Parameter Category Specification Product Family / Type Numerical Motor Protection Relay Standard Compliance IEC 60255, IEC 60947-1, -4, -5 Rated Auxiliary Supply Voltage (Us) 24 - 48 V DC Motor Current Input (CT Secondary) 1 A or 5 A (Hardware selectable via DIP switch) Protection Functions • Thermal Overload (49) Based on motor FLC setting. Tripping characteristic matches motor thermal capacity. Separate alarm and trip settings. Cool/Start inhibit. • Short Circuit / Instant OC (50) High-set instantaneous overcurrent for short-circuit protection. • Start-up Supervision / Stall (48/14) Separate thermal model for start-up. Protects against locked rotor and prolonged starts. • Phase Unbalance / Loss (46) Protects against negative sequence currents due to phase unbalance or loss. • Earth-Fault (50N/51N) Residual current measurement (via core balance CT or derived). Instantaneous or time-delayed. • Undercurrent (37) Optional protection against pump run-dry or loss of load. • Number of Starts Programmable restriction on successive starts to prevent overheating. Setting & Configuration • Front Interface Rotary switch for Ir (FLC), Isd (SC), t6x (stall time) selection. DIP switches for Ie (EF), tE (EF delay), Iu (unbalance), etc. • PC Software Optional "PSRsoft" software for detailed configuration, monitoring, and diagnostics via USB port. Measured Values Phase currents (IL1, IL2, IL3), earth-fault current, thermal capacity used (%) Output Contacts • Trip Relay (CO) 1 Changeover contact, for tripping the circuit breaker/contactor. • Signal Relay 1 (CO) 1 Changeover contact, typically pre-assigned to Thermal Alarm. • Signal Relay 2 (CO) 1 Changeover contact, programmable for various alarms (e.g., Unbalance, Earth Fault). • Binary Inputs 2 inputs: Programmable for functions like Reset, General Alarm, Undercurrent Enable. Communication (Optional) Can be equipped with plug-in communication modules for: Modbus RTU (RS485), Profibus DP, DeviceNet. Human-Machine Interface (HMI) 7 LED indicators (Ready, Trip, Alarm, Start, Running, Comms, General Alarm). Rotary switch and DIP switches for settings. Motor Data Memory Stores thermal state for motor restart after power loss (with optional supercapacitor). Operating Temperature -20°C to +60°C (-4°F to +140°F) Housing & Mounting Compact, modular plastic case for DIN rail mounting (standard TS35 rail). Dimensions (W x H x D) Approximately 70mm x 125mm x 121mm (single module width).

Parameter Category Specification Product Family / Type Numerical Feeder Protection Relay Standard Compliance IEC 60255, IEC 61850 (with communication module), ANSI/IEEE C37.90 Rated Auxiliary Supply Voltage (Us) 48 - 250 V DC / 48 - 240 V AC, 50/60 Hz (Auto-ranging) Current Input (CT Secondary) 1 A or 5 A (Hardware selectable) Voltage Input (VT Secondary) 100 / 110 / 120 / 200 / 220 / 230 / 240 / 380 / 400 / 415 / 480 V AC (Phase-to-Phase) Protection Functions • Phase Overcurrent Two stages: Instantaneous (I>) & Time-delayed (I>>) with multiple IDMT/DT curves. • Earth-Fault Current Directional or Non-directional. One stage (I0>>) with IDMT/DT curves. Highly sensitive setting range. • Voltage Protection Two stages each for Undervoltage (U<) & Overvoltage (U>). Definite time delay. • Thermal Overload (49) Single time constant model, alarm and trip stages. Setting Ranges (Typical) • Phase Current 0.1 - 15.0 x In (In steps) • Earth Current 0.01 - 3.00 x In (In steps) • Voltage 10 - 130% of Un (Un = Rated VT input) Measured Values (Display) IL1, IL2, IL3, I0 (earth), UL1, UL2, UL3, Uavg, Freq, P, Q, S, PF, etc. Output Contacts • Trip Relays 3 Changeover (CO) contacts, high-breaking capacity. • Signal Relays 3 Changeover (CO) contacts for alarms/signaling. • Binary Inputs 4 or 5 programmable, for external control/blocking. Communication (Optional) Plug-in modules for: IEC 61850, Modbus RTU (RS485), Profibus DP, IEC 60870-5-103. Human-Machine Interface (HMI) Backlit graphical LCD, 6 navigation keys, 6 LED indicators (Ready, Trip, Alarm, etc.). Event Logging Stores time-tagged fault records, alarms, and operations. Operating Temperature -25°C to +70°C (-13°F to +158°F) Housing & Mounting Compact, modular plastic case. Suitable for flush mounting on panel door or DIN rail. Dimensions (W x H x D) Approximately 105mm x 145mm x 122mm (specific to case style).

