Specifications Product Type: Power Contactor Series: A Model: A145-30-11 Rated Operational Current (Ie): 145 A (AC-3) Rated Operational Voltage (Ue): Up to 690 V AC Number of Poles: 3P (main contacts) Main Contact Configuration: 3 NO Auxiliary Contacts: 1 NO + 1 NC (11) Control Voltage (Coil): 220 V AC Control Voltage Frequency: 50 / 60 Hz Utilization Category: AC-3 (motor control) AC-1 (resistive loads) Mounting Type: Panel mounting Connection Type: Screw terminals Typical Applications: Motor starters Pumps, fans, compressors Industrial automation and power distribution Standards: IEC / EN 60947-4-1

Specifications Product Type: Contactor Relay / Auxiliary Contactor Series: NL Model: NL40E Control Voltage (Coil): 24 V DC Voltage Type: DC Number of Poles: 4-pole Contact Configuration: 4 NO (Normally Open) Rated Operational Voltage (Ue): Up to 690 V AC Rated Operational Current (Ie): 10 A (AC-1, typical auxiliary circuit rating) Rated Frequency: 50 / 60 Hz Connection Type: Screw terminals Mounting Type: DIN rail or panel mounting Coil Polarity: Polarity sensitive (DC coil) Typical Applications: Control and signaling circuits Industrial automation systems Interlocking and logic control Standards: IEC / EN 60947-5-1

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT2 Frame Size: XT2 Breaking Capacity Class: N (normal breaking capacity) Rated Current (In): 160 A Trip Unit Type: Ekip LS/I (Electronic) Long-Time Protection (L): Adjustable overload protection Short-Circuit Protection: S (short-time delay, adjustable) I (instantaneous, adjustable) Trip Unit Rating Plug: R160 Trip Unit Setting Type: FF (Fixed frame) Number of Poles: 3P Rated Operational Voltage (Ue): Up to 690 V AC Rated Frequency: 50 / 60 Hz Mounting Type: Fixed installation Operating Mechanism: Manual Communication / Measurement: Not included (basic electronic protection only) Standards: IEC / EN 60947-2 Typical Applications: Power distribution feeders Industrial and commercial electrical installations Systems requiring adjustable protection and coordination

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT2 Frame Size: XT2 Rated Current (In): 160 A Trip Unit Type: MA (Magnetic Only) Thermal Protection: Not included Magnetic Protection: Short-circuit protection only Magnetic Trip Setting Range: 20 × In / 120–280 A (fixed setting) Trip Unit Setting: FF (Fixed) Number of Poles: 3P Breaking Unit: S (standard breaking capacity) Rated Operational Voltage (Ue): Up to 690 V AC Rated Frequency: 50 / 60 Hz Mounting Type: Fixed installation Operating Mechanism: Manual Typical Applications: Motor feeders with external overload relay Transformer protection Industrial power distribution Standards: IEC / EN 60947-2

Specifications Product Type: Contactor Series: AL Model: AL26-30-01 Rated Operational Current (Ie): 26 A (AC-3) Rated Operational Voltage (Ue): Up to 690 V AC Number of Poles: 3P (main contacts) Main Contact Configuration: 3 NO Auxiliary Contacts: 1 NC (01) Control Voltage (Coil): 24 V DC Coil Type: DC operated Rated Frequency: 50 / 60 Hz (main circuit) Mounting Type: DIN rail or panel mounting Connection Type: Screw terminals Utilization Category: AC-3 (motor control) AC-1 (resistive loads) Typical Applications: Motor starters Industrial automation panels Pumps, fans, compressors Standards: IEC / EN 60947-4-1

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: SACE S2X Frame Size: S2X Rated Current (In): 80 A Trip Unit Type: R11 (Thermal-Magnetic) Thermal Protection: Fixed overload protection Magnetic Protection: Fixed instantaneous short-circuit protection Trip Unit Setting: FFC (Fixed Thermal / Fixed Magnetic) Number of Poles: 3P Rated Operational Voltage (Ue): Up to 690 V AC Rated Insulation Voltage (Ui): 800 V Rated Impulse Withstand Voltage (Uimp): 8 kV Rated Frequency: 50 / 60 Hz Breaking Capacity Class: X (high breaking capacity) Mounting Type: Fixed installation Operating Mechanism: Manual Standards: IEC / EN 60947-2 Typical Applications: Power distribution feeders Industrial and commercial electrical systems Protection of cables and downstream equipment

Specifications Product Type: Molded Case Circuit Breaker (MCCB) Series: Tmax XT5 Frame Size: XT5 Rated Current (In): 630 A Trip Unit Type: TMA (Thermal-Magnetic) Thermal Protection: Fixed setting (overload protection) Magnetic Protection: Fixed instantaneous short-circuit protection Magnetic Trip Range: Up to 6300 A Number of Poles: 3P Breaking Unit: S (standard breaking capacity) Rated Operational Voltage (Ue): Up to 690 V AC Rated Frequency: 50 / 60 Hz Mounting Type: Fixed installation Operating Mechanism: Manual Main Application: Power distribution Motor feeders and transformers Industrial and commercial electrical systems Standards: IEC / EN 60947-2

