Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT2 Frame Size: XT2 Rated Current (In): 160 A Number of Poles: 4P Trip Unit Type: TMD (Thermal-Magnetic) Thermal Protection: Fixed setting (overload protection) Magnetic Protection: Fixed instantaneous short-circuit protection Trip Unit Setting Type: FF (Fixed Frame) Rated Operational Voltage (Ue): Up to 690 V AC Rated Frequency: 50 / 60 Hz Breaking Capacity Class: S (standard breaking capacity) Mounting Type: Fixed installation Operating Mechanism: Manual Connection Type: Screw terminals Typical Applications: Power distribution feeders Industrial and commercial electrical systems Protection of cables, transformers, and downstream equipment Standards: IEC / EN 60947-2

Specifications Product Type: Power Contactor Series: AL Model: AL16-30-01 (equivalent AL series designation) Rated Operational Current (Ie): 16 A (AC-3) Rated Operational Voltage (Ue): Up to 690 V AC Number of Poles: 3P Main Contact Configuration: 3 NO (Normally Open) Auxiliary Contacts: Typically 1 NO + 1 NC Control Voltage (Coil): 24 V DC Coil Type: DC operated Rated Frequency: 50 / 60 Hz Mounting Type: DIN rail or panel mounting Connection Type: Screw terminals Utilization Category: AC-3 (motor control) AC-1 (resistive loads) Typical Applications: Motor starters Industrial automation panels Pumps, fans, compressors Standards: IEC / EN 60947-4-1

Specifications Product Type: Residual Current Circuit Breaker with Overcurrent Protection (RCBO) Series / Model: GSH204 Rated Current (In): 10 A Rated Residual Operating Current (IΔn): 30 mA Trip Type / Characteristic: C-type (instantaneous short-circuit response) Poles: 2P (Single-phase + Neutral) Rated Operational Voltage (Ue): 230 V AC Rated Frequency: 50 / 60 Hz Rated Short-Circuit Breaking Capacity (Icn / Ics): Typically 6 kA Mounting Type: DIN rail Connection Type: Screw terminals Typical Applications: Protection of circuits in residential and commercial installations Protection against earth leakage and overcurrent Lighting, socket outlets, and small appliances Standards: IEC / EN 61009-1

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: T1N Frame Size: T1N160 Rated Current (In): 160 A Trip Unit Type: TMD (Thermal-Magnetic) Thermal Protection: Fixed setting (overload protection) Magnetic Protection: Fixed instantaneous short-circuit protection Magnetic Trip Range: 63 – 630 A Trip Unit Setting: FFC (Fixed Thermal / Fixed Magnetic) Number of Poles: 4P Rated Operational Voltage (Ue): Up to 690 V AC Rated Frequency: 50 / 60 Hz Mounting Type: Fixed installation Operating Mechanism: Manual Typical Applications: Power distribution feeders Industrial and commercial electrical systems Protection of cables, transformers, and downstream equipment Standards: IEC / EN 60947-2

Specifications Product Type: Manual Motor Starter (MMS) Series: MS132 Rated Operational Current (Adjustable): 0.25 – 0.40 A Protection Functions: Thermal overload protection (adjustable) Magnetic short-circuit protection Phase loss sensitive Tripping Class: Class 10 Rated Operational Voltage (Ue): Up to 690 V AC Rated Insulation Voltage (Ui): 690 V Rated Frequency: 50 / 60 Hz Number of Poles: 3P Control Type: Manual ON/OFF via rotary handle Mounting Type: DIN rail or panel mounting Connection Type: Screw terminals Reset Type: Manual reset Typical Applications: Small motor protection Industrial control panels Pumps, fans, and auxiliary drives Standards: IEC / EN 60947-2, IEC / EN 60947-4-1

Specifications Product Type: Manual Motor Starter (MMS) Series: MS132 Rated Operational Current (Adjustable): 0.10 – 0.16 A Protection Functions: Thermal overload protection (adjustable) Magnetic short-circuit protection Phase loss sensitive Tripping Class: Class 10 Rated Operational Voltage (Ue): Up to 690 V AC Rated Insulation Voltage (Ui): 690 V Rated Frequency: 50 / 60 Hz Number of Poles: 3P Control Type: Manual ON/OFF with rotary handle Mounting Type: DIN rail or panel mounting Connection Type: Screw terminals Reset Type: Manual reset Typical Applications: Small motor protection Industrial control panels Pumps, fans, and auxiliary drives Standards: IEC / EN 60947-2, IEC / EN 60947-4-1

