Key Features & Benefits Precision Motion Control Controls up to 6 robot axes simultaneously 1μs servo update rate Advanced vibration suppression technology Enhanced Reliability 50,000+ hour MTBF rating Redundant processor architecture Built-in self-diagnostics Industrial Durability 0-55°C operating temperature Vibration resistant (5-500Hz, 5g) Conformal coated PCB Seamless Integration Plug-and-play with IRC5 controller Auto-configuration with RobotStudio LED status indicators Technical Specifications Parameter Specification Processor Dual-core 800MHz Axis Control 6 axes Communication SERCOS III interface Power Consumption 25W max Certifications CE, UL, ISO 10218-1 Typical Applications ✔ Automotive assembly lines ✔ Foundry material handling ✔ Machine tending ✔ Arc welding systems ✔ Painting automation

168

ABB

Key Features & Benefits Advanced Motion Control 25A continuous current output <1ms dynamic response time Adaptive vibration suppression Enhanced Reliability Dual-channel safety monitoring Overcurrent/overvoltage protection 60,000 hour MTBF rating Industrial Durability 0-55°C operating temperature IP20 protection (controller mounted) Conformal coated electronics Smart Diagnostics Real-time current monitoring Predictive maintenance alerts LED status indicators Technical Specifications Parameter Specification Output Current 25A continuous/50A peak Input Voltage 400-480V AC 3-phase Communication SERCOS III interface Protection STO, SS1, SS2 safety functions Certifications CE, UL, ISO 10218-1 Typical Applications ✔ Automotive spot welding ✔ Material handling systems ✔ Machine tending robots ✔ Foundry automation ✔ Painting robots

90

ABB

Key Features & Benefits Precision Power Conversion Input: 230V AC (180-264V range) Output: 24V DC @ 6A (144W) 92% typical efficiency Industrial Durability -25°C to +70°C operating temperature 100% full load burn-in tested 150% power reserve for peak loads Advanced Protection Short-circuit/overload protection Overvoltage shutdown Automatic recovery Easy Integration Compact DIN-rail mounting LED power status indicator Plug-and-play installation Technical Specifications Parameter Specification Input Voltage 230V AC (180-264V) Output Voltage 24V DC (±1%) Output Current 6A continuous Ripple & Noise <100mV p-p Certifications CE, UL, EN 60950 Typical Applications ✔ PLC control cabinets ✔ Industrial robot controllers ✔ Process instrumentation ✔ Motor control centers ✔ Conveyor systems

868

ABB

Key Features & Benefits Precision Voltage Control Input: 3-phase 400V AC (50/60Hz) Output: 0-400V AC continuously adjustable 1% output voltage regulation Industrial-Grade Construction 30A continuous current rating IP54 protection rating Forced air cooling system Reliable Performance 50,000+ mechanical cycles lifespan Overload protected design Low maintenance requirements Versatile Mounting Panel or floor mounting options 360° continuous rotation Dual scale dial indicator Technical Specifications Parameter Specification Input Voltage 3-phase 400V AC ±10% Output Range 0-400V AC Current Rating 30A continuous Frequency 50/60Hz Insulation Class Class B Certifications CE, UL, IEC 61558 Typical Applications ✔ Industrial heating control ✔ Motor speed regulation ✔ Test bench power supplies ✔ Process oven temperature control ✔ Lighting load testing

585

ABB

Key Features: Function: Analog output module (typically 4-20 mA or 0-10 V signals). Channels: Usually provides multiple output channels (exact number depends on configuration). Isolation: Electrical isolation between channels to prevent interference. Accuracy: High precision with low drift for reliable process control. Communication: Interfaces with ABB’s control systems via a fieldbus or backplane connection. Diagnostics: Supports module health monitoring and fault detection. Mounting: Designed for DIN rail or panel mounting in industrial environments.

798

ABB

Key Features: Input Voltage: Typically 24V DC (range may vary, e.g., 19.2–30V DC). Output Power: Supplies 5V DC and 24V DC for the controller and connected I/O modules. Redundancy Support: Can be used in redundant configurations for high-availability systems. Protection Features: Overvoltage, undervoltage, short-circuit, and overtemperature protection. Hot-Swappable: Allows replacement without shutting down the entire system (in supported configurations). Status Indicators: LED indicators for power status, faults, and redundancy mode. Mounting: Designed for installation in the AC 800M rack or cabinet.

987

ABB

Key Features: Modular Design: Supports expandable I/O modules for customization. Processor Performance: Efficient processing for real-time control tasks. Communication Interfaces: Built-in RS-232/RS-485 ports. Supports Ethernet (TCP/IP), PROFIBUS DP, and Modbus RTU for seamless integration. Optional PROFINET, CANopen, or DeviceNet via add-on modules. Programming & Configuration: Programmable using ABB Automation Builder (IEC 61131-3 standard: LD, FBD, ST, SFC, IL). Supports CODESYS-based development. Memory & Storage: Flash memory for program storage. Removable SD card for data logging and backup. Robust Construction: Industrial-grade durability (-20°C to +60°C operating temperature). DIN rail or panel mounting. Integrated Web Server: Allows remote monitoring and diagnostics via a web browser.

