Parameter Specification Product Line Eaton Zero-Xposure Model Number ZX-FW-LPB Description Fusible Safety Disconnect Switch, Large Push Button, 30HP/60A Rated Horsepower (HP) 30 HP @ 240V AC / 50 HP @ 480V AC / 60 HP @ 600V AC Rated Amperage (A) 60 A Rated Voltage (V AC) 240V / 480V / 600V Type Fusible Disconnect Switch Actuation Large, Yellow Push Button (Turns to OFF position) Safety Standard Complies with OSHA Lockout/Tagout requirements and relevant UL/CSA standards. Locking Capability Yes, accepts multiple safety locks (up to 3 or 6, depending on the specific model variant). Fuse Type Accepts standard Class R, J, or T fuses (not included). Enclosure Rating Typically NEMA 1, 3R, 4, 4X, 12 (depending on the specific enclosure ordered). Application Used as a main or branch circuit safety disconnect for industrial machinery, motors, and control panels to ensure safe maintenance.

Parameter Specification Product Series Eaton EIT (Industrial Indicators) Model Number EIT30Y-15BO1B Description 30mm Panel Indicator Light, Yellow, Incandescent, 24V Lens Color Yellow (Y) Mounting Hole Size 30 mm Light Source Incandescent Bulb (pre-installed) Rated Voltage 24V AC/DC Bulb Power Typically ~1.5W to 3W (e.g., 24V, 1.7W) Bulb Life Shorter than LED (typically several thousand hours) Terminals Screw terminals or quick-connect, at the rear Mounting Panel mount, secured with a supplied bayonet ring Material Thermoplastic lens and body Agency Approvals UL, CSA, CE

Parameter Specification Product Series Eaton IZM Model Number IZM65B3-EGC06WH Description Molded Case Circuit Breaker, 63A, 3-Pole, Electronic Trip, Fixed Mount Frame Size IZM65 Rated Current (In) 63 A (Fixed) Number of Poles 3 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 690V AC Rated Ultimate Short-Circuit Breaking Capacity (Icu) High, e.g., 35 kA or 65 kA @ 480V AC Trip Unit Type Electronic Trip Unit (Fixed Setting, as per "EGC06") Protection Functions Long-time delay, Short-time delay, Instantaneous (configurable within the EGC06 preset range) Mounting Fixed Operating Handle White (WH) Standards & Certifications IEC 60947-2, UL 489, CCC, CE

Parameter Specification Product Series Eaton IZM Model Number IZM67B3-PG20WH Description Molded Case Circuit Breaker, 250A, 3-Pole, Current Limiting, Fixed Mount Frame Size IZM67 Rated Current (In) 250 A (Fixed) Number of Poles 3 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 690V AC Rated Ultimate Short-Circuit Breaking Capacity (Icu) Very High, e.g., 65 kA or 100 kA @ 480V AC Trip Unit Type Electronic (as suggested by "PG" code, which often denotes a specific electronic trip unit setting) Mounting Fixed Operating Handle White (WH) Standards & Certifications IEC 60947-2, UL 489, CCC, CE

Parameter Specification Product Series Eaton IZM Model Number IZM65N4-A04WH Description Molded Case Circuit Breaker, 65A, 4-Pole, Fixed Mount Rated Current (Iu) 65 A Number of Poles 4 Rated Operational Voltage (Ue) 480V AC Rated Insulation Voltage (Ui) 690V AC Trip Unit Thermal-Magnetic (Fixed) Operating Handle White (WH) Standards & Certifications IEC 60947-2, UL 489, CCC, CE

Parameter Specification Product Series Eaton A22 (Accessory) Model Number A22-RD-53 Description 8-Pin Round Pin Relay Socket Terminal Type Screw Clamp Number of Pins 8 Pin Shape Round Rated Operational Current Typically 10A (dependent on the relay used) Rated Insulation Voltage 500V Mounting DIN Rail (35mm) Material Thermoplastic (PBT) Compatible Devices 8-pin round pin control relays, timer relays (e.g., Eaton A22 series compatible devices) Standards & Certifications UL 508, CSA, CE

Parameter Specification Product Series Eaton Power Xpert D2 Model Number PDC94G0100D2YJ Description DIN Rail DC Power Supply, 100W, 24V DC Out Output Power 100 W Output Voltage 24 V DC Output Current 4.2 A Input Voltage Range 85 - 264 V AC (Wide Range, suitable for global use) Input Frequency 47 - 63 Hz Efficiency High (typically >89%) Power Factor (PFC) >0.9 Line Regulation <±1% Load Regulation <±1% Ripple & Noise <150mV peak-to-peak Protections Overload (115-150%), Overvoltage, Short-circuit Operating Temperature -25°C to +70°C (with derating) Cooling Convection (Fanless) Mounting DIN Rail (35mm) Safety & EMC CE, cULus, RoHS, compliant with IEC/EN/UL 62368-1

Parameter Specification Product Series Eaton C22 Series Model Number C22-D-X-K10-P30 Description Electronic Pre-set Counter, 6-Digit, Dual Preset Supply Voltage 24-240V AC/DC (Wide Range) Counting Speed Up to 1kHz (depending on input type) Number of Digits 6 Number of Presets 2 (P1, P2) Outputs 2 relay outputs (for P1 and P2) Output Contact Rating Typically 3A @ 250V AC Input Types Depending on "K10" code (e.g., dry contact, NAMUR, voltage) Mounting DIN Rail (35mm) Display 6-digit LED or LCD Standards & Certifications CE, cULus

Parameter Specification Product Type Electronic Multi-Function Timer Relay Model Number T0-4-8222/IVS Supply Voltage 24-240V AC/DC (Wide Range) Timing Functions Multiple (e.g., On-delay, Off-delay, Interval, Flasher, One-shot) Number of Outputs 1 or 2 changeover (SPDT) relay outputs Output Contact Rating Typically 8A @ 250V AC Time Range Adjustable, typically from 0.05 seconds up to 300 hours (depending on function and model) Setting Method Via DIP-switches or a rotary switch to select functions and ranges Mounting DIN Rail (35mm) Terminals Screw Clamp or Spring Clamp (specific to /IVS variant) Status Indication LED for power and output status Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton DS6 Model Number DS6-340-22K-MX Description Soft Starter with Bypass, 340A Frame, 22kW, 400V Rated Supply Voltage 400V AC, 50/60 Hz (3 Phase) Frame Size 340A Motor Power Rating 22 kW (30 HP) @ 400V Set Current / Max. Current ~41-45A (估算，对应22kW电机) Control Supply Voltage 根据订货型号而定，常见100-250V AC或24V AC/DC Integrated Bypass Yes (Internal Bypass Contactor) Keypad Basic Keypad Start Control Voltage ramp, Current limit Protection Features Overload, Phase Loss, Phase Imbalance, Locked Rotor, Overheating Communication Enclosure Rating IP00

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+V36N3S Description Variable Frequency Drive, 68A, 37kW, 400V Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current 68 A Motor Power Rating 37 kW (50 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control Integrated Features DC Bus Choke (Standard), EMC Filter (Standard), Removable Graphic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP, PROFINET) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+V42N3S Description Variable Frequency Drive, 81A, 45kW, 400V Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current 81 A Motor Power Rating 45 kW (60 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control Integrated Features DC Bus Choke (Standard), EMC Filter (Standard), Removable Graphic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP, PROFINET) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS
