Brand:ABB

Model:DSQC541

Sub-Model:Back Plane

Module Category:Control

Operating Voltage Range:10 to 30 V DC

Communication Protocol:EtherCAT

Number of I/O Channels:8 Digital Inputs + 4 Digital Outputs

Dimensions (WxHxD):84 x 37 x 80 mm

Weight:0.2 kg

Environmental Conditions:Operating Temperature: -25°C to 60°C, Storage Temperature: -40°C to 85°C

Certifications:CE, UL, CSA, EN61131-2

    The ABB DSQC541 Back Plane is engineered to deliver exceptional performance and reliability in industrial automation environments. This compact back plane supports up to 32 I/O channels, making it ideal for applications requiring precise control and data acquisition.

    Featuring a robust metal construction, the DSQC541 is built to withstand harsh industrial conditions, ensuring long-term operational stability. Its low power consumption ensures efficient energy use without compromising on functionality.

    Integrated with EtherCAT, a leading real-time Ethernet protocol, this back plane facilitates fast and reliable communication between control systems and peripheral devices, enhancing overall system responsiveness and efficiency.

    Operable within a wide temperature range from -20°C to +70°C, the DSQC541 is suitable for a variety of industrial settings, from cold storage facilities to hot manufacturing plants. This versatility makes it a preferred choice across diverse industries.

    With its dual I/O configuration, the DSQC541 offers both differential and single-ended inputs and outputs, providing flexibility for connecting a wide range of sensors and actuators. This feature enables users to tailor the module to their specific application needs, ensuring optimal performance and ease of integration.
