Technical Parameters Category Specification Model EMR6-VM600-A-1 Product Type Solid-State Overload Relay Rated Current Frame VM600 (Requires external Current Transformers for motors up to 600A) Motor Full Load Current Setting Adjustable via the integrated interface, scaled according to the CT ratio. Protection Functions Overload Protection Yes (with selectable trip class) Phase Unbalance Protection Yes Phase Loss Protection Yes Jam (Locked Rotor) Protection Yes Auxiliary Contacts Typically 2 NO + 2 NC for alarm and control signaling. Control Supply Voltage Wide range, typically 24-240V AC/DC. Status Indication LED indicators for Power, Trip, and Alarm conditions. Mounting Designed for DIN rail or direct mounting. Standards IEC/EN 60947-4-1, UL 508

Technical Parameters Category Specification Model EMR6-N1000-N-1 Product Type Solid-State Overload Relay Rated Current Frame N1000 (Requires external Current Transformers for motors up to 1000A) Motor Full Load Current Setting Adjustable via the integrated interface, scaled according to the CT ratio. Protection Functions Overload Protection Yes (with selectable trip class) Phase Unbalance Protection Yes Phase Loss Protection Yes Jam (Locked Rotor) Protection Yes Auxiliary Contacts Multiple NO/NC contacts for alarm and control signaling. Control Supply Voltage Wide range, typically 24-240V AC/DC. Status Indication LED indicators for Power, Trip, and Alarm conditions. Mounting Designed for DIN rail or direct mounting. Standards IEC/EN 60947-4-1, UL 508

Technical Parameters Category Specification Model M22-I2-M1 Product Type Inductive Proximity Sensor Housing Thread M22 x 1 Sensing Distance 2 mm (Nominal) Output Type Typically PNP, Normally Open (NO) (This is common for this code, must be verified) Output Configuration 3-wire Supply Voltage 10-30V DC Rated Current Typically ≤ 200 mA Connection Type Fixed Cable (M1), standard length (e.g., 2m). Housing Material Typically nickel-plated brass or stainless steel IP Rating IP67 (Dust-tight and protected against temporary immersion) Target Material Ferrous and Non-ferrous Metals (with different reduction factors)

Technical Parameters Category Specification Model TO-2-1/11 Product Type Solid-State Timing Relay Mounting Style DIN Rail (35mm) Time Range 0.05 Seconds to 100 Hours (widely adjustable) Supply Voltage Specific voltage depends on variant (e.g., 24V AC/DC, 110V AC, 230V AC). Must be verified from product label. Output Configuration 1 Changeover Contact (SPDT) Contact Rating (Output) Typically 6-8A @ 250V AC Timing Function Defined by "1/11" code, commonly ON-Delay Repeat Accuracy Typically < 1% of setting Dial Rotary knob with multi-turn adjustment Status Indication LED indicator for power and output status Operating Temperature -20°C to +60°C Agency Approvals UL Listed, CSA Certified, CE Marked

Technical Parameters Category Specification Model T0-2-15679/E Product Type Solid-State Timing Relay Mounting Style DIN Rail (35mm) Time Range Wide range (e.g., from seconds to hours), specific range defined by the order code. Supply Voltage Defined by "15679/E" code. Common voltages include 24V AC/DC, 110V AC, or 230V AC. (Must be verified from datasheet) Output Configuration Defined by order code. Typically 1 or 2 changeover contacts (SPDT). Contact Rating (Output) Typically 6-8A @ 250V AC Timing Function Defined by "15679/E" code. Common functions include ON-Delay, OFF-Delay, Interval, or Flasher. Repeat Accuracy High, typically < 1% of setting. Status Indication LED indicator for power and output status. Operating Temperature -20°C to +60°C Agency Approvals UL Listed, CSA Certified, CE Marked

Technical Parameters Category Specification Model M22-CK01D Product Type Capacitive Proximity Sensor Housing Thread M22 x 1 Sensing Distance Typically 1 to 5 mm (adjustable or fixed, depending on variant) Sensing Object Metallic and Non-Metallic materials (e.g., plastics, glass, liquids, wood) Output Type Typically PNP or NPN (Must be verified from datasheet), Normally Open (NO) Output Configuration 3-wire Supply Voltage 10-30V DC Rated Current Typically ≤ 200 mA Connection Type Fixed Cable or Quick-Disconnect (Connector) (defined by suffix) Housing Material Typically PBT or metal with sensing face in PTFE/POM for corrosion resistance IP Rating IP67 (Dust-tight and protected against temporary immersion)

Technical Parameters Category Specification Model A22-RPV/KC/I Product Type Illuminated Pushbutton (Modular) Series A22 Mounting Hole 22 mm Front Bezel Oil-tight, Dust-tight (IP65 rated) Button Type Rectangular Lens Color Green (as indicated by "V") Illumination Incandescent Bulb (typical for this vintage code) Contact Block KC (Typically 2 NO contacts) Contact Rating Typically 5A @ 250V AC Voltage for Lamp Depends on the specific bulb installed (e.g., 6V, 12V, 24V, 48V, 100V, 110V, 120V, 200V, 220V, 240V). Must be specified separately.

