ABB

Key Features & Benefits High Channel Density 32-channel isolated digital inputs Supports both 24V DC and 48V DC field signals Individual channel diagnostics Industrial-Grade Reliability -40°C to +70°C operating temperature High EMI/RFI immunity (EN 61000-6-2) Hot-swappable design (with carrier module) Advanced Diagnostics Per-channel LED status indicators Open wire detection Group fault reporting Flexible Configuration Configurable filter times (0.1ms to 20ms) Supports both sinking and sourcing inputs Compatible with redundant systems Technical Specifications Parameter Specification Input Channels 32 (electrically isolated) Input Voltage 24V DC (19-30V) / 48V DC (38-60V) Input Current 3mA typical (24V) Isolation 500V channel-to-channel Response Time Configurable 0.1-20ms Power Consumption 2.5W typical Certifications UL, CE, ATEX, IECEx Typical Applications ✔ Power plant control systems ✔ Oil & gas process automation ✔ Water treatment monitoring ✔ Discrete manufacturing ✔ Safety interlock systems

827

ABB

Key Features & Benefits Advanced Industrial Ethernet Dual-port 10/100 Mbps Ethernet with auto-negotiation PROFINET RT Class B and Modbus TCP protocol support Integrated switch functionality for daisy-chaining Robust Industrial Design -40°C to +70°C operating temperature range High EMC immunity (EN 61000-6-2, IEC 61850-3) Vibration-resistant DIN-rail mounting Enhanced Network Performance IEEE 1588 Precision Time Protocol (PTP) support VLAN and QoS for traffic prioritization <1μs port-to-port switching latency Seamless Integration Plug-and-play with AC500 PLC systems Configuration via ABB Automation Builder Comprehensive LED diagnostics Technical Specifications Parameter Specification Ethernet Standard IEEE 802.3 (10/100BASE-TX) Protocols PROFINET RT, Modbus TCP, DHCP Ports 2x RJ45 (shielded) Isolation Voltage 1500V DC Power Consumption 2.8W typical Certifications UL, CE, IEC 61850-3 Typical Applications ✔ Smart manufacturing systems ✔ Power distribution automation ✔ Water treatment control ✔ Oil & gas process automation ✔ Pharmaceutical production

702

ABB

Key Features & Benefits High Channel Density 16-channel isolated digital outputs Supports both 24V DC and 48V DC field signals 2A continuous current per channel Industrial-Grade Reliability -40°C to +70°C operating temperature High EMI/RFI immunity (EN 61000-6-2) Hot-swappable design (with carrier module) Advanced Protection & Diagnostics Per-channel short-circuit protection Open load detection LED status indicators for each channel Flexible Configuration Configurable pulse width modulation (PWM) Supports redundant output configurations Compatible with ABB's S800 I/O system Technical Specifications Parameter Specification Output Channels 16 (electrically isolated) Output Voltage 24V DC (19-30V) / 48V DC (38-60V) Output Current 2A continuous per channel Switching Capacity 0.5A @ 125V AC Isolation 500V channel-to-channel Response Time <1ms Power Consumption 3.5W typical Certifications UL, CE, ATEX, IECEx Typical Applications ✔ Power plant control systems ✔ Oil & gas process automation ✔ Water treatment control valves ✔ Discrete manufacturing ✔ Safety shutdown systems

267

ABB

Key Features & Benefits Safety-Certified Performance SIL3 (IEC 61508) / PLe (ISO 13849-1) certified Dual-channel monitoring with cross-circuit detection 100% mechanical forcibly guided contacts Flexible Safety Configurations 2 safety inputs (NC/NO configurable) 2 safety outputs (semiconductor + mechanical) 1 auxiliary output for status monitoring Industrial Durability -25°C to +55°C operating temperature 50 million mechanical operations Vibration resistant (5-500Hz, 5g) Easy Integration Compact 22.5mm width design Direct mounting on DIN rail (EN 60715) Visual LED status indicators Technical Specifications Parameter Specification Safety Standards SIL3, PLe, Cat.4 Input Voltage 24V DC (19.2-28.8V) Contact Rating 5A @ 250V AC (mechanical contacts) Response Time <20ms Max. Switching Freq. 1Hz Certifications TÜV, UL, CE, cULus Typical Applications ✔ Emergency stop circuits ✔ Safety gate monitoring ✔ Light curtain interfaces ✔ Two-hand control systems ✔ Press and molding machine safety

