Technical Parameters Parameter Specification Product type Molded Case Circuit Breaker (MCCB) Product series ABB SACE Tmax T2H ABB Ordering Code 1SDA051041R1 Poles 3 poles Terminal type Front fixed terminals Trip unit type TMD (Thermal‑magnetic) Current setting range 32–500 A Rated uninterrupted current (Iu) 160 A frame rating Rated operational voltage (Ue) 690 V AC / 500 V DC Rated insulation voltage (Ui) 800 V Rated impulse withstand voltage (Uimp) 8 kV Breaking capacity – service (Ics) 100 kA @ 220–230 V AC / 70 kA @ 380–415 V AC / 55 kA @ 440 V AC / 36 kA @ 500 V AC / 8 kA @ 690 V AC Ultimate breaking capacity (Icu) Same as service values depending on voltage Protection functions Overload and short‑circuit protection Standards compliance IEC 60947‑2 Mechanical durability ~25,000 operations Electrical durability ~8,000 operations at rated conditions Power loss per pole ~2.7 W at rated load Mounting Panel fixed installation Typical applications Industrial and commercial power distribution protection

Technical Parameters Parameter Specification Product type Molded Case Circuit Breaker (MCCB) Product series ABB SACE Tmax T2S160 Poles 3 poles Trip unit type Thermal‑magnetic (TMD) adjustable Current setting range 63–630 A (adjustable) Terminal type Front fixed (FF) Rated operational voltage (Ue) Up to 690 V AC Rated insulation voltage 800–1000 V class (system dependent) Rated impulse withstand ~8 kV Breaking capacity Typical 50 kA @ 400/415 V AC (varies by variant) Protection functions Overload protection, short‑circuit protection Standards compliance IEC 60947‑2 compatible Mounting Panel fixed installation Mechanical durability Industrial grade Typical applications Power distribution protection, industrial switchgear

Technical Parameters (English) Parameter Specification Product type Molded Case Circuit Breaker (MCCB) Product series ABB SACE Isomax S3N ABB Ordering Code 1SDA013356R1 Poles 3 poles Terminal type Front fixed (FF) Trip unit Thermal‑magnetic Frame size S3N 160 Rated current (In) 160 A (frame rating) Adjustable overcurrent release R160 (thermomagnetic protection range) Rated operational voltage (Ue) Up to 690 V AC (typical low‑voltage rating) Protection functions Overload and short‑circuit protection Standards IEC 60947‑2 compliant Typical applications Industrial power distribution, feeder and branch circuit protection

Technical Parameters Parameter Specification Product type Molded Case Circuit Breaker (MCCB) Product series ABB SACE Tmax T3N Poles 3 poles ABB Ordering Code 1SDA051246R1 Rated current (In) 200 A Trip unit Thermal‑magnetic Rated operational voltage Up to 690 V AC Rated insulation voltage (Ui) 800 V AC Rated impulse withstand voltage (Uimp) 8 kV Breaking capacity 36 kA (typical @ IEC ratings) Installation Fixed (panel) mounting Terminals Front fixed terminals Protection functions Overload and short‑circuit protection Standards IEC 60947‑2 compliant Ambient operating temperature Standard industrial range Typical applications Power distribution, feeder protection, switchgear

Technical Parameters Parameter Specification Product type Molded Case Circuit Breaker (MCCB) Product series ABB SACE Tmax T6 Poles 4 poles (4P) Rated current (In) 800 A Trip unit type TMA (thermal‑magnetic) Short circuit release range 4000–8000 A (undelayed) Rated operational voltage (Ue) Up to 690 V AC / 750 V DC Rated insulation voltage (Ui) 1000 V Rated impulse withstand voltage (Uimp) 8 kV Breaking capacity (Ics / Icu) Examples: 70 kA @230 V AC, 36 kA @380–415 V AC (varies by system voltage) Mechanical durability ~20,000 cycles Electrical durability ~5000 cycles at rated load Mounting Panel / fixed installation with front terminals Control type Manual toggle Protection functions Overload and short‑circuit protection Ambient operating temperature Typical industrial range Degree of protection IP20 (with appropriate enclosure) Standards IEC/EN compliant for low‑voltage circuit breakers

Technical Parameters Parameter Specification Product type Molded case circuit breaker (MCCB) Product series ABB SACE ISOMAX S6 N Poles 3 poles Rated current (In) 800 A Rated operational voltage (Ue) 690 V AC Breaking capacity (Icu / Ics) Up to 100 kA (AC-1/AC-3, depending on variant) Tripping unit Thermal-magnetic, adjustable Short-circuit protection Yes Overload protection Yes Control type Manual / optional motorized operation Mechanical durability High (industrial grade) Electrical durability High (industrial grade) Mounting Panel or frame mounting Ambient operating temperature −25 °C to +60 °C Protection degree IP40–IP42 (depending on installation) Standards IEC 60947-2 compliant Typical applications Industrial power distribution, medium-voltage switchgear, commercial electrical installations