Specifications Product Type: Power Contactor Series: A Model: A145-30-11 Rated Operational Current (Ie): 145 A (AC-3) Rated Operational Voltage (Ue): Up to 690 V AC Number of Poles: 3P (main contacts) Main Contact Configuration: 3 NO Auxiliary Contacts: 1 NO + 1 NC (11) Control Voltage (Coil): 220 V AC Control Voltage Frequency: 50 / 60 Hz Utilization Category: AC-3 (motor control) AC-1 (resistive loads) Mounting Type: Panel mounting Connection Type: Screw terminals Typical Applications: Motor starters Pumps, fans, compressors Industrial automation and power distribution Standards: IEC / EN 60947-4-1

Specifications Product Type: Contactor Relay / Auxiliary Contactor Series: NL Model: NL40E Control Voltage (Coil): 24 V DC Voltage Type: DC Number of Poles: 4-pole Contact Configuration: 4 NO (Normally Open) Rated Operational Voltage (Ue): Up to 690 V AC Rated Operational Current (Ie): 10 A (AC-1, typical auxiliary circuit rating) Rated Frequency: 50 / 60 Hz Connection Type: Screw terminals Mounting Type: DIN rail or panel mounting Coil Polarity: Polarity sensitive (DC coil) Typical Applications: Control and signaling circuits Industrial automation systems Interlocking and logic control Standards: IEC / EN 60947-5-1

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT2 Frame Size: XT2 Breaking Capacity Class: N (normal breaking capacity) Rated Current (In): 160 A Trip Unit Type: Ekip LS/I (Electronic) Long-Time Protection (L): Adjustable overload protection Short-Circuit Protection: S (short-time delay, adjustable) I (instantaneous, adjustable) Trip Unit Rating Plug: R160 Trip Unit Setting Type: FF (Fixed frame) Number of Poles: 3P Rated Operational Voltage (Ue): Up to 690 V AC Rated Frequency: 50 / 60 Hz Mounting Type: Fixed installation Operating Mechanism: Manual Communication / Measurement: Not included (basic electronic protection only) Standards: IEC / EN 60947-2 Typical Applications: Power distribution feeders Industrial and commercial electrical installations Systems requiring adjustable protection and coordination

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT2 Frame Size: XT2 Rated Current (In): 160 A Trip Unit Type: MA (Magnetic Only) Thermal Protection: Not included Magnetic Protection: Short-circuit protection only Magnetic Trip Setting Range: 20 × In / 120–280 A (fixed setting) Trip Unit Setting: FF (Fixed) Number of Poles: 3P Breaking Unit: S (standard breaking capacity) Rated Operational Voltage (Ue): Up to 690 V AC Rated Frequency: 50 / 60 Hz Mounting Type: Fixed installation Operating Mechanism: Manual Typical Applications: Motor feeders with external overload relay Transformer protection Industrial power distribution Standards: IEC / EN 60947-2

Specifications Product Type: Contactor Series: AL Model: AL26-30-01 Rated Operational Current (Ie): 26 A (AC-3) Rated Operational Voltage (Ue): Up to 690 V AC Number of Poles: 3P (main contacts) Main Contact Configuration: 3 NO Auxiliary Contacts: 1 NC (01) Control Voltage (Coil): 24 V DC Coil Type: DC operated Rated Frequency: 50 / 60 Hz (main circuit) Mounting Type: DIN rail or panel mounting Connection Type: Screw terminals Utilization Category: AC-3 (motor control) AC-1 (resistive loads) Typical Applications: Motor starters Industrial automation panels Pumps, fans, compressors Standards: IEC / EN 60947-4-1

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: SACE S2X Frame Size: S2X Rated Current (In): 80 A Trip Unit Type: R11 (Thermal-Magnetic) Thermal Protection: Fixed overload protection Magnetic Protection: Fixed instantaneous short-circuit protection Trip Unit Setting: FFC (Fixed Thermal / Fixed Magnetic) Number of Poles: 3P Rated Operational Voltage (Ue): Up to 690 V AC Rated Insulation Voltage (Ui): 800 V Rated Impulse Withstand Voltage (Uimp): 8 kV Rated Frequency: 50 / 60 Hz Breaking Capacity Class: X (high breaking capacity) Mounting Type: Fixed installation Operating Mechanism: Manual Standards: IEC / EN 60947-2 Typical Applications: Power distribution feeders Industrial and commercial electrical systems Protection of cables and downstream equipment
