Technical Specifications Parameter Specification Part Number / Model 1SDA067047R1 Product Type Molded Case Circuit Breaker (MCCB) Series / Family Tmax XT2N Trip Mechanism / Release Type Magnetic (MF) Number of Poles 3 (3P) Rated Current (In) 8.5 A Rated Frame Current (Iu) 160 A Adjustment Range of Magnetic Release (Im) 120 A Rated Operational Voltage (Ue) up to 690 V AC / 500 V DC Rated Insulation Voltage (Ui) 1000 V Rated Impulse Withstand Voltage (Uimp) 8 kV Rated Short‑Circuit Breaking Capacity (Icu) 36 kA at 400 V AC Rated Service Short‑Circuit Breaking Capacity (Ics) up to 36 kA Terminal Type Front bolt terminals Connection Capacity Cable/busbar connections (32.5–100 mm²) Mechanical Durability ~25,000 operations Electrical Endurance ~8,000 operations Standards Compliance IEC 60947‑2 Degree of Protection IP20 Weight ~1.2–1.4 kg Dimensions (approx.) Width ~90 mm Typical Applications Protection of three‑phase feeders Short‑circuit and overcurrent protection in industrial panels Power distribution systems in industrial and commercial buildings Motor feeder protection and general circuit protection

Technical Specifications Parameter Specification Part Number / Model 1SDA067045R1 Product Type Molded Case Circuit Breaker (MCCB) Series / Family Tmax XT2N Trip Unit / Release Magnetic (MF) Number of Poles 3 (3P) Rated Frame Current (Iu) 160 A Magnetic Trip Setting (Ii) 28 A Rated Operational Voltage (Ue) 690 V AC / 500 V DC Rated Insulation Voltage (Ui) 1000 V Rated Impulse Withstand Voltage (Uimp) 8 kV Rated Short‑Circuit Breaking Capacity (Icu) 65 kA @ 220–240 V AC; 36 kA @ 380–440 V AC; 10 kA @ 690 V AC Rated Service Breaking Capacity (Ics) Same as Icu Terminal Type Front bolt terminals Terminal Screw Torque ~6 N·m Mounting Fixed installation Standards Compliance IEC 60947‑2 Mechanical Durability ~25,000 operations Electrical Endurance ~8,000 operations

Technical Specifications Parameter Specification Product / Model ABB A26‑30‑10 380‑400V AC Contactor Type Three‑pole AC power contactor Series / Family ABB A26 series contactors (block type) Number of Main Contacts 3 Normally Open (3 NO) Auxiliary Contacts 1 Normally Open (1 NO) built‑in Control Coil Voltage (Uc) 380–400 V AC 50 Hz / 400–415 V AC 60 Hz Rated Operational Voltage – Main Circuit Up to 690 V AC Conventional Free‑Air Thermal Current (Ith) ~45 A (at 40 °C free air) Rated Operational Current (AC‑1) ~45 A (690 V AC, 40 °C) Rated Operational Current (AC‑3) ~26 A at 380–440 V AC (typical) Rated Operational Power (AC‑3) ~11 kW at 380–400 V AC Rated Insulation Voltage (Ui) 1000 V (IEC) Rated Impulse Withstand Voltage (Uimp) 8 kV Rated Breaking/Making Capacity (AC‑3) 8× / 10× Ie Short‑Time Withstand Current (Icw) 210–400 A depending on duration Switching Frequency (Electrical) AC‑1: 600 cycles/h; AC‑3: 1200 cycles/h Mechanical Durability ~10,000,000 operations Terminal Type Screw terminals Mounting Panel / DIN‑rail compatible Degree of Protection IP20 Coil Consumption ~3–12 VA holding, with pull‑in values per IEC Application Motor control, power switching, lighting & general loads