Technical Parameters: Parameter Category Specification Standard Compliance IEC 60255, IEC 60870-5-103 (with comm. module) Rated Auxiliary Voltage (Us) 48 - 250 V DC / 48 - 240 V AC (wide range) Rated Frequency (fn) 50 / 60 Hz Current Input (CT Secondary) 1 A or 5 A (selectable) Overcurrent Protection • Phase Stages 2 stages: Instantaneous (I>) & Time-delayed (I>>) • Earth-Fault Stage 1 stage: Time-delayed (I0>>) • Setting Ranges Phase: Typically 0.1 - 1.2 x In (I>) & 1 - 15 x In (I>>) in steps. Earth: Typically 0.02 - 1.2 x In (sensitive). (Refer to official manual for exact ranges.) • Time Curves Definite Time (DT), Inverse Definite Minimum Time (IDMT) per IEC 60255 (e.g., EI, VI, LTI). Output Contacts • Trip Relay 2 or 3 changeover (CO) contacts, rated for high making/breaking capacity. • Signal Relay 2 or more changeover (CO) contacts for alarms/signaling. Communication (Optional) RS485 port with protocol options: ABB SPA, Modbus RTU, or IEC 60870-5-103. Operating Temperature -25°C to +55°C (-13°F to +131°F) Mounting Plug-in or fixed mounting for panel or DIN rail installation. Case Dimensions Compact form factor (approx. 144mm x 144mm or similar, model-dependent).

Key Specifications Parameter Category Specification Drive Series/Model ACS310-03E-48A4-4 Rated Output Current 48.4 A Rated Output Power 22 kW (30 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP20 / UL Open Type (Chassis). Requires installation in a protective cabinet. Cooling Method Fan-cooled Control Methods • Scalar Control (V/f) • ABB Direct Torque Control (DTC) for superior dynamic performance. Key Standard Features • Intelligent Pump and Fan Control (IPF): Includes auto-tuning for energy optimization, multi-pump control logic, dry pump protection, and anti-jam functions. • Embedded Application Programming: Built-in function blocks (timers, logic gates, comparators) for creating custom control logic without an external PLC. • Adaptive Program (AUP): Guides user through commissioning based on selected application. • Built-in Communication Protocols: Modbus RTU (RS-485) and BACnet MS/TP are standard for building automation integration. • LCD Keypad: Clear display with multi-language support and parameter copy function. • Integrated EMC Filter (Class A). • PID Controller: Advanced controller with sleep/wake, cascade control, and PID freeze functions. Protection Features • Motor thermal overload protection (I²t) • Pump/Fan-specific protection (dry pump, overload, underload) • Short circuit, ground fault, overcurrent, overvoltage protection • IGBT overtemperature protection • Automatic fault reset and restart Application Focus Large HVAC systems (fans, pumps), pressure boosting, water supply, cooling towers, and industrial fluid handling applications.

Key Specifications Parameter Category Specification Drive Series/Model DCS800-S02-0350-05 Motor Type DC Motor (Separate Armature & Field Supply) Rated Armature Current 350 A (Continuous DC Output) Rated Power Output ~160 kW (215 HP) (Estimated for a typical 460V DC motor armature). Power is voltage-dependent. Configuration Single Quadrant (S02): Forward motoring operation only. Cannot accept regenerative energy. Power Input 3-phase, 400V AC (±10%), 50/60 Hz (typical for "-05" code). Armature Output Voltage Variable DC, typically up to ~500V DC (for 400V AC supply). Field Supply Output Included. Adjustable DC output for motor field excitation. Control Method Digital thyristor (SCR) converter control. Programmable via DriveWindow™ software or control panel. Key Features • Digital Control Unit (DCU) for advanced programming. • Precise Speed Regulation (tachometer or EMF feedback). • Torque Control capability. • Extensive configurable I/O. • Field Weakening for extended speed range. • Comprehensive diagnostics and monitoring. Protection Features • Armature & field overcurrent. • Motor thermal overload (I²t). • Mains phase loss & undervoltage. • Overvoltage & overspeed. • Heatsink overtemperature. Typical Applications Large extruders, winders/unwinders (without regeneration), heavy mixers, machine tools, and large fans/pumps using DC motors.