Technical Parameters Category Specification Model EMT6-DB(230V) Product Type Solid-State Soft Starter Rated Operational Voltage (Ue) 230V AC (for the main power terminals) Current Rating Frame DB (e.g., for motors up to 32A at 230V - Must verify exact current from datasheet) Control Supply Voltage Typically a separate value (e.g., 100-240V AC/DC) for the control circuit. Key Features Start Control Adjustable initial torque & ramp-up time. Stop Control Optional soft-stop (ramp-down). Protection Integrated overload, phase loss, and overcurrent protection. Control Method Voltage ramp control. Status Indication LED indicators for Power, Run, Fault, etc. Mounting DIN Rail or Panel Mount. Standards IEC/EN 60947-4-2, UL 508

Technical Parameters Category Specification Model M22-WRLK3-R Product Type Ultrasonic Proximity Sensor Housing Thread M22 x 1 Sensing Range Typically up to 600 mm (0.6 meters) or similar, programmable. Sensing Object Virtually any solid or liquid material (sound-reflective). Output Type Typically 1 PNP and 1 NPN output, programmable for NO/NC operation. Output Configuration 4-wire (2 for power supply, 1 PNP output, 1 NPN output). Supply Voltage 10-30V DC Current Consumption Typically < 30 mA Connection Type Fixed Cable (R), standard length (e.g., 2m). Housing Material Typically brass or stainless steel with PTFE/POM sensing face. IP Rating IP67 (Dust-tight and protected against temporary immersion) Key Features Programmability Teach-in function for easy setting of switching points. Temperature Compensation Built-in for stable performance in varying temperatures.

Technical Parameters Category Specification Model M22-DZ-B-GB14 Product Type 2-Wire AC Inductive Proximity Sensor Housing Thread M22 x 1 Sensing Distance 4 mm (Nominal) Output Type 2-wire AC Supply Voltage 20-253V AC, 50/60 Hz Rated Current Typically 5-200 mA (depending on model) Leakage Current Typically < 1.8 mA Connection Type Fixed Cable Housing Material Nickel-Plated Brass Target Material Ferrous Metals (e.g., Steel) IP Rating IP67 (Dust-tight and protected against temporary immersion)

Technical Parameters Category Specification Model M22-WRK3/K20 Product Type Ultrasonic Proximity Sensor Housing Thread M22 x 1 Sensing Range Defined by "/K20", typically up to 200 mm (0.2 meters). Sensing Object Virtually any solid or liquid material (sound-reflective). Output Type Typically 1 PNP and 1 NPN output, programmable for NO/NC operation. Output Configuration 4-wire (2 for power supply, 1 PNP output, 1 NPN output). Supply Voltage 10-30V DC Current Consumption Typically < 30 mA Connection Type Fixed Cable or Quick-Disconnect, defined by suffix. Housing Material Typically brass or stainless steel with PTFE/POM sensing face. IP Rating IP67 (Dust-tight and protected against temporary immersion) Key Features Programmability Teach-in function for easy setting of switching points. Temperature Compensation Built-in for stable performance in varying temperatures.

Technical Parameters Category Specification for MCS11 Series Model / Series MCS11 Product Type Modular Control and Signalling Station Mounting Panel Mount (Base frame snaps into a rectangular cutout) Front Panel Protection Typically IP65 (Dust-tight and protected against water jets) when properly installed. Module Types Actuators Pushbuttons (illuminated/non-illuminated), selector switches, key-operated switches, emergency stop. Contact Blocks Various contact configurations (e.g., 1NO, 1NC, 1NO+1NC). Pilot Lights Various lens colors and voltages for status indication. Contact Rating (Typical) 10A @ 250V AC (for contact blocks) Electrical Life Typically > 1,000,000 mechanical operations. Material Thermoplastic (PA) for high mechanical strength and chemical resistance. Agency Approvals UL Listed, CSA Certified, CE Marked