Technical Specifications Parameter Specification Part / Model ABB A12‑30‑01 220‑230 V AC Contactor (e.g., 1SBL161001R8001) Product Type Three‑pole AC power contactor Number of Main Contacts 3 Normally Open (3 NO) Auxiliary Contacts 1 (typically NC or configurable) Control Coil Voltage (Uc) 220‑230 V AC (50 Hz) / 230‑240 V AC (60 Hz) Rated Operational Voltage – Main Circuit Up to 690 V AC Conventional Free‑Air Thermal Current (Ith) ~28 A (IEC 60947‑4‑1) Rated Operational Current AC‑1 (Ie) ~27 A @ 690 V (40 °C) Rated Operational Current AC‑3 (Ie) ~12 A @ 220‑240 V AC Rated Operational Power AC‑3 (Pe) ~3 kW @ 220–240 V AC; ~5.5 kW @ 380–415 V AC Rated Operational Current AC‑15 (Ie) ~4 A @ 220‑240 V AC Rated Insulation Voltage (Ui) 1000 V IEC Rated Impulse Withstand Voltage (Uimp) 8 kV Rated Making / Breaking Capacity AC‑3: 10× / 8× Ie Switching Frequency AC‑1: ~600 cycles/hr; AC‑3: ~1200 cycles/hr Mechanical Durability ~10 million operations Coil Consumption ~8 VA holding; ~70–74 VA pull‑in Connection / Terminals Screw terminals for main and control wiring Mounting DIN‑rail / panel mount capable Standards Compliance IEC 60947‑4‑1, IEC 60947‑5‑1 Ambient Operating Temperature Range Typically −40 °C to +55 °C Typical Weight ~0.34 kg Typical Dimensions (approx.) Width ~44 mm, Height ~74 mm, Depth ~74 mm

Technical Specifications Parameter Specification Part Number / Model ABB 1SDA038676R1 Product Type Molded Case Circuit Breaker (MCCB) Series / Family SACE Isomax S5 Trip Unit Type PR212‑P electronic release with LSI (Long‑Time, Short‑Time, Instantaneous) Number of Poles 3 poles (3P) Rated Current (In) 630 A Protection Functions Overload (L), Short‑Time (S), Instantaneous (I) Rated Operational Voltage (Ue) Up to 690 V AC typical Frame / Housing Fixed MCCB with front terminal connections IEC Utilization Category IEC 60947‑2 compliant Settings / Adjustments Adjustable trip parameters via PR212‑P release Auxiliary / Control Electronic trip unit for coordination and protection Mounting Panel / switchgear fixed installation Application Overload and fault protection in power distribution and industrial circuits Typical Accessories Auxiliary contacts, shunt trip, alarm contact modules (optional)

Technical Specifications Parameter Specification Part Number / Model AX09‑30‑01‑81 / 1SBL901074R8101 Product Type AC Power Contactor Series / Family AX series Control Coil Voltage 24 V AC, 50/60 Hz Number of Poles 3 main poles (3P) Main Contacts 3 Normally Open (NO) Auxiliary Contacts 1 Normally Closed (NC) built‑in Rated Operational Voltage (Main Circuit) Up to 690 V AC Rated Operational Current (AC‑1) ~22 A at 690 V AC Rated Operational Current (AC‑3) ~9 A (typical motor control duty) Rated Operational Power (AC‑3) up to ~4–5.5 kW depending on voltage Rated Insulation Voltage (Ui) 690 V (IEC 60947‑4‑1) Rated Frequency 50 / 60 Hz (main & control circuits) Conventional Free‑Air Thermal Current (Ith) 24 A Maximum Breaking Capacity ~250 A at 440 V AC; ~90 A at 690 V AC Switching Frequency (Electrical) AC‑1: 600 cycles/hour; AC‑3: 1200 cycles/hour Switching Frequency (Mechanical) 3600 cycles/hour Short‑time Withstand Current (Icw) ~100 A for 10 s (cold) Terminal Type Screw terminals Mounting DIN‑rail / panel compatible Operating Temperature Range ~‑40 °C to +70 °C Degree of Protection IP20 Dimensions (approx.) Width ~44 mm × Height ~74 mm × Depth ~74 mm Weight (approx.) ~0.33 kg

