ABB

Key Specifications Parameter Specification Output Current 169A Rated Power 75kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%) Overload 150% for 60 seconds Control Method Direct Torque Control (DTC) Efficiency >98% at full load Enclosure IP21 (open chassis) Advanced Features Precision Control: ✔ Ultra-fast torque response (<5ms) ✔ Speed accuracy: ±0.01% of set value ✔ Adaptive motor tuning (AMT) Connectivity: Standard interfaces: Dual Ethernet ports (1Gbps) PROFINET IRT OPC UA server Optional modules: PROFIBUS DP-V2 EtherNet/IP BACnet MS/TP Safety & Protection: Integrated safety functions (STO, SS1, SLS) SIL3/PL e certified Advanced diagnostics with predictive maintenance Mechanical Specifications Dimensions: 350 × 800 × 300mm (W×H×D) Weight: 42kg Cooling: Smart fan control Ambient Temperature: 0°C to +50°C

318

ABB

Core Components ACS800-01-0050-5 Main Drive Unit Power Rating: 37kW (50HP) Output Current: 96A continuous Input Voltage: 3-phase 200-240V AC (-15%/+10%) Control Method: Direct Torque Control (DTC) Overload Capacity: 150% for 60 seconds Efficiency: 97.5% at full load D150 Braking Module Braking Power: 150% of drive rating Peak Capacity: 75kW for 10% duty cycle Dynamic Response: <5ms reaction time E200 High-Resolution Encoder Interface Resolution Support: Up to 24-bit Protocols: EnDat 2.2, Hiperface DSL Update Rate: 250kHz Key System Features Performance Enhancements: ✔ Ultra-Precise Control: ±0.01% speed accuracy with encoder ✔ Advanced Braking: Regenerative energy management ✔ Rapid Deceleration: 200% braking torque capacity ✔ Smart Cooling: Temperature-optimized airflow Technical Specifications: Enclosure Rating: IP21 (NEMA 1) Communication: PROFIBUS DP (standard) Optional EtherNet/IP Safety: STO (Safe Torque Off) certified Dimensions: 350 × 700 × 300mm (W×H×D) Weight: 32kg (complete system)

944

ABB

Core Specifications Drive Unit (ACS800-04-0040-3): Output Power: 40kW (400V) Output Current: 78A continuous Input Voltage: 3-phase 380-415V AC (±10%) Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Efficiency: >97% at full load Switching Frequency: 1-12kHz (adjustable) P901 Control Panel: 7" color touchscreen display Multi-language interface (12 languages) Built-in web server for remote monitoring 8GB data logging capacity USB port for configuration backup Key System Features Advanced Control: ✔ Precision Regulation: ±0.1% speed accuracy ✔ Application Macros: 8 pre-programmed configurations ✔ Process Control: Built-in PID with auto-tuning ✔ Energy Optimization: Adaptive motor control Connectivity: Standard interfaces: PROFIBUS DP Modbus RTU Ethernet Optional fieldbus modules available Safety & Protection: Safe Torque Off (STO) - SIL3 certified Motor thermal protection Ground fault monitoring DC bus overvoltage protection Mechanical Specifications Enclosure: IP21 (NEMA 1) Cooling: Forced air with temperature control Dimensions: 300 × 600 × 250mm (W×H×D) Weight: 25kg (complete system)

127

ABB

Core Specifications Drive Unit (ACS800-04P-0320-3): Output Power: 320kW (400V) Output Current: 620A continuous Input Voltage: 3-phase 380-415V AC (±10%) Overload Capacity: 150% for 60 seconds 200% for 3 seconds Control Technology: Direct Torque Control (DTC) Efficiency: 98.2% at full load Switching Frequency: 1-3kHz (adjustable) P901 Control Panel: 7" high-brightness TFT touchscreen Multi-language HMI (16 languages) Integrated web server (HTTP/HTTPS) 16GB data logging capacity USB 3.0 configuration port Real-time clock with battery backup Key System Features Advanced Performance: ✔ Ultra-Precise Control: ±0.05% speed accuracy ✔ Adaptive Control: 12 application-specific macros ✔ Process Optimization: Dual PID controllers with fuzzy logic ✔ Harmonic Mitigation: <3% THID with active front end option Connectivity: Standard interfaces: PROFINET IRT (2 ports) EtherNet/IP OPC UA over TCP/IP Optional modules: PROFIBUS DP-V2 BACnet MS/TP Modbus TCP Safety Systems: SIL3 certified safety functions: Safe Torque Off (STO) Safe Stop 1 (SS1) Safe Speed Monitor (SSM) Redundant safety circuits Automatic self-test routines Mechanical Specifications Enclosure: IP21 (NEMA 1) Cooling System: Smart cooling with dual fans Dimensions: 550 × 900 × 400mm (W×H×D) Weight: 98kg (complete system) Noise Level: <65dB at 1m

