor) ~96 A at 220–400 V AC (motor load) Rated Operational Voltage (Main Circuit) Up to 690 V AC Rated Operational Power (AC‑3) ~25 kW @ 230 V AC, ~45 kW @ 380–400 V AC, ~55 kW @ 415–690 V AC Rated Insulation Voltage (Ui) 1000 V (IEC) Rated Impulse Withstand Voltage (Uimp) ~8 kV Frequency Rating 50/60 Hz Coil Operating Frequency 50/60 Hz / DC Mounting Type DIN‑rail or panel mounting with screw terminals Degree of Protection Typically IP10/IP20 (depending on installation) Operating Ambient Temp. −60 °C to +80 °C (storage) / −40 °C to +70 °C (operating) Mechanical Switching Frequency Up to ~3600 cycles/hr Electrical Switching Frequency (AC‑3) Up to ~1200 cycles/hr Dimensions (approx.) ~125.5 mm (H) × 70 mm (W) × 116 mm (D) Weight ~1.17 kg Typical Applications Motor control, industrial power switching, automation panels

Technical Parameters Specification Details Product Type Industrial AC Contactor Model / Order Code AF40‑30‑00‑11 Series AF Series Number of Poles 3 (three main poles) Main Contact Configuration 3 Normally Open (3NO) Auxiliary Contacts None (standard) Rated Operational Current AC‑3 40 A (motor/inductive load) Rated Operational Current AC‑1 up to ~70 A (general resistive load) Rated Operational Power (AC‑3) 11 kW @ 220–240 V AC; 18.5 kW @ 380–400 V AC; 22 kW @ 415–690 V AC Rated Operational Voltage (Main Circuit) up to 690 V AC Control / Coil Voltage 24–60 V AC (50/60 Hz) or 20–60 V DC (wide control range) Rated Frequency 50/60 Hz Mounting Type DIN‑rail or panel with screw terminals Terminal Type Screw terminals Operating Temperature Range approx. −40 °C to +70 °C Dimensions (approx.) 125.5 mm H × 55 mm W × 111 mm D Degree of Protection IP10 (main terminals enclosed) Switching Frequency Mechanical up to ~3600 cycles/hour Application Motor control, resistive and lightly inductive load switching

Technical Parameters Specification Details Product AC Contactor (3‑pole) Model / Order Code AF65‑30‑11‑13 Series AF Series Number of Poles 3 (three main contacts) Contact Configuration 3 Normally Open (NO) main contacts Auxiliary Contacts 1 Normally Open (1NO) + 1 Normally Closed (1NC) Rated Operational Voltage (Main Circuit) Up to 690 V AC Rated Operational Current (AC‑3) 65 A at 400 V AC (motor switching) Rated Operational Current (AC‑1) 105 A general switching Control/Coil Voltage Range 100–250 V AC/DC wide‑range electronic coil Frequency 50/60 Hz Rated Insulation Voltage (Ui) Typically 690 V IEC / 600 V UL Built‑in Features Surge suppression, wide voltage acceptance Mounting Type DIN‑rail / panel mounting Terminal Type Screw terminals Operating Temperature Wide industrial range Approx. Switching Power (AC‑3) ~30 kW at 400 V AC Switching Power (AC‑1) ~105 A resistive load Dimensions (typical) ~4.7 × 2.76 × 4.57 in (H × W × D) Enclosure Protection IP10/IP20 depending on orientation Typical Use Cases Motor control, power circuit switching, industrial control systems

Technical Parameters Specification Details Product Type Industrial AC Contactor Series / Model A50‑30 Number of Main Contacts 3 Normally Open (NO) Auxiliary Contacts Optional 1NO + 1NC (on variants like A50‑30‑11) Rated Operational Voltage (Main Circuit) Up to 690 V AC / 1000 V AC depending on application Rated Operational Current AC‑1 ~100 A at 400 V AC Rated Operational Current AC‑3 ~50–55 A at 400 V AC Rated Operational Power (Motor) up to 30 kW (500–690 V AC) / 22 kW (380–400 V AC) Control / Coil Voltage AC coil (e.g., 24 V AC / 110 V AC / 230–240 V AC / 400–415 V AC) Rated Insulation Voltage (Ui) ~1000 V (IEC) / 600 V (UL/CSA) Utilization Category IEC/EN 60947‑4‑1 Main Circuit Terminals Screw terminals Rated Making/Breaking Capacity 10× Ie / 8× Ie (AC‑3) Switching Frequency AC‑1: 600 cycles/hr, AC‑3: 600 cycles/hr Mechanical Switching Frequency 3600 cycles/hr Operating Temperature Range Standard industrial range Standards Compliance IEC/EN 60947 series Typical Applications Motor control, power switching, HVAC, pumps, industrial equipment

Technical Parameters Specification Details Product Type AC Contactor (3‑pole) Series / Model UA63‑30 Number of Main Contacts 3 Normally Open (NO) Auxiliary Contacts None (standard) Rated Operational Voltage (Main Circuit) Up to 690 V AC for power circuit switching Control/Coil Voltage Multiple options, e.g.: 24 V AC, 110 V AC, 220–230 V AC, 500–600 V AC Rated Frequency 50/60 Hz Rated Operational Current AC‑3 ~65 A at 220/230/240 V AC (general motor/inductive load) Rated Operational Current AC‑1 ~115 A at 690 V AC (general resistive load) Rated Insulation Voltage (Ui) ~1000 V (IEC standards) Rated Impulse Withstand Voltage (Uimp) ~8 kV Operating Ambient Temperature Approx. −40 °C to +55 °C (varies by coil option) Mounting DIN‑rail or panel with screw terminals Connection Type Screw terminal for power circuit Utilization Category IEC/EN 60947‑1 / IEC/EN 60947‑4‑1 Application Categories AC‑1 general switching, AC‑3 motor switching Peak Breaking Capacity Up to ~1300 A at 440 V AC Mechanical Durability High cycle life per IEC contactor standards Typical Applications Motor control, capacitor banks, industrial power switching Standards Compliance IEC/EN 60947 series

Technical Parameters Specification Details Product Type Industrial Contactor Series A-Line (A12) Model / Order Code A12-30-22 (1SBL161001R8022) Number of Poles 3 main poles Auxiliary Contacts 2 Normally Open (NO) + 2 Normally Closed (NC) Rated Operational Current ~11 A (general switching) Rated Operational Voltage (Main Circuit) Up to 600 V AC Control / Coil Voltage 120 V AC (standard for this variant) Rated Power (Motor Control) ~3 HP at 240 V AC; ~7.5 HP at 480 V AC; ~10 HP at 600 V AC Phase 3-phase Mounting Panel / DIN rail (application-dependent) Contact Type (Main) AC magnetic contactor Auxiliary Contact Configuration 2NO + 2NC Typical Applications Motor starters, power switching, industrial controls, HVAC systems Standards Compliance IEC/EN 60947-4-1 type performance Weight ~0.34–0.4 kg (depending on variant) Coil Control Frequency 50/60 Hz compatible