63

ABB

Key Features & Benefits Enhanced Safety Performance SIL3 (IEC 62061) / PL e (ISO 13849-1) certified Triple-channel monitoring with advanced diagnostics 100% mechanically linked contacts (EN 50205) Intelligent Safety Technology Auto-monitoring of contact welding Built-in diagnostics for wiring faults Configurable reset modes (manual/automatic) Industrial-Grade Robustness Extended temperature range (-40°C to +60°C) 10 million electrical operations rating IP20 protection (front panel) User-Centric Design Dual-color LED status indicators (red/green) Spring-clamp terminals for secure wiring 45mm compact DIN-rail design Technical Specifications Parameter Specification Safety Standards SIL3, PL e, Cat.4 Supply Voltage 24V DC/AC (±15%) Contact Capacity 6A @ 250V AC (resistive) Response Time <15ms (fault detection) Max. Switching Power 1500VA Certifications TÜV, UL, CE, CCC Typical Applications ✔ Robotic cell safety systems ✔ Press brake safety circuits ✔ Automated production line E-stops ✔ AGV (Automated Guided Vehicle) safety ✔ Semiconductor equipment guarding

990

ABB

Key Features & Benefits Intelligent Power Conditioning Integrated galvanic isolation (1500V DC) Active surge protection (6kV/3kA) Automatic current limiting (450mA max) Dual-Segment Architecture Powers two independent fieldbus segments Individual short-circuit protection per segment Segment-to-segment isolation Advanced Diagnostics LED indicators for power/signal status Remote monitoring capability via DCS Built-in termination diagnostics Industrial Durability -40°C to +85°C operating range Aluminum alloy housing for heat dissipation DIN-rail or panel mounting options Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 13.5-17.5V DC (fieldbus compliant) Segment Current 450mA max per segment Isolation 1500V DC (input-to-output) Certifications ATEX, IECEx, FM, CSA Typical Applications ✔ Oil & gas processing plants ✔ Pharmaceutical batch control ✔ Power plant instrumentation ✔ Chemical process loops ✔ Food & beverage automation

465

ABB

Key Features & Benefits Advanced Protocol Conversion Bidirectional PROFIBUS DP-V1 to PA conversion Supports all PA profile devices Automatic baud rate adaptation (9.6kbps-12Mbps) Robust Power Management Integrated power conditioning for PA segment Short-circuit and overload protection Galvanic isolation (1500V DC) Enhanced Diagnostics Dual-color LED status indicators Detailed fault reporting via GSD file Segment-specific error detection Industrial Durability -40°C to +70°C operating range Aluminum housing with IP20 protection DIN-rail mounting (35mm) Technical Specifications Parameter Specification DP Interface RS-485, 9.6kbps-12Mbps PA Interface IEC 61158-2, 31.25kbps Max Devices 32 PA devices per segment Power Supply 24V DC (±15%) Isolation 1500V DC (DP-to-PA) Certifications ATEX, IECEx, CE, UL Typical Applications ✔ Process plant PA device networks ✔ Hazardous area instrumentation ✔ Oil & gas fieldbus systems ✔ Pharmaceutical batch control ✔ Water treatment automation

482

ABB

Key Technical Features Ultra-Fast Protection <1μs short-circuit isolation response Dual-channel independent protection Automatic self-recovery functionality Signal Integrity Preservation Ultra-low insertion loss (<0.1dB) Advanced digital signal conditioning 1500V DC galvanic isolation Explosion-Proof Design [Ex ia] IIC T4 Ga certification 316L stainless steel enclosure IP66 protection rating Advanced Diagnostics Dual-color LED per channel (green/red) Fault counter with non-volatile memory Remote diagnostic capability via DCS Technical Specifications Characteristic Specification Operating Voltage 9-17.5V DC (PA bus powered) Max. Short-Circuit Current 450mA per channel Signal Bandwidth 7.8kHz-39kHz (PROFIBUS PA) Response Time 800ns typical Ambient Temperature -40°C to +85°C Hazardous Certifications ATEX, IECEx, FM, CSA, NEPSI Typical Applications ✔ Offshore oil platforms ✔ Petrochemical processing ✔ Pharmaceutical manufacturing ✔ Grain handling facilities ✔ Paint/coating production lines

