Module Type:Analog Input/Output

Connector Type:16-pin

Power Consumption:Max 50mA @ 24VDC

Operating Temperature Range:-25°C to +60°C

Communication Interface:Profibus DP

Input Voltage Range:0 to 24V DC

Output Current Range:0 to 20mA

Number of Channels:8 Input, 8 Output

Dimensions:96 x 96 x 116 mm

Weight:0.3 kg

    Experience unparalleled precision and reliability with the ABB AX561 Analogue I/O Module. Engineered to meet the demands of modern industrial automation, this module ensures accurate and efficient data exchange in a variety of operational environments.

    Featuring a modular design for easy installation and configuration, the AX561 is compatible with leading communication protocols such as Profinet and DeviceNet, enhancing its interoperability across diverse systems.

    Operate within extreme temperature ranges (-25°C to +70°C) without compromising performance, thanks to its robust design. This makes it ideal for applications in harsh industrial conditions.

    With support for 8x Analog Input and 8x Analog Output channels, the AX561 offers versatile connectivity options, catering to a wide range of monitoring and control requirements. Its low power consumption ensures energy efficiency, reducing overall system costs.

    Equipped with an IP20 enclosure rating, the module provides basic protection against dust and splashing water, making it suitable for a broad spectrum of industrial settings. The compact size (72 x 72 x 35mm) and lightweight design (0.1kg) facilitate easy installation and integration.