Specifications Product Type: Contactor Relay / Auxiliary Contactor Series / Model: TNL22E-51 Control Voltage: 17–32 V DC Voltage Type: DC Number of Poles: 4-pole Contact Configuration: 2 NO + 2 NC (Normally Open / Normally Closed) Rated Operational Function: Switching of auxiliary and control circuits Main Circuit: Not suitable for power switching Coil Polarity: Polarity sensitive (A1+ / A2–) Connection Type: Screw terminals Mounting Type: DIN rail or panel mounting Typical Applications: Control panels Industrial automation systems Signaling and interlocking circuits Approximate Dimensions (H × W × D): 78 × 44 × 97 mm Approximate Weight: 0.5 kg

Technical Specifications Parameter Specification Part / Model MS132‑10 Product Type Manual Motor Starter / Motor Protection Circuit Breaker Series / Family MS132 Rated Operational Current (Ie) 10 A (setting range 6.3 – 10 A) Number of Poles 3 poles Rated Operational Voltage 690 V AC / 250 V DC Rated Service Short‑Circuit Breaking Capacity (Ics) 100 kA @ 400 V AC Trip Class 10 Trip Mechanism Thermo‑magnetic with overload & short‑circuit protection Disconnect Function Built-in Phase Loss Sensitivity Yes Handle / Control Rotary ON/OFF/Trip with position indicator; lockable Temperature Compensation Yes (–25 °C to +70 °C operating) Suitable For Three-phase and single-phase motors Rated Power (AC‑3) ~0.25 kW @ 400 V AC Terminal Type Screw terminals Mounting DIN rail or panel mount Degree of Protection IP20 Frequency 50 / 60 Hz Dimensions (W × H × D) ~45 mm × 90 mm × 86.75 mm Approx. Weight ~0.26 kg

Technical Specifications Parameter Specification Part Number / Model 1SDA050955R1 Product Type Molded Case Circuit Breaker (MCCB) Series / Family ABB Tmax T2N Trip Unit Type Thermo‑magnetic (TMD) Number of Poles 3 poles (3P) Rated Current (In) 50 A Rated Operational Voltage (Ue) Up to 690 V AC typical Overload Trip Adjustment Adjustable thermal range (approx. 50–500 A range on TMD unit) Short‑Circuit Protection Fixed magnetic trip (part of TMD release) Rated Ultimate Breaking Capacity (Icu) 36 kA (at 400 V AC class typical) Rated Service Breaking Capacity (Ics) Similar to Icu at common system voltages Connection Type Front terminals Mounting Fixed installation Standards Compliance IEC 60947‑2 (typical for Tmax series) Degree of Protection IP20 (typical) Typical Width ~90 mm Approx. Weight ~1.1 kg

Technical Specifications Parameter Specification Part / Model ABB CA5‑22E Product Type Auxiliary Contact Block Contact Configuration 2 Normally Open (NO) + 2 Normally Closed (NC) Rated Insulation Voltage (Ui) Up to 690 V AC Rated Operational Voltage 50 / 60 Hz, auxiliary circuit up to 690 V Rated Operational Current (AC‑15) ~6 A @ 24 / 127 V AC; ~4 A @ 220 / 240 V AC; ~3 A @ 380 / 440 V AC; ~2 A @ 500 / 690 V AC Rated Operational Current (DC‑13) ~6 A @ 24 V DC; ~2.8 A @ 48 V DC; ~0.55 A @ 110–125 V DC; ~0.3 A @ 220–250 V DC Terminal Type Screw terminals Mounting Type Front‑mounted on ABB contactors Operating Cycles 1200 electrical cycles/hour, 3600 mechanical cycles/hour Short‑Time Withstand Current 140 A for 0.1 s Maximum Mechanical Durability ~10 million cycles Maximum Electrical Durability ~3 million cycles Degree of Protection IP20 (auxiliary terminals) Dimensions (approx.) 44 × 47 × 39 mm (W × H × D) Weight (approx.) ~0.06 kg

Technical Specifications Parameter Specification Part Number / Model 1SAM550000R1010 Product Name MS495‑100 Manual Motor Starter Product Type Manual Motor Starter / Motor Protection Circuit Breaker Series / Family MS495 Rated Operational Current (Ie) 100 A (adjustable 80–100 A) Number of Poles 3 Rated Operational Voltage 450 – 690 V AC Service Short‑Circuit Breaking Capacity (Ics) 25 kA @ 400 V AC Ultimate Breaking Capacity (Icu) 50 kA @ 400 V AC Trip Class Class 10 (thermal/magnetic) Short‑Circuit (Instantaneous) Setting ~1235 A Rated Operational Power (AC‑3) ~55 kW @ 400 V AC Control / Operation Rotary ON/OFF/Trip handle, lockable Mechanism Trip‑free with temperature compensation Protection Functions Overload, short circuit, phase failure Mounting Panel or control panel chassis Connection Type Screw terminals Degree of Protection IP20 Pollution Degree 3 Ambient Temperature (Operating) –20 °C to +70 °C Dimensions (W × H × D) 70 mm × 165 mm × 174 mm Weight ~2.28 kg Standards IEC low-voltage control and protection standards