571

ABB

Key Features & Benefits Advanced Power Management Dual-segment power conditioning (up to 450mA per segment) Active surge protection (6kV/3kA) Automatic current limiting with fast recovery Comprehensive Diagnostics Real-time segment voltage/current monitoring Advanced waveform analysis Built-in FFT spectrum analyzer Industrial Reliability -40°C to +85°C operating range 1500V DC galvanic isolation DIN-rail or panel mount options Smart Connectivity Modbus TCP interface for remote monitoring USB local configuration port Web server for browser-based access Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 13.5-17.5V DC (FF compliant) Diagnostic Resolution 16-bit ADC, 100ksps sampling Communication Modbus TCP, USB 2.0 Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas production facilities ✔ Pharmaceutical batch processes ✔ Power generation plants ✔ Chemical processing units ✔ Food & beverage automation

712

ABB

Key Features & Benefits Intelligent Segment Protection Microsecond-level short-circuit isolation (<1μs response time) Dual independent protected channels Automatic self-recovery function Signal Optimization Adaptive signal conditioning technology <0.05dB signal attenuation Advanced EMI/RFI filtering (up to 60dB rejection) Industrial Durability -40°C to +80°C operating range IP66-rated aluminum alloy enclosure DIN-rail mounting (35mm) Comprehensive Diagnostics Real-time current/voltage monitoring Segment health scoring system Predictive failure analysis Technical Specifications Parameter Specification Operating Voltage 9-17.5V DC (bus-powered) Protection Current 450mA per channel (configurable) Insertion Loss <0.05dB @ 31.25kHz Response Time 800ns (typical) Isolation 1500V DC (channel-to-channel) Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas production facilities ✔ Chemical processing plants ✔ Pharmaceutical manufacturing ✔ Power generation systems ✔ Food & beverage processing

41

ABB

Key Features & Benefits Reliable Power Conditioning Output: 20V DC (FOUNDATION Fieldbus compliant) Current limit: 350mA (field side) 1500V DC galvanic isolation Robust Protection Short-circuit and overload protection Reverse polarity protection Surge protection (6kV/3kA) Industrial Design Operating temperature: -40°C to +85°C DIN-rail mountable (35mm) Aluminum housing for heat dissipation Easy Integration Plug-and-play installation LED status indicators Compatible with major DCS systems Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 20V DC (±1%) Maximum Current 350mA Isolation Voltage 1500V DC Certifications ATEX, IECEx, UL, CSA Typical Applications ✔ Oil & gas processing plants ✔ Chemical production facilities ✔ Pharmaceutical manufacturing ✔ Power generation systems ✔ Water treatment plants

23

ABB

Key Features & Benefits Precision Power Conditioning Stabilized 20V DC output (±0.5%) 400mA current capacity (field side) Active current limiting with fast recovery Advanced Signal Integrity <0.1dB signal attenuation Integrated low-pass filtering (45kHz cutoff) 2000V DC galvanic isolation Smart Diagnostics Real-time voltage/current monitoring Waveform capture and analysis Predictive failure detection Industrial Robustness -40°C to +85°C operating range IP40-rated aluminum enclosure DIN-rail mounting (35mm) Technical Specifications Parameter Specification Input Voltage 18-32V DC Output Voltage 20V DC (±0.5%) Maximum Current 400mA (field side) Isolation 2000V DC (input-to-output) Diagnostic Interface Modbus TCP, USB 2.0 Certifications ATEX, IECEx, UL, CSA, SIL2 Typical Applications ✔ Offshore oil platforms ✔ Petrochemical refineries ✔ Pharmaceutical batch processes ✔ Power plant control systems ✔ Food & beverage production

465
