ABB

Key Specifications Parameter Specification Output Current 26A Rated Power 11kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Flux-optimized V/f & DTC (Sensorless Vector) Overload 150% for 60 seconds Communication Modbus RTU (RS485) standard Advanced Features ✔ Energy Optimization - Adaptive programming reduces energy consumption by 20-50% ✔ Intuitive Control - ABB Assist Panel with plain-text parameter interface ✔ Built-in Safety - Safe Torque Off (STO) function (SIL3/PL e certified) ✔ Smart Cooling - Temperature-controlled fan with low noise operation ✔ Fieldbus Ready - Optional PROFIBUS DP, BACnet, Ethernet/IP adapters ✔ Robust Protection - Motor thermal, short-circuit, and phase-loss protection Model Identification ACS580: Series name 01: IP21 enclosure rating 026A: 26A output current 4: 400V voltage class (380-480V)

552

ABB

Key Specifications Parameter Specification Output Current 4A Rated Power 1.1kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Flux-optimized V/f & DTC (Sensorless Vector) Overload 150% for 60 seconds Communication Modbus RTU (RS485) standard Key Features ✔ Energy Optimization - Automatic motor adaptation reduces energy consumption by up to 30% ✔ Intuitive Operation - ABB Assist Panel with plain-text parameter names ✔ Compact Design - Space-saving dimensions (155 x 190 x 175mm) ✔ Built-in Safety - Safe Torque Off (STO) function (SIL3/PL e) ✔ Fieldbus Ready - Optional PROFIBUS DP, BACnet, Ethernet/IP adapters

86

ABB

Key Specifications Parameter Specification Output Current 46A Rated Power 18.5kW (4-pole) / 22kW (2-pole) Input Voltage 3-phase 380–480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis, panel-mountable) Control Method Flux-optimized V/f & DTC (Sensorless Vector) Overload 150% for 60 seconds Communication Modbus RTU (RS485), optional fieldbus Key Features ✔ Energy Optimization – Adaptive programming reduces energy consumption by up to 30% in pump/fan applications. ✔ User-Friendly Interface – Assist Panel with plain-text parameter names (no codes). ✔ Built-in Safety – Safe Torque Off (STO, SIL3/PL e) for emergency stops. ✔ Smart Cooling – Temperature-controlled fan (IP21) with low acoustic noise. ✔ Fieldbus Ready – Supports PROFIBUS DP, BACnet MS/TP, Ethernet/IP (via adapters). ✔ Robust Protection – Motor thermal protection, short-circuit, and phase-loss safeguards. Model Number Breakdown ACS580: Series (ABB’s general-purpose drive) 01: IP21 enclosure (basic protection) 046A: 46A output current 4: 400V voltage range (380–480V)

775

ABB

Key Specifications Parameter Specification Output Current 12A Rated Power 5.5kW (400V, 4-pole motor) Input Voltage 3-phase 380–480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis, panel-mountable) Control Method Flux-optimized V/f & DTC (Sensorless Vector) Overload 150% for 60 seconds Communication Modbus RTU (RS485), optional fieldbus Key Features ✔ Energy-Saving Control – Automatic motor adaptation reduces energy consumption by up to 30% in pump/fan applications. ✔ Intuitive Operation – Assist Panel with plain-text parameter names (no codes). ✔ Built-in Safety – Safe Torque Off (STO, SIL3/PL e) for emergency stops. ✔ Smart Cooling – Temperature-controlled fan (IP21) with low acoustic noise. ✔ Fieldbus Ready – Supports PROFIBUS DP, BACnet MS/TP, Ethernet/IP (via adapters). ✔ Robust Protection – Motor thermal protection, short-circuit, and phase-loss safeguards. Model Number Breakdown ACS580: Series (ABB’s general-purpose drive) 01: IP21 enclosure (basic protection) 12A7: 12A output current, 5.5kW power class 4: 400V voltage range (380–480V)