949

ABB

Key Specifications Parameter Specification Continuous Power 44kW Peak Power 88kW (10% duty cycle) DC Link Voltage 510-780V DC Current Rating 85A continuous Enclosure Rating IP20 (cabinet-mounted) Cooling Method Forced air with temperature control Protection Class I (with PE terminal) Technical Features ✔ Advanced Braking Control Automatic current limitation Adaptive braking torque regulation Pre-charge circuit for safe startup ✔ Monitoring & Protection Thermal overload protection (Class 10) Short-circuit and overvoltage protection Fault relay output (NO/NC contacts) LED status indicators (power, active, fault) ✔ Robust Construction Industrial-grade power components Coated PCB for harsh environments DIN rail compatible mounting Dimensions: 310 × 225 × 210mm (W×H×D) Weight: 9.2kg Compatibility Designed for use with: ACS580 series drives ACS880 multi-drive systems ACQ800 process drives Requires external braking resistor (not included) Certifications & Compliance CE marked (EMC Directive 2014/30/EU) Low Voltage Directive 2014/35/EU RoHS 3 (2015/863/EU) UL recognized component Installation Requirements Minimum clearance: 100mm sides, 150mm above Ambient temperature: Operation: 0°C to +50°C (derating above +40°C) Storage: -40°C to +85°C Relative humidity: 5-95% non-condensing Altitude: ≤1000m (derating required above) Ordering Information Package Includes: APBU-44CE braking unit Mounting bracket set Terminal covers Installation manual (3BHE041543R0001)

996

ABB

Key Specifications Parameter Specification Compatibility ACS800, ACS880, ACQ800 series drives Protocols PROFIBUS DP-V1, Modbus RTU, CANopen Data Rate Up to 12Mbps (PROFIBUS) Isolation 1500V AC reinforced isolation Power Supply 24V DC (±10%) Enclosure IP20 (for cabinet mounting) Operating Temp -25°C to +70°C Technical Features ✔ Multi-Protocol Support Simultaneous protocol operation Automatic baud rate detection Parameter mapping for all major ABB drives ✔ Advanced Diagnostics LED status indicators for all channels Built-in error logging Signal quality monitoring ✔ Robust Design Industrial-grade components DIN rail mounting EMC compliant to EN 61800-3

272

ABB

Core Specifications Drive Unit (ACS800-04-0210-3): Output Power: 210kW (400V) Output Current: 410A continuous Input Voltage: 3-phase 380-415V AC (-15%/+10%) Overload Capacity: 150% for 60 seconds Control Method: Direct Torque Control (DTC) Efficiency: >98% at full load P901 Control Panel: 7" color touchscreen display Multi-language interface (12 languages) Built-in web server for remote monitoring Data logging capacity: 8GB Integrated USB port for configuration backup Key System Features Advanced Control: ✔ Precision Regulation: ±0.1% speed accuracy ✔ Adaptive Programming: 8 application-specific macros ✔ Process Control: Built-in PID with auto-tuning Connectivity: Standard interfaces: PROFIBUS DP Modbus RTU Ethernet/IP Optional fieldbus modules available Safety & Protection: STO (Safe Torque Off) - SIL3 certified Motor thermal protection Ground fault monitoring DC bus overvoltage protection Mechanical Specifications Enclosure: IP21 (NEMA 1) Cooling: Forced air with temperature control Dimensions: 450 x 800 x 350mm (WxHxD) Weight: 65kg (complete system)