Technical Specifications Part Number / Model 1SDA092548R1 Product Type Molded Case Circuit Breaker (MCCB) Series / Family S2N / ABB Circuit Breaker Number of Poles 4 Poles (4P) Rated Current (In) 160 A Model Designation S2N160 R160 4P FFC+RC212V Trip Mechanism Thermal‑magnetic protection Frame / Housing Plastic casing for compact installation Rated Operational Voltage (Ue) Up to typical low‑voltage AC systems (e.g., 230/400 V AC) Application Overload and short‑circuit protection in distribution boards and panels Accessories May include auxiliary contacts or releases such as RC212V Mounting Panel / DIN‑rail compatible depending on enclosure Standards Compliance Designed to meet IEC and relevant low‑voltage circuit breaker standards

Technical Specifications Parameter Specification Part Number / Model 2CDS251001R0634 Product Name Miniature Circuit Breaker — S201‑C63 Series / Family ABB System pro M compact (S200) Configuration Single pole (1P) Tripping Characteristic Type C (general purpose) Rated Current (Iₙ) 63 A Rated Operational Voltage 230/400 V AC (IEC 60898‑1); 230 V AC (IEC 60947‑2) Rated Insulation Voltage (Uᵢ) 440 V Rated Impulse Withstand Voltage (Uᵢₘₚ) 4 kV (air altitude); higher values at sea level Operational Voltage Range 12–253 V AC; 12–72 V DC Rated Short‑Circuit Capacity (Icn) 6 kA (AC) Rated Ultimate Short‑Circuit Breaking Capacity (Icu) 10 kA at 230/400 V AC Rated Service Short‑Circuit Breaking Capacity (Ics) 7.5 kA (230 V AC) Energy Limitation Class Class 3 Overvoltage Category III Pollution Degree 3 Power Loss ~4.8 W per pole Frequency 50/60 Hz Degree of Protection IP20 Operating Ambient Temperature −25 °C to +55 °C Mounting DIN‑rail (TH35) Terminal Type Screw terminals with lifted cylindrical design Endurance Electrical ~10,000 cycles; Mechanical ~20,000 cycles Contact Position Indication Red (ON) / Green (OFF) Standards Compliance IEC/EN 60898‑1; IEC/EN 60947‑2; UL 1077 Accessories Bottom‑fitting auxiliary contacts possible

Technical Specifications Parameter Specification Part / Model AL26‑30‑10 24 V DC Contactor Product Type Power Contactor Series / Family ABB AL Series Coil Voltage (Rated Control Voltage) 24 V DC Main Contacts 3 normally open (3 NO) Auxiliary Contacts 1 normally open (1 NO) Rated Operational Voltage – Main Circuit up to 690 V AC Rated Operational Current AC‑1 (Ie) 45 A (690 V, 40 °C) / 40 A (55 °C) Rated Operational Current AC‑3 (Ie) ~26 A (220–440 V AC) / ~13 A (690 V AC) Rated Operational Power AC‑3 (Pe) up to 15 kW (440–500 V AC) / ~11 kW (380–690 V AC) Rated Making Capacity AC‑3 10 × Ie Rated Breaking Capacity AC‑3 8 × Ie Rated Operational Current DC‑13 (Ie) 6 A / 144 A (24 V DC) Conventional Free‑Air Thermal Current (Ith) 45 A Max Mechanical Switching Frequency ~3600 cycles/hour Max Electrical Switching Frequency AC‑1: ~600 cycles/hour; AC‑3: ~1200 cycles/hour Operate / Release Times Close: ~55 – 110 ms; Open: ~12 – 18 ms Terminal Type Screw terminals Rated Insulation Voltage (Ui) ~1000 V (IEC 60947‑4‑1) Rated Frequency (Main Circuit) 25 – 400 Hz Ambient Operating Temperature –40 °C to +55 °C Mechanical Durability High cycle life per IEC standards Mounting DIN‑rail / panel mounting capable Standards Compliance IEC/EN 60947‑4‑1, IEC/EN 60947‑5‑1 Weight (approx.) ~0.75 kg Dimensions (approx.) Width ~54 mm × Height ~90 mm × Depth ~110 mm