621

ABB

Core Components ACD880-104-0600A-7 Main Drive Unit Power Stage: Current Rating: 600A continuous Voltage Class: 380-500V AC (±10%) Topology: Active Front End (AFE) with IGBT technology Efficiency: 98.2% typical at full load Performance Features: <3% current harmonics (THID) 0.99 displacement power factor Regenerative braking capability C252 Advanced Control Panel 7" multi-touch HMI with 1280×800 resolution Dual-core processor for real-time visualization Integrated web server for remote access 8GB non-volatile memory for data logging E205 High-Precision Encoder Interface Supports 24-bit absolute encoders 250kHz update rate Dual-channel safety-rated position feedback Technical Highlights ✔ Precision Motion Control Speed regulation: ±0.01% of base speed Torque ripple: <2% of rated torque Advanced anti-cogging algorithms ✔ Smart Energy Management Regenerative energy recovery Automatic power factor correction Energy consumption monitoring (kWh/MWh) ✔ Industrial Connectivity Standard interfaces: 2× PROFINET IRT (TSN-ready) 1× EtherNet/IP OPC UA Pub/Sub ✔ Safety Systems SIL3/PL e safety functions: Safe Torque Off (STO) Safe Stop 1 (SS1) Safe Limited Speed (SLS) Mechanical Specifications Main Drive Dimensions: 600×800×400mm (W×H×D) Cooling Requirements: Forced air (2000m³/h minimum) Ambient Conditions: Operation: 0°C to +45°C (derating above +40°C) Storage: -25°C to +70°C Humidity: 5-95% non-condensing Certifications & Compliance Safety: ISO 13849-1, IEC 62061 EMC: EN 61800-3 Category C4 Marine: DNV GL, ABS, LR Explosive Atmospheres: ATEX II 3G Ex ec nC IIC T4 Gc

555

ABB

Technical Specifications Parameter Specification Output Current 246A continuous Power Rating 132kW (400V 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Overload Capacity 110% for 60s (heavy-duty) / 150% for 3s Efficiency >97.5% at full load Enclosure IP21 (NEMA 1 equivalent) Advanced Technical Features 1. Enhanced Motor Control Flux-optimized V/f control with automatic slip compensation Low-speed torque boost (0.5Hz @ 150% torque) Advanced sequencing for pump cascading systems 2. Intelligent Protection System Multi-level I²t thermal modeling (motor + drive) Real-time bearing current monitoring Integrated DC bus overvoltage suppression 3. Industrial Connectivity Dual-port RS485 Modbus RTU (isolated) Optional PROFIBUS DP-V1 (3.5Mbps) BACnet MS/TP protocol for HVAC integration Mechanical Design Dimensions: 350(W) × 450(H) × 250(D) mm Cooling System: Intelligent fan control with dust-proof design Installation: Wall-mounted or floor-standing (200mm minimum clearance) Weight: 38kg (without options) Application-Specific Capabilities For Pumping Systems: Automatic cavitation prevention logic Sleep/wake function for demand-based operation Duty rotation for multi-pump installations For Ventilation: Fireman's override functionality Airflow calculation via differential pressure input Night purge cycling capability Compliance & Certifications Safety: SIL2 compliant (with appropriate configuration) EMC: EN 61800-3 Category C3 Marine: DNV-GL type approval (optional) Climate: Operates at -15°C to +50°C (with derating)

701

ABB

Key Specifications Parameter Specification Output Current 246A Rated Power 132kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Sensorless Vector Control (SLVC) Overload 110% for 60 seconds (heavy-duty rating) Communication Modbus RTU standard + optional fieldbus Technical Highlights ✔ High-Efficiency Design 98% typical efficiency at full load Automatic energy optimization for variable torque loads ✔ Advanced Protection Features I²t motor thermal protection Built-in DC choke (harmonic mitigation) Ground fault and short-circuit protection ✔ Industrial-Grade Construction Reinforced cooling system with temperature-controlled fans -10°C to +40°C operation (with derating above 40°C) Compact footprint for power class (WxHxD: 350×450×250mm) ✔ Smart Control Capabilities Built-in PID controller with auto-tuning Customizable application macros Predictive maintenance monitoring

84

ABB

Key Specifications Parameter Specification Output Current 125A Rated Power 55kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Sensorless Vector Control (SLVC) & V/f control Overload 150% for 60 seconds Communication Modbus RTU (RS485) standard Advanced Features ✔ Energy Optimization Technology Automatic load adaptation with up to 50% energy savings ABB's proprietary Adaptive Programming for pumps and fans ✔ Robust Motor Protection I²t thermal overload protection Short-circuit, ground fault, and phase loss protection Motor stall prevention ✔ Intelligent Control Interface LCD keypad with 8 language options Quick start-up wizard with application macros ✔ Process Control Capabilities Built-in PID controller with auto-tuning Customizable acceleration/deceleration ramps ✔ Industrial-Grade Design Compact dimensions: 255 x 245 x 220mm (WxHxD) Wide operating temperature: -10°C to +50°C Forced cooling with temperature-controlled fan Model Number Breakdown ACS510: Series designation 01: IP21 protection level 125A: 125A output current rating 4: 400V voltage class (380-480V)