827

ABB

Key Specifications Parameter Specification Rated Power 44kW continuous Peak Power 88kW for 10% duty cycle DC Voltage 510-780V DC Current Rating 85A continuous Enclosure IP20 (cabinet-mounted) Cooling Forced air (built-in fan) Protection Over-temperature, over-current Technical Features ✔ Compact Design Dimensions: 300 x 220 x 200mm (WxHxD) Weight: 8.5kg ✔ Advanced Protection Automatic thermal monitoring Short-circuit protection Status relay outputs ✔ Easy Integration Direct connection to ABB drives Standard screw terminals LED status indicators Compatibility Designed for use with: ACS580 series drives ACS880 series drives Other ABB drives with external braking capability

870

ABB

Technical Specifications Power Characteristics: Output Current: 800A continuous Rated Power: 440kW (400V configuration) Input Voltage: 3-phase 380-500V AC (-15%/+10%) Overload Capacity: 110% continuous, 150% for 60s Control & Performance: Control Method: Direct Torque Control (DTC) Speed Accuracy: ±0.01% of base speed Torque Response: <5ms Efficiency: >98% at full load System Configuration: P901 Option: Includes advanced process controller with: Dual-channel safety system (SIL3/PL e) Multi-axis synchronization capability Integrated PLC functionality (IEC 61131-3) Key Features Advanced Control: ✔ Process Perfect technology for critical applications ✔ Adaptive programming for pumps/compressors ✔ Harmonic mitigation (<3% THD with active front end) Connectivity: Standard interfaces: 2x PROFINET IRT (TSN-ready) OPC UA over TCP/IP Embedded web server Optional fieldbus modules available Mechanical Design: Enclosure: IP00 (cabinet installation required) Cooling: Liquid/air hybrid cooling system Dimensions: 800 x 2000 x 600mm (WxHxD) Weight: 320kg (base unit)

421

ABB

Key Specifications Parameter Specification Output Current 9A Rated Power 2.2kW (3HP) at 230V Input Voltage 3-phase 200-240V AC (-15%/+10%), 50/60Hz Enclosure IP20 (NEMA 1 equivalent) Control Methods Sensorless Vector Control (V/f) Overload 150% for 60 seconds Communication Modbus RTU via RJ45 port Key Features ✔ Compact Design - Ultra-small footprint (132 x 150 x 150mm) ✔ Simple Operation - Basic keypad with LED display ✔ Motor Protection - Built-in thermal overload protection ✔ Quick Setup - 5-parameter quick start function ✔ EMC Compliance - Meets EN 61800-3 Category C2 Model Identification ACS180: Series name 04N: 230V input voltage class 06A9: 9A output current (3HP rating) 1: Standard control panel version

684

ABB

Key Specifications Parameter Specification Output Current 39A Rated Power 15kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Flux-optimized V/f & DTC (Sensorless Vector) Overload 150% for 60 seconds Communication Modbus RTU (RS485) standard Advanced Features ✔ Energy Optimization - Adaptive control reduces energy consumption by 20-50% ✔ Intuitive Operation - ABB Assist Panel with plain-text parameter interface ✔ Built-in Safety - Safe Torque Off (STO) function (SIL3/PL e certified) ✔ Smart Cooling - Temperature-controlled fan with low noise operation ✔ Fieldbus Ready - Optional PROFIBUS DP, BACnet, Ethernet/IP adapters ✔ Robust Protection - Motor thermal, short-circuit, and phase-loss protection Model Identification ACS580: Series name 01: IP21 enclosure rating 039A: 39A output current 4: 400V voltage class (380-480V)

114

ABB

Key Specifications Parameter Specification Output Current 9.5A Rated Power 4kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%), 50/60Hz Enclosure IP21 (open chassis) Control Methods Flux-optimized V/f & DTC (Sensorless Vector) Overload 150% for 60 seconds Communication Modbus RTU (RS485) standard Advanced Features ✔ Energy Saving Technology - Adaptive control reduces energy consumption by up to 30% ✔ User-Friendly Interface - ABB Assist Panel with plain-text parameter display ✔ Compact Design - Space-saving dimensions (190 x 195 x 175mm) ✔ Integrated Safety - Safe Torque Off (STO) function (SIL3/PL e) ✔ Smart Cooling - Temperature-controlled fan operation ✔ Fieldbus Connectivity - Optional PROFIBUS DP, BACnet, Ethernet/IP adapters Model Identification ACS580: Series designation 01: IP21 enclosure rating 09A5: 9.5A output current (4kW power class) 4: 400V voltage class (380-480V)

657