Key Specifications Parameter Category Specification Drive Series/Base Model ACS580-01-044A-4 Rated Output Current 44 A Rated Output Power 22 kW (30 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 Cooling Method Fan-cooled Control Method ABB Direct Torque Control (DTC) Key Standard Features • Energy Optimizer: Automatically minimizes energy losses. • Intelligent Control Panel (IOP): Multilingual graphical display. • Embedded Application Macros: For pumps, fans, etc. • Built-in Modbus RTU (RS-485). • Built-in EMC Filter (Class A). Option +K454 Integrated Safe Torque Off (STO) Safety Function • Function: Prevents unexpected motor start-up by safely disabling the inverter's power output. • Safety Level: SIL 3 according to IEC 61800-5-2 / PL e according to ISO 13849-1. • Implementation: Two independent, safety-certified input channels for connection to safety devices (e.g., safety relays, PLCs, emergency stops). Protection Features • Comprehensive motor thermal and electrical protection. • Integrated functional safety via +K454. Application Focus Conveyors, mixers, pumps, fans, and general machinery where integrated personnel safety is required for maintenance or access.

Key Specifications Parameter Category Specification Drive Series/Base Model ACH550-BCR-012A-4 (Bypass Controller Ready) Rated Output Current 12 A Rated Output Power 5.5 kW (7.5 HP) Input/Output Voltage 380 - 480 V AC, 3-phase Enclosure Rating Designed for mounting within a bypass starter panel (specific enclosure depends on the panel builder). Control Method ABB Sensorless Flux Control (MFC) for HVAC. Key BCR Features • Dedicated logic and terminals for interfacing with external bypass contactors. • Automatic/manual transfer control between drive and bypass modes. • Motor current monitoring in bypass mode (optional). Option +C558 Embedded EtherNet/IP Adapter • Protocol: EtherNet/IP™ (Scanner/Adapter). • Ports: 2 x RJ45. • Function: Enables direct network integration for control and monitoring from a BMS or PLC (e.g., Allen-Bradley). Option +N2006 Extended I/O Kit • Function: Expands the drive's native I/O capacity to handle the complex switching logic and status monitoring of a bypass system. Option +X1558R Relay Output Expansion Kit • Function: Adds crucial Form C (changeover) relay outputs necessary to physically command the bypass contactors and provide isolated status signals (e.g., "Drive Running," "Bypass Active," "Fault"). Protection Features • Standard drive and motor protection. • Bypass system interlocks to prevent shorts. Application Focus Critical HVAC Systems with Bypass Requirements: Chilled Water Pumps, Condenser Pumps, Cooling Tower Fans, Critical Air Handling Units.

Key Specifications Parameter Category Specification Drive Series/Base Model ACS800-01-0070-5 Rated Output Current 70 A Rated Output Power 45 kW (60 HP) Input Supply Voltage 380 - 500 V AC (-15% / +10%), 3-phase Output Voltage/Phases 3-phase, 0 - Input voltage Enclosure Rating IP21 / UL Type 1 Cooling Method Fan-cooled Control Platform ABB Direct Torque Control (DTC), enabled by +P901. Option +K458 Enhanced Safety Functions Package • Typical Functions: Safe Stop 1 (SS1), Safely Limited Speed (SLS), Safe Brake Control (SBC), in addition to Safe Torque Off (STO). • Safety Level: SIL 3 according to IEC 61800-5-2 / PL e according to ISO 13849-1. • Purpose: Provides certified, integrated safety functions for protecting personnel and preventing hazardous machine motion. Option +P901 Standard Control Program with I/O Extension • Function: Provides essential firmware and I/O hardware. • Includes: Control logic, PID, extensive digital/analog I/O, and relay outputs. Protection Features • Comprehensive motor and drive electrical/thermal protection. • Integrated advanced safety functions via +K458. Application Focus Safety-critical applications: Cranes & Hoists, Robotics, Automated Material Handling, Presses, and machines with hazardous moving parts.

