Operating Voltage Range:24…240 V AC / 19…60 V DC

Output Type:Discrete

Output Count:8 Channels

Power Dissipation:(0.25 W + 0.24 W x No of Outputs at State 1)

Electrical Connection:Screw Terminal

Current Consumption:55 mA @ 5 V DC, 80 mA @ 24 V DC

Rack Product Weight:0.93 lb (US) / 0.42 kg

Compliance Standards:Conforms to EN/IEC 61131-2

    Introducing the Schneider TSX08H04MFD – a cutting-edge digital input module designed to meet the stringent demands of industrial automation environments. This module is equipped with advanced technology and robust construction, ensuring reliable performance in even the most challenging conditions.

    Featuring an operating voltage range from 12 to 24VDC, the TSX08H04MFD is capable of handling a variety of power sources, making it versatile for different industrial settings. Each channel can accommodate a maximum input current of 5mA, providing precise signal detection.

    With 8 inputs, this module offers ample connectivity options for integrating various sensors and actuators, enabling comprehensive monitoring and control of your automation processes. Its fast switching time of typical 5ms ensures that you receive real-time information without any delay.

    The module is designed to withstand environmental extremes, operating effectively within a temperature range of -20°C to +55°C. Its IP20 protection class safeguards against dust ingress, enhancing its durability and reliability in industrial environments.

    Compact and lightweight, measuring 75mm x 122mm x 90mm and weighing just 0.3kg, the Schneider TSX08H04MFD is easy to install and integrate into existing systems. It also supports communication through Modbus TCP/IP, seamlessly connecting to various industrial networks and software platforms.
