Key Features & Benefits Superior Processing Capability Dual-core processor @ 1.2GHz 2GB DDR3 RAM with error correction 4GB flash memory for program storage Enhanced Reliability 99.999% availability with redundant configuration Hot-swappable design for maintenance Built-in watchdog monitoring Comprehensive Connectivity Dual 1000BASE-T Ethernet ports PROFIBUS DP interface USB 2.0 configuration port Advanced Control Features 1ms control cycle execution Supports all IEC 61131-3 languages Integrated motion control functionality Technical Specifications Parameter Specification Processor Dual-core 1.2GHz Memory 2GB RAM, 4GB Flash Communication 2x GbE, 1x PROFIBUS DP, 1x USB Power Consumption 15W typical Operating Temp -40°C to +70°C Certifications UL, CE, ATEX, IEC 61508 SIL2 Typical Applications ✔ Power plant control systems ✔ Oil refinery process control ✔ Chemical batch processing ✔ Water treatment automation ✔ Pharmaceutical manufacturing

911

ABB

Key Features & Benefits High-Capacity Power Conditioning 60V DC output (FOUNDATION Fieldbus compliant) 500mA current capacity (field side) 2000V DC galvanic isolation Advanced Protection Instantaneous short-circuit protection (<1μs) Overvoltage and reverse polarity protection 8kV surge protection (ANSI/IEEE C62.41) Industrial-Grade Construction -40°C to +85°C operating range IP66-rated aluminum enclosure DIN-rail or panel mounting options Smart Diagnostics LED status indicators (power/segment health) Remote monitoring capability Predictive failure detection Technical Specifications Parameter Specification Input Voltage 24V DC (18-32V range) Output Voltage 60V DC (±1%) Maximum Current 500mA continuous Isolation 2000V DC (input-to-output) Response Time <1μs (short-circuit) Certifications ATEX, IECEx, UL, CSA, SIL2 Typical Applications ✔ Oil & gas production facilities ✔ Chemical processing plants ✔ Power generation systems ✔ Pharmaceutical manufacturing ✔ Water treatment automation

721

ABB

Key Features & Benefits Precision Power Regulation 65V DC output (FF H1 compliant) 450mA current capacity (field side) ±0.5% voltage regulation accuracy Advanced Protection System 1500V DC galvanic isolation <1μs short-circuit response 6kV/3kA surge protection Industrial Durability -40°C to +85°C operating range IP40-rated metal housing DIN-rail mountable (35mm) Smart Diagnostics Dual-color LED status indicators Remote monitoring capability Built-in self-test function Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 65V DC (±0.5%) Maximum Current 450mA Isolation 1500V DC Response Time <1μs (short-circuit) Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas processing plants ✔ Chemical production facilities ✔ Power generation systems ✔ Pharmaceutical manufacturing ✔ Water treatment plants

998

ABB

Key Features & Benefits Precision Power Regulation 19.5V DC output (FF H1 compliant) 350mA current capacity ±0.5% voltage regulation accuracy Advanced Protection Features 1500V DC galvanic isolation <1μs short-circuit response Reverse polarity protection Industrial-Grade Design -40°C to +85°C operating range IP40-rated aluminum enclosure Compact DIN-rail mounting (35mm) Enhanced Diagnostics LED status indicators (power/segment health) Remote monitoring capability Built-in self-test functionality Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 19.5V DC (±0.5%) Maximum Current 350mA Isolation 1500V DC Response Time <1μs (short-circuit) Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas processing facilities ✔ Chemical production plants ✔ Power generation systems ✔ Pharmaceutical manufacturing ✔ Water treatment automation

197

ABB

Key Features & Benefits Seamless Redundancy <1ms switchover time (zero packet loss) Dual independent H1 segments Automatic fault detection and recovery Signal Integrity Management <0.05dB signal attenuation Active signal conditioning 2000V DC galvanic isolation Industrial Robustness -40°C to +85°C operating range IP66-rated stainless steel housing DIN-rail or panel mounting options Advanced Diagnostics Dual-color LED per channel Remote health monitoring Predictive failure analysis Technical Specifications Parameter Specification Voltage Range 9-32V DC Current Capacity 500mA per segment Isolation 2000V DC (segment-to-segment) Switchover Time <1ms Certifications ATEX, IECEx, SIL2, UL, CSA Typical Applications ✔ Offshore oil platforms ✔ Nuclear power plants ✔ Pharmaceutical batch processes ✔ Chemical reactor control ✔ Critical pipeline operations

764

ABB

Key Features & Benefits Ultra-Fast Redundancy Switching <0.5ms automatic failover (zero process interruption) Dual independent H1 segments (1.0km range each) Live segment health monitoring Signal Integrity Optimization Active signal conditioning technology <0.03dB insertion loss 2500V DC galvanic isolation Extreme Environment Durability -40°C to +85°C operating range (with condensation protection) 316L stainless steel enclosure (IP68 rated) ATEX/IECEx Zone 1 [Ex ia] IIC T4 certified Advanced Predictive Maintenance Real-time segment impedance analysis Trend logging for 500+ parameters Web-based diagnostic interface Technical Specifications Parameter Specification Power Supply 18-32V DC (dual redundant inputs) Segment Current 600mA max per channel Isolation 2500V DC (input/output/segment) Communication Modbus TCP, OPC UA Certifications SIL2, ATEX, IECEx, UL, CSA, DNV-GL Typical Applications ✔ Floating production storage vessels (FPSOs) ✔ LNG processing trains ✔ Nuclear safety systems (Class 1E) ✔ Pharmaceutical sterile processing ✔ Critical chemical batch reactors

