Dimension:15.2 x 10.2 x 25.4 cm

Weight:1.4 kg

Number of Channels:8

Bit Depth:12-bit

Signal Range:Voltage: 0-5 VDC, Current: 4-20 mA

Isolation Rating:50V

Operating Temperature:-20°C to +70°C

Power Consumption:Max 10W

    The ABB YPG109BV 3ASD489306C505 Analog Input Board is engineered to meet the demanding requirements of modern industrial environments. Its high-resolution, microprocessor-based system ensures precise data acquisition from various analog sources, enhancing system reliability and performance.

    Featuring 16 input channels capable of handling both voltage and current signals, this board offers flexibility and versatility in integration with diverse industrial equipment. With a sampling rate of 1 kHz, it captures rapid changes in signal values, crucial for applications requiring high-speed data processing.

    Accurate within ±0.05%, the board’s measurement precision is unparalleled, making it ideal for applications where absolute accuracy is paramount. Designed to operate within a wide temperature range (-20°C to +60°C), it ensures reliable operation in harsh industrial conditions.

    The compact size (140mm x 80mm x 25mm) and low power consumption (10W) make it an efficient choice for space-constrained installations without compromising on performance. Its RS-485 communication interface facilitates seamless integration with existing industrial networks, enabling real-time data exchange and control.

    Equipped with 4 relay outputs, the board supports various control functions, from simple alarm notifications to complex process control scenarios. Its CE and UL safety certifications guarantee compliance with international safety standards, ensuring a safe working environment for operators.
