Power Supply Voltage:12 VDC

Frequency Range:0 to 1 kHz

Output Type:Square Wave

Load Capacity:Up to 100mA

Operating Temperature:-20°C to +85°C

Reliability Rating:MTBF > 50,000 hours

Communication Interface:RS-232C

Dimensions:76mm x 44mm x 19mm

Weight:0.15 kg

    Engineered for precision and reliability, the Honeywell W-357-1MPD Electronics Pulse module is designed to meet the stringent demands of modern industrial automation systems. It seamlessly integrates into various control systems to provide accurate and responsive pulse generation.

    This module boasts an operating frequency range from 1 kHz to 500 kHz, allowing it to adapt to a wide variety of applications across different industries. Its adjustable pulse width ranging from 1 μs to 250 ms ensures compatibility with most pulse-based control mechanisms.

    Featuring a maximum pulse current of 20 mA per channel, this module delivers robust performance without compromising on energy efficiency. The supply voltage range of 5 VDC to 24 VDC provides flexibility, accommodating different power sources commonly found in industrial settings.

    With an accuracy of +/- 0.5% at 10 kHz, the Honeywell W-357-1MPD module ensures precise timing and synchronization in critical control processes. Its operation is further enhanced by its temperature range of -40°C to +85°C, ensuring reliable performance in both cold and hot environments.

    Designed with ease of integration in mind, the module features an open collector output, facilitating seamless connection with other electronic components. This makes it a versatile choice for a broad spectrum of industrial control applications, including machinery, robotics, and process control systems.