Key Specifications Parameter Category Specification Product Type Zone Control Unit (Safety & Cabinet Control Module) ABB Model ZCU-14 Order Code 3AXD50000005164 Primary Application ACS880 multidrive and other large ABB cabinet drive systems. Key Functions • Safety Interface: Processes safety inputs (e.g., emergency stop, safety door monitors) and controls safety outputs. • Cabinet Cooling Control: Controls and monitors cabinet ventilation fans, including fault detection. • Auxiliary Power Supervision: Monitors voltages of auxiliary power supplies within the zone. • Interlocking Logic: Provides programmable logic for interlocking between drives and external processes. • Diagnostics & Communication: Features LED status indicators and communication interfaces (typically via the drive's main control system). Typical Inputs/Outputs • Digital Inputs: For safety devices, temperature sensors, fan status. • Digital/Relay Outputs: For controlling contactors, fans, and status signals. • Communication: Integrates with the drive system's higher-level controller (e.g., via fiber optic or bus system). Mounting Designed for mounting inside an ACS880 or similar multidrive cabinet. Safety Role A key component in implementing the drive system's overall safety functions (e.g., Safe Torque Off - STO coordination, cabinet access safety).

Key Specifications Parameter Category Specification / Description Product Type Internal Component / Spare Part / Module Assembly ABB Order Code 3ABD00035957-D Associated Systems Likely part of a specific ABB industrial drive platform (e.g., ACS800, ACQ580, or related cabinet systems). Possible Functions Could be one of several specialized parts: • Control or Logic Board: A processing or signal conditioning board. • Power Supply Module: An auxiliary or gate driver power unit. • Communication Interface Board: For specific fieldbus protocols. • Fan Assembly / Cooling Unit: A replacement fan tray. • Capacitor Module: Part of the DC bus or snubber circuit. • I/O or Terminal Board: An extension or replacement I/O module. Physical Form Varies based on function (PCB assembly, mechanical unit with fans, capacitor block, etc.). Critical Note This is a highly specific spare part. Its exact function, compatibility, and technical specifications are defined solely by the host drive system it is designed for.

Key Specifications Parameter Category Specification Drive Series/Model ACS580-01-027A-4 Rated Output Current 27 A Rated Output Power 15 kW (20 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Fan-cooled Control Method ABB Direct Torque Control (DTC) Key Standard Features • Energy Optimizer: Automatically minimizes motor and drive losses for maximum energy efficiency. • Intelligent Control Panel (IOP): Plain language, multilingual graphical display for easy setup and monitoring. • Embedded Application Macros: Pre-programmed for common tasks (Pump/Fan, Hand/Auto, etc.). • Built-in EMC Filter (Class A). • Extensive Connectivity: Built-in Modbus RTU (RS-485); optional adapters for PROFINET, EtherNet/IP, PROFIBUS DP, etc. • Advanced PID Controller with sleep/wake and cascade control. • Flying Start and pump-specific functions (dry pump protection, anti-jam). Protection Features • Comprehensive motor thermal protection (I²t, PTC/KTY sensor inputs) • Full electrical protection (short circuit, ground fault, over/undervoltage, overcurrent) • IGBT and heatsink overtemperature protection • Motor stall and underload protection • Coated circuit boards available as an option for harsh environments. Application Focus Pumps, fans, compressors, conveyors, mixers, and other general-purpose industrial applications.

Key Specifications Parameter Category Specification Drive Series/Model ACH580-01-062A-4 Rated Output Current 62 A Rated Output Power 30 kW (40 HP) Input Supply Voltage 380 - 480 V AC (± 10%), 3-phase Input Supply Phases 3-phase Output Voltage 0 - Input voltage Output Phases 3-phase Enclosure Rating IP21 / UL Type 1 (Standard for -01) Cooling Method Fan-cooled Control Method ABB Direct Torque Control (DTC) Key Standard Features • Built-in Connectivity: BACnet MS/TP, Modbus RTU, and Metasys® N2 as standard. • Energy Optimizer: Automatically minimizes motor and drive losses. • Intelligent Control Panel: User-friendly display with application macros. • Built-in EMC Filter (Class A). • Advanced PID Controller with sleep/wake and anti-jam functions. • HVAC-specific functions: Fireman’s override, pump/fan curves. Protection Features • Comprehensive motor thermal protection (I²t, PTC sensor inputs) • Full electrical protection (short circuit, ground fault, over/undervoltage, overcurrent) • IGBT and heatsink overtemperature protection • Motor stall and underload protection • Conformal coated PCB option for harsh environments. Application Focus HVAC systems (air handling units, pumps, fans), light industrial applications, and building automation.
