Manufacturer:A-B (Allen Bradley)

Model:1770-XYB

Module Type:Digital Input Module

Channels:16 Channels

Voltage Range:10-30 VDC

Current Rating:10 mA per Channel

Operating Temperature:-25°C to +70°C

Humidity Range:5% to 95%, Non-Condensing

Power Requirements:24 VDC

Dimensions:Width: 1.625 inches, Height: 4.25 inches, Depth: 4.375 inches

Weight:Approximately 0.5 lbs

Communication Protocol:RS-232/RS-485

Certifications:CE, UL, RoHS Compliant

    The Allen-Bradley 1770-XYB Digital Input Module is engineered for seamless integration into industrial automation environments. It offers robust performance with reliable digital signal processing capabilities.

    This module supports up to 16 channels of digital inputs, making it ideal for applications requiring multiple data points. Each channel supports an input voltage range of DC 12-48V, ensuring compatibility with a wide range of sensors and devices.

    With a compact design measuring 178mm x 90mm x 60mm, the 1770-XYB module fits easily into existing control panels and machinery without taking up excessive space. Its lightweight construction, weighing approximately 0.5 kg, makes installation quick and easy.

    Designed for harsh industrial environments, the module operates reliably within a temperature range of -20°C to +70°C, making it suitable for use in various settings, from manufacturing floors to outdoor installations.

    The Allen-Bradley 1770-XYB module supports standard communication protocols such as RS-232 and RS-485, enabling seamless integration with existing control systems and networks. Its durable build ensures long-term reliability and minimal downtime.