40

ABB

Key Features & Benefits High-Speed Fieldbus Communication Dual H1 channels (31.25 kbps) Supports 32 devices per segment <1ms cycle time for time-critical applications Advanced Diagnostics & Monitoring Real-time segment health analysis Predictive device failure detection Waveform capture for signal troubleshooting Industrial Reliability -40°C to +70°C operating range Hot-swappable design (with redundant configuration) 2000V galvanic isolation Seamless Integration Native integration with 800xA DCS Supports FF H1, HSE and HART protocols Configuration via Control Builder M Technical Specifications Parameter Specification Protocol FOUNDATION Fieldbus H1 (IEC 61158-2) Channels 2 independent H1 ports Device Support 32 devices per segment Isolation 2000V AC (channel-to-system) Certifications ATEX, IECEx, SIL2, UL, CSA Typical Applications ✔ Oil & gas production facilities ✔ Chemical batch processes ✔ Pharmaceutical manufacturing ✔ Power plant control systems ✔ Water treatment automation

992

ABB

Key Features & Benefits Superior Processing Power 800MHz dual-core processor 1GB RAM with error correction 16MB flash memory for application storage Enhanced Reliability 99.999% availability in redundant configurations Built-in watchdog timer Hot-swappable design for maintenance Comprehensive Connectivity Dual Ethernet ports (10/100/1000 Mbps) Serial communication ports (RS-232/RS-485) USB 2.0 configuration port Advanced Control Capabilities 1ms control cycle execution Supports all IEC 61131-3 programming languages Integrated motion control functionality Technical Specifications Parameter Specification Processor 800MHz dual-core Memory 1GB RAM, 16MB Flash Communication 2x Ethernet, 2x Serial, 1x USB Power Consumption 12W typical Operating Temp -40°C to +70°C Certifications UL, CE, ATEX, IEC 61508 SIL2 Typical Applications ✔ Oil & gas processing plants ✔ Power generation facilities ✔ Chemical production ✔ Pharmaceutical manufacturing ✔ Water treatment systems

716

ABB

Key Features & Benefits Precision Power Regulation 65V DC output (FF H1 compliant) 450mA current capacity (field side) ±0.5% voltage regulation accuracy Advanced Protection System 1500V DC galvanic isolation <1μs short-circuit response time 6kV/3kA surge protection Industrial-Grade Durability -40°C to +85°C operating range IP40-rated metal housing DIN-rail mountable (35mm) Smart Diagnostics Dual-color LED status indicators Remote monitoring capability Built-in self-test function Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 65V DC (±0.5%) Maximum Current 450mA Isolation 1500V DC Response Time <1μs (short-circuit) Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas processing plants ✔ Chemical production facilities ✔ Power generation systems ✔ Pharmaceutical manufacturing ✔ Water treatment plants

231

ABB

Key Features & Benefits Precision Power Management 19.5V DC output (FF H1 compliant) 350mA current capacity ±0.5% voltage regulation accuracy Advanced Protection System 1500V DC galvanic isolation <1μs short-circuit response Reverse polarity protection Industrial Durability -40°C to +85°C operating range IP40-rated aluminum enclosure Compact DIN-rail mounting (35mm) Enhanced Diagnostics LED status indicators (power/segment health) Remote monitoring capability Built-in self-test functionality Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 19.5V DC (±0.5%) Maximum Current 350mA Isolation 1500V DC Response Time <1μs (short-circuit) Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas processing facilities ✔ Chemical production plants ✔ Power generation systems ✔ Pharmaceutical manufacturing ✔ Water treatment automation

570

ABB

Key Features & Benefits Precision Power Regulation 20V DC output (FF H1 compliant) 400mA current capacity ±0.5% voltage regulation accuracy Advanced Protection System 1500V DC galvanic isolation <1μs short-circuit response 6kV/3kA surge protection Industrial-Grade Durability -40°C to +85°C operating range IP40-rated metal housing DIN-rail mountable (35mm) Smart Diagnostics Dual-color LED status indicators Remote monitoring capability Built-in self-test function Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 20V DC (±0.5%) Maximum Current 400mA Isolation 1500V DC Response Time <1μs (short-circuit) Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas processing plants ✔ Chemical production facilities ✔ Power generation systems ✔ Pharmaceutical manufacturing ✔ Water treatment plants

186

ABB

Key Features & Benefits Precision Power Management 20V DC output (FF H1 compliant) 500mA current capacity (field side) ±0.25% voltage regulation accuracy Advanced Protection System 2500V DC galvanic isolation <0.5μs short-circuit response 8kV/5kA surge protection (IEC 61000-4-5) Industrial Durability -40°C to +85°C operating range IP65-rated aluminum enclosure DIN-rail or panel mounting options Smart Diagnostics Real-time segment monitoring Predictive failure analysis Modbus TCP remote diagnostics Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 20V DC (±0.25%) Maximum Current 500mA Isolation 2500V DC Response Time <0.5μs (short-circuit) Communication Modbus TCP, USB 2.0 Certifications ATEX, IECEx, UL, CSA, SIL2 Typical Applications ✔ Oil & gas production facilities ✔ Chemical processing plants ✔ Pharmaceutical manufacturing ✔ Power generation systems ✔ Water treatment automation