242

ABB

Key Features: Rated Current: 18A (suitable for medium-power motor loads). Voltage Rating: 230V AC (typical for industrial control circuits). Protection Functions: Overload protection (adjustable trip settings). Short-circuit protection (magnetic or thermal trip). Phase-loss protection (optional, depending on model). Control Logic: Built-in electromechanical relay for switching. Manual reset or auto-reset options after tripping. Status Indication: LED indicators for power, fault, and relay status. Mounting & Wiring: DIN rail-mounted for easy installation. Screw terminals for secure connections. Compliance & Safety: Meets IEC/EN 60947-4-1 standards for motor starters. UL & CE certified for global use.

904

ABB

Key Features: ✔ Energy Savings: Built-in ABB’s Energy Optimizer reduces motor energy consumption. Automatic motor adaptation (AMA) for optimal efficiency. ✔ Motor Protection & Safety: Overload, overvoltage, undervoltage, short-circuit, and ground fault protection. Thermal motor protection (PTC input for motor temp monitoring). ✔ User-Friendly Interface: Built-in keypad for easy parameter setting. LED display for real-time monitoring (speed, current, fault codes). Optional control panel (ACP10 or ACP7). ✔ Flexible Control Options: Analog (0-10V, 4-20mA), digital (24V DC), and relay I/O. Modbus RTU (RS485) & BACnet MS/TP for building automation. Optional fieldbus cards (Profibus, CANopen, Ethernet/IP). ✔ Application-Specific Features: Pump & Fan Control: Built-in PID controller for flow/pressure regulation. Industrial Automation: Multi-motor control, flying start, and brake chopper support.

471

ABB

Key Specifications: Model: ACS510-01-290A-4 Rated Power: 160kW (215HP) Output Current: 290A Input Voltage: 3-phase 380-480V AC ±10% Frequency Range: 50/60Hz ±5% Output Frequency Range: 0-500Hz Control Methods: Scalar control (V/f) Sensorless vector control Efficiency: >97.5% Protection Class: IP21 (standard) Advanced Features: Energy Optimization: Automatic Energy Optimization (AEO) function Sleep mode for pump applications Motor Protection: Built-in motor thermal protection Short circuit, ground fault and overload protection Under/over voltage protection Control Options: Built-in PID controller Flying start and DC braking Torque boost capability Communication Protocols: Standard RS485 interface Modbus RTU protocol Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen)

543

ABB

Key Specifications Parameter Specification Model ACS550-01-180A-4 Rated Power 90 kW (120 HP) Output Current 180 A Input Voltage 3-phase, 380-480V AC (±10%), 50/60 Hz Output Voltage 0-480V AC (matches input) Frequency Range 0-500 Hz Control Method Scalar (V/f) & Sensorless Vector Control (SVC) Overload Capacity 150% for 60 sec, 200% for 3 sec Efficiency >98% Protection Class IP21 (open chassis) 3. Key Features ✔ Motor Control & Performance Sensorless Vector Control (SVC) for improved torque & speed accuracy Automatic Motor Adaptation (AMA) for optimal motor tuning Flying Start – can restart a spinning motor without stopping Torque Boost for high-starting torque applications ✔ Energy Saving & Optimization ABB Energy Optimizer reduces motor energy consumption by up to 30% Sleep Mode for pump & fan applications (reduces idle power waste) Brake Chopper support (for dynamic braking) ✔ Protection & Safety Short-circuit, overload, overvoltage, and ground fault protection Motor Thermal Protection (PTC input) Safe Torque Off (STO) option (safety compliance) ✔ User Interface & Programming Built-in keypad (LCD display) Quick Setup Macro (pre-configured for pumps, fans, conveyors) CopyCat function (easy parameter transfer between drives) ✔ Communication & Connectivity Standard RS485 (Modbus RTU) Optional fieldbus cards (Profibus DP, DeviceNet, CANopen, Ethernet/IP) BACnet MS/TP for HVAC applications

720

ABB

Key Technical Specifications Model Number: ACS510-01-290A-4 Rated Power: 160kW (215HP) Output Current: 290A Input Voltage: 3-phase 380-480V AC ±10% Frequency Range: 50/60Hz ±5% Output Frequency: 0-500Hz Control Methods: Scalar control (V/f) Sensorless vector control Overload Capacity: 150% for 60 seconds Efficiency: >97.5% Protection Class: IP21 (standard) 3. Advanced Features Energy Saving Functions: Automatic Energy Optimizer (AEO) Sleep mode for pump applications Adaptive programming for optimal efficiency Motor Protection: Built-in motor thermal protection Short circuit protection (I²t) Ground fault monitoring Under/over voltage protection Control Capabilities: Built-in PID controller Flying start function Torque boost (0-30%) DC braking 4. Communication & Connectivity Standard RS485 interface Modbus RTU protocol support Optional fieldbus adapters available: Profibus DP DeviceNet CANopen 5. Physical Characteristics Dimensions: 482 × 350 × 262 mm (W×H×D) Weight: Approximately 45kg Cooling Method: Forced air cooling Ambient Temperature Range: -15°C to +50°C Relative Humidity: <95% non-condensing Installation: DIN rail or panel mounting7. Certifications & Compliance CE marked UL listed cULus certified Complies with EN/IEC 61800-3 RoHS compliant 8. Ordering Information Complete model designation: ACS510-01-290A-4 Standard delivery includes: Drive unit Installation guide Basic control cables Optional accessories: External EMC filter Braking resistor unit Fieldbus communication modules Remote control panel