181

ABB

Key Specifications Parameter Specification Output Current 25A Rated Power 11kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Sensorless Vector Control (SLVC) & V/f control Overload 150% for 60 seconds Communication Modbus RTU (RS485) standard Advanced Features ✔ Energy-Saving Optimization Automatic adaptation to load changes Up to 50% energy reduction in variable torque applications ✔ Comprehensive Motor Protection Thermal overload protection (I²t monitoring) Short-circuit, phase loss, and ground fault protection ✔ User-Friendly Interface LCD keypad with multilingual support (8 languages) Quick start-up wizard for fast commissioning ✔ Integrated Process Control Built-in PID controller for pressure/flow/temperature regulation Customizable application macros ✔ Compact & Robust Design Dimensions: 198 x 145 x 175mm (WxHxD) Operating temperature: -10°C to +50°C Model Number Decoding ACS510: Series name (ABB's general-purpose drives) 01: IP21 enclosure rating 025A: 25A output current 4: 400V voltage class (380-480V)

224

ABB

Technical Specifications Parameter Specification Output Current 72A Rated Power 37kW (400V 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Sensorless Vector Control (SLVC) & V/f control Overload 150% for 60 seconds Communication Modbus RTU (standard), optional fieldbus Key Features ✔ Energy Optimization Automatic adaptation to load changes Energy savings up to 50% in pump/fan applications ✔ Advanced Motor Protection Thermal overload protection (I²t) Short-circuit, ground fault, and phase loss protection ✔ User-Friendly Operation LCD keypad with multilingual interface Quick start-up wizard ✔ Process Control Built-in PID controller Customizable application macros ✔ Compact & Robust Space-saving design (220 x 190 x 195mm) -10°C to +50°C operating range Model Number Breakdown ACS510: Series name 01: IP21 enclosure 072A: 72A output current 4: 400V voltage class

708

ABB

Key Specifications Parameter Specification Output Current 180A Rated Power 90kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Overload 150% for 60 seconds Control Flux-optimized V/f & DTC (Optional) Advanced Features ✔ Dynamic Motor Control - Optional Direct Torque Control (DTC) for superior low-speed performance ✔ Heavy-Duty Design - Industrial-grade components for 24/7 operation ✔ Smart Cooling - Temperature-controlled fan with dust-proof design ✔ Multi-Protocol Support - Built-in Modbus RTU + optional fieldbus cards (PROFIBUS, DeviceNet) ✔ Advanced Sequencing - Built-in PLC functionality with 3 programmable macros Technical Highlights Application-Specific Profiles: Pre-configured for pumps, fans, conveyors, and cranes Harmonic Mitigation: Optional DC choke or line filter available Safety: STO (Safe Torque Off) compliant Environmental: Operates at -15°C to +50°C (with derating) Model Designation ACS550: ABB's industrial drive series 01: IP21 enclosure (NEMA 1 equivalent) 180A: 180A output current 4: 400V voltage class

772

ABB

Key Specifications: Output Current: 46A Rated Power: 22kW (for 400V 4-pole motor) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Enclosure Rating: IP21 (open chassis) Control Methods: Sensorless Vector Control (SLVC) & V/f control Overload Capacity: 150% for 60 seconds Communication Protocol: Built-in Modbus RTU (RS485) Advanced Features: Energy Optimization: Automatic adaptation to load changes for maximum efficiency in variable torque applications Intelligent Motor Protection: Comprehensive safeguards including thermal overload, short-circuit, and phase-loss protection User-Friendly Interface: LCD keypad with multilingual support (8 languages) and quick-start wizard Integrated PID Controller: Enables precise process control for pressure, flow, and temperature regulation Compact Design: Space-efficient footprint for cabinet installation Fieldbus Connectivity: Supports optional PROFIBUS DP and BACnet modules Model Number Decoding: ACS510: Series designation 01: IP21 enclosure type 046A: 46A output current rating 4: 400V voltage class (380-480V)
