Operating Voltage Range:24VDC ± 10%

Motor Speed Monitoring:Voltage measurement across 1 TB-1 to 1 TB-3 terminals

Adjustable PI-Tach Scale:Up to 50% of motor speed

Terminal Connections:Three-screw terminal strip for easy wiring

Jumpers and Potentiometers:Over 20 jumpers and seven potentiometers for configuration flexibility

Capacitors Count:118 capacitors for stable power supply

Button Controls:7-button panel for operational adjustments

Metal Terminals:Four metal male terminals for robust connection

Diodes:22 diodes for enhanced signal processing

    The GE F31X134EPRBEG1 is engineered for industrial strength and reliability, providing a robust solution for complex control scenarios.

    Featuring a compact yet powerful design, this encoder process board is equipped with a variety of components including capacitors, resistors, potentiometers, and buttons for intuitive control and customization.

    With its three-screw terminal strip, users can easily monitor and fine-tune motor speeds using a voltmeter or adjust the PI-tach scale for optimal performance at 50% of the motor speed.

    Comprised of a durable structure with a light green tower and three flat-head screws, this board ensures secure mounting and easy access to all its critical components.

    Designed for compatibility with a wide range of industrial drive systems, including the DC-300 drive, the F31X134EPRBEG1 supports diverse applications across various industries, enhancing operational efficiency and precision.
