Module Type:IGBT

Model Number:BGAD-02C

Rated Current (A):200

Operating Voltage (V):600

Switching Frequency (kHz):25

Thermal Resistance (°C/W):1.5

Cooling Method:Active Cooling

Package Size (mm):220 x 150 x 80

Weight (kg):1.5

    The ABB BGAD-02C IGBT module is engineered to deliver unparalleled performance in industrial control systems. Its robust design ensures reliability and longevity, making it suitable for applications across various industries including manufacturing, energy, and automation.

    Featuring a high switching frequency, this module optimizes energy usage and reduces heat generation, enhancing overall system efficiency. The active cooling system further ensures stable operation under demanding conditions.

    With a rated current of 200A and an operating voltage of 600V, the BGAD-02C is capable of handling a wide range of power requirements. Its thermal resistance of 1.5°C/W facilitates effective heat dissipation, prolonging the lifespan of the module.

    The compact package size and lightweight design of the BGAD-02C make it easy to integrate into existing systems without compromising on performance. This modular design also simplifies maintenance and replacement processes.

    ABB’s BGAD-02C IGBT module is backed by extensive research and development, ensuring compatibility with leading industrial control systems. It is a testament to ABB’s commitment to delivering cutting-edge technology solutions that drive operational excellence.