Technical Specifications Parameter Specification Part Number / Model 1SBL323001R8810 ABB Type / Code AL40‑30‑10 DC Contactor Coil Voltage 220 V DC Number of Poles 3 main poles (3 NO) Auxiliary Contacts 1 normally‑open (1 NO) Rated Operational Current – AC‑1 (Ie) 60 A at 690 V AC free‑air thermal current Rated Operational Current – AC‑3 (Ie) 37 A at 415 V AC Rated Operational Power (AC‑3) 18.5 kW at 400 V AC Control Coil Consumption ~3.5 W (low‑consumption DC coil) Rated Insulation Voltage (Ui) 1000 V Rated Short‑time Withstand Current (Icw) 400 A for 10 s Terminal Type Screw terminals Mounting Panel / DIN rail capable (block contactor design) Rated Frequency (Control) DC control Rated Frequency (Main) 25‑400 Hz Ambient Air Temperature –25 °C to +55 °C (operating) Product Class Block contactor per IEC 60947‑4‑1 Weight (approx.) 0.85 kg Product Range ABB AL Contactors

Technical Specifications Parameter Specification Product Manual Motor Starter Model / Part Number MS325‑16 Rated Operational Current (Ie) 16 A Setting Range (Overload Protection) 12.5 – 16 A Number of Poles 3 poles Rated Operational Voltage (Ue) up to 690 V AC and 440 V DC Rated Service Short‑Circuit Breaking Capacity (Ics) 100 kA at 230 V AC, 60 kA at 400 V AC, 40 kA at 440 V AC, 25 kA at 500 V AC, 4 kA at 690 V AC Rated Ultimate Short‑Circuit Breaking Capacity (Icu) Same as Ics Rated Instantaneous Short‑Circuit Current Setting (Ii) 240 A Rated Operational Power AC‑3 ~7.5 kW (400 V AC) Trip Class Class 10A Control / Handle Rotary ON/OFF handle with clear indication Functions Manual switching, overload protection, short‑circuit protection Disconnect Function Built‑in Temperature Compensation Yes Trip‑Free Mechanism Yes Poles in Series for Single‑Phase 3 poles can be used in series Auxiliary / Accessory Options Auxiliary contacts, signalling contacts, undervoltage release, shunt trip (optional) Enclosure Protection IP20 Operating Temperature Range –25 °C to +50 °C (typical) Mechanical Durability High cycle life (thousands of operations) Dimension (approx.) Width: 54 mm, Height: 87.5 mm, Depth: 75.5 mm Standards Compliance IEC/EN 60947‑4‑1 / IEC/EN 60947‑1 series

Technical Specification Parameter Specification Part / Model ABB XT1N160 TMD80‑800 FF 3P Product Type Molded Case Circuit Breaker (MCCB) Series / Family ABB Tmax XT Number of Poles 3‑pole (3P) Trip Unit Type Thermal‑magnetic (TMD), adjustable (80–800 A) Rated Current (I_n) 80 A Rated Uninterrupted Current (I_u) 160 A Operational Voltage (U_e) 690 V AC / 500 V DC Rated Insulation Voltage (U_i) 800 V Rated Impulse Withstand Voltage (U_imp) 8 kV Rated Ultimate Short‑Circuit Breaking Capacity (I_cu) up to 65 kA (at lower AC voltages) Rated Service Short‑Circuit Breaking Capacity (I_cs) up to 50 kA (at lower AC voltages) Rated Instantaneous Short‑Circuit Setting (I_i) 800 A Frequency 50/60 Hz Mounting Type Fixed installation (front terminals) Terminal Connection Front bolt connections Mechanical Durability ~25,000 operations Electrical Durability ~8,000 operations Power Loss per Pole ~4.8 W Standards Compliance IEC 60947‑2 Typical Use Power distribution protection in industrial/commercial installations