Technical Parameters Parameter Specification Product type Electromechanical contactor Product series ABB A series Poles 3 poles Main contact configuration 3 NO (Normally Open) Built-in auxiliary contacts 1 NO + 1 NC Rated operational voltage (Ue) Up to 690 V AC Rated operational current (Ie, AC-1) 260 A Rated motor power (AC-3) Up to 160 kW at 400 V Coil voltage 220 V AC Control voltage frequency 50 / 60 Hz Mechanical durability Up to 10 million operations Electrical durability Depends on load and utilization category Ambient operating temperature −25 °C to +60 °C Mounting Panel or DIN rail mounting Protection degree IP00 (IP20 with accessories) Applicable standards IEC / EN compliant Typical applications Motor starters, industrial control panels, automation systems

Technical Parameters Parameter Specification Product type Electromechanical contactor Product series ABB A series ABB Ordering Code 1SFL491001R8022 Poles 3 poles Main contact configuration 3 NO (Normally Open) Built-in auxiliary contacts 2 NO + 2 NC Rated operational voltage (Ue) Up to 690 V AC Rated operational current (Ie, AC-1) 185 A Rated motor power (AC-3) Up to 110 kW at 400 V Coil voltage 110–240 V AC / DC (variant dependent) Control voltage frequency 50 / 60 Hz Mechanical durability Up to 5 million operations Electrical durability Depends on load and utilization category Ambient operating temperature −25 °C to +60 °C Mounting Panel or DIN rail mounting Protection degree IP00 (IP20 with accessories) Applicable standards IEC / EN compliant Typical applications Motor starters, industrial control panels, automation systems

Technical Parameters Parameter Specification Product type Electromechanical contactor Product series ABB A series ABB Ordering Code 1SFL531001R8011 Poles 3 poles Main contact configuration 3 NO (Normally Open) Built-in auxiliary contacts 1 NO + 1 NC Rated operational voltage (Ue) Up to 690 V AC Rated operational current (Ie, AC-1) 260 A Rated motor power (AC-3) Up to 160 kW at 400 V Coil voltage 110–240 V AC / DC (variant dependent) Control voltage frequency 50 / 60 Hz Mechanical durability Up to 10 million operations Electrical durability Depends on load and utilization category Ambient operating temperature −25 °C to +60 °C Mounting Panel or DIN rail mounting Protection degree IP00 (IP20 with accessories) Applicable standards IEC / EN compliant Typical applications Motor starters, industrial control panels, automation systems

Technical Parameters Parameter Specification Product type Electromechanical contactor Product series ABB AF series Poles 3 poles Main contact configuration 3 NO (Normally Open) Built-in auxiliary contacts 1 NO + 1 NC Rated operational voltage (Ue) Up to 690 V AC Rated operational current (Ie, AC-1) 52 A Rated motor power (AC-3) Up to 30 kW at 400 V Coil voltage 110–240 V AC / DC (variant dependent) Control voltage frequency 50 / 60 Hz Mechanical durability Up to 5 million operations Electrical durability Depends on load and utilization category Ambient operating temperature −25 °C to +55 °C Mounting Panel or DIN rail mounting Protection degree IP00 (IP20 with accessories) Applicable standards IEC / EN compliant Typical applications Motor starters, industrial control panels, automation systems

Technical Parameters Parameter Specification Product type Electromechanical contactor Product series ABB AX series Poles 3 poles Main contact configuration 3 NO (Normally Open) Built-in auxiliary contacts 1 NO + 1 NC Rated operational voltage (Ue) Up to 690 V AC Rated operational current (Ie, AC-1) 32 A Rated motor power (AC-3) Up to 15 kW at 400 V Coil voltage 110–240 V AC / DC (variant dependent) Control voltage frequency 50 / 60 Hz Mechanical durability Up to 5 million operations Electrical durability Depends on load and utilization category Ambient operating temperature −25 °C to +55 °C Mounting Panel or DIN rail mounting Protection degree IP00 (IP20 with accessories) Applicable standards IEC / EN compliant Typical applications Motor starters, industrial control panels, automation systems

Technical Parameters Parameter Specification Product type Industrial contactor Product series ABB GAF series Poles 3 poles Main contact configuration 3 NO (Normally Open) Built-in auxiliary contacts 1 NO + 1 NC Rated operational voltage (Ue) Up to 690 V AC Rated operational current (Ie, AC-1) 300 A Rated motor power (AC-3) Up to 160 kW at 400 V Coil voltage 110–240 V AC / DC (variant dependent) Control voltage frequency 50 / 60 Hz Mechanical durability Up to 10 million operations Electrical durability Depends on load and utilization category Ambient operating temperature −25 °C to +60 °C Mounting Panel or DIN rail mounting Protection degree IP00 (IP20 with accessories) Applicable standards IEC / EN compliant Typical applications Motor starters, industrial control panels, high-power motor switching
