ABB

Core Specifications Drive Unit (ACS800-01-0016-3): Output Power: 11kW (15HP) at 400V Output Current: 24A continuous Input Voltage: 3-phase 380-480V AC (±10%) Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Efficiency: >97% at full load Switching Frequency: 1-12kHz (adjustable) P901 Control Panel: 7" high-brightness color touchscreen Multi-language interface (12 languages) Built-in web server for remote monitoring 8GB data logging capacity USB port for configuration backup Real-time clock with battery backup Key System Features Advanced Control: ✔ Precision Regulation: ±0.1% speed accuracy ✔ Application Macros: 8 pre-programmed configurations ✔ Process Control: Built-in PID with auto-tuning ✔ Energy Optimization: Adaptive motor control algorithm Connectivity: Standard Interfaces: PROFIBUS DP Modbus RTU (RS485) Ethernet Optional Modules: PROFINET IRT EtherNet/IP BACnet MS/TP Safety & Protection: Integrated Safety: Safe Torque Off (STO) - SIL3 certified Safe Stop 1 (SS1) Protection Features: Motor thermal protection Ground fault monitoring DC bus overvoltage protection Mechanical Specifications Enclosure Rating: IP21 (NEMA 1) Cooling System: Temperature-controlled fan Dimensions: 250 × 500 × 220mm (W×H×D) Weight: 18kg (complete system) Noise Level: <58dB at 1m

398

ABB

Core Specifications 1. ACS800-01-0040-3 Drive Unit Output Power: 30kW (400V) Output Current: 60A continuous Input Voltage: 3-phase 380-480V AC (±10%) Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Efficiency: 97.5% at full load 2. D150 Braking Module Braking Capacity: 150% of drive rating Peak Power: 45kW (10% duty cycle) Response Time: <2ms 3. P901 Control Panel 7" high-resolution color touchscreen Multi-language interface (16 languages) Integrated web server functionality 16GB data logging capacity USB 3.0 configuration port Key System Features Performance Enhancements: ✔ Precision Control: ±0.05% speed accuracy ✔ Rapid Deceleration: 200% braking torque capacity ✔ Process Optimization: Dual PID controllers with auto-tuning ✔ Energy Recovery: Regenerative braking capability Connectivity & Integration: Standard Interfaces: PROFIBUS DP Modbus RTU Ethernet Optional Modules: PROFINET IRT EtherNet/IP OPC UA Safety Systems: Safe Torque Off (STO) - SIL3 certified Safe Stop 1 (SS1) Safe Speed Monitor (SSM) Automatic self-diagnostics Physical Specifications Enclosure Rating: IP21 (NEMA 1) Dimensions: 350 × 700 × 250mm (W×H×D) Weight: 28kg (complete system) Cooling: Smart temperature-controlled fans Noise Level: <60dB at 1m

981

ABB

Key Specifications Parameter Specification Output Current 32A Rated Power 15kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%) Overload 150% for 60 seconds Control Method Direct Torque Control (DTC) Efficiency >98% at full load Enclosure IP21 (open chassis) Advanced Features Precision Control: ✔ Ultra-fast torque response (<5ms) ✔ Speed accuracy: ±0.01% of set value ✔ Adaptive motor tuning (AMT) ✔ Automatic energy optimization Connectivity: Standard interfaces: Dual Ethernet ports (1Gbps) PROFINET IRT Modbus RTU (RS485) Optional modules: PROFIBUS DP-V2 EtherNet/IP BACnet MS/TP Safety & Protection: Integrated safety functions (STO, SS1, SLS) SIL3/PL e certified Advanced diagnostics with predictive maintenance Motor thermal protection Mechanical Specifications Dimensions: 250 × 600 × 220mm (W×H×D) Weight: 15kg Cooling: Smart fan control Ambient Temperature: 0°C to +50°C Relative Humidity: 5-95% non-condensing

96

ABB

Core Specifications Drive Unit (ACS800-01-0060-3): Output Power: 45kW (60HP) at 400V Output Current: 90A continuous Input Voltage: 3-phase 380-480V AC (±10%) Overload Capacity: 150% for 60 seconds 200% for 3 seconds Control Technology: Direct Torque Control (DTC) Efficiency: 97.5% at full load Switching Frequency: 1-8kHz (adjustable) P901 Control Panel: 7" high-brightness color touchscreen Multi-language interface (14 languages) Integrated web server with remote monitoring 16GB data storage capacity USB 3.0 configuration port Real-time clock with battery backup Key System Features Advanced Performance: ✔ Precision Control: ±0.05% speed accuracy ✔ Adaptive Programming: 12 application macros ✔ Process Optimization: Dual PID controllers ✔ Energy Management: Power consumption monitoring Connectivity: Standard Interfaces: PROFINET IRT Modbus RTU (RS485) Ethernet/IP Optional Modules: PROFIBUS DP-V2 BACnet MS/TP OPC UA Safety Systems: SIL3 certified safety functions: Safe Torque Off (STO) Safe Stop 1 (SS1) Safe Speed Monitor (SSM) Automatic self-diagnostics Mechanical Specifications Enclosure: IP21 (NEMA 1) Cooling System: Smart temperature-controlled fans Dimensions: 350 × 750 × 300mm (W×H×D) Weight: 32kg (complete system) Noise Level: <63dB at 1m

218

ABB

Core Specifications Drive Unit (ACS800-01-0016-5): Output Power: 11kW (15HP) at 200V Output Current: 39A continuous Input Voltage: 3-phase 200-240V AC (±10%) Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Efficiency: >97% at full load Switching Frequency: 1-12kHz (adjustable) P901 Control Panel: 7" color touchscreen display Multi-language interface (12 languages) Built-in web server for remote monitoring 8GB data logging capacity USB port for configuration backup Key System Features Advanced Control: ✔ Precision Regulation: ±0.1% speed accuracy ✔ Application Macros: 8 pre-programmed configurations ✔ Process Control: Built-in PID with auto-tuning ✔ Energy Optimization: Adaptive motor control Connectivity: Standard interfaces: PROFIBUS DP Modbus RTU Ethernet Optional fieldbus modules available Safety & Protection: Safe Torque Off (STO) - SIL3 certified Motor thermal protection Ground fault monitoring DC bus overvoltage protection Mechanical Specifications Enclosure: IP21 (NEMA 1) Cooling: Forced air with temperature control Dimensions: 250 × 500 × 220mm (W×H×D) Weight: 18kg (complete system)

880

ABB

Core Specifications 1. ACS800-01-0120-3 Drive Unit Output Power: 90kW (400V) Output Current: 180A continuous Input Voltage: 3-phase 380-480V AC (±10%) Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Efficiency: 97.8% at full load 2. D150 Braking Module Braking Capacity: 150% of drive rating Peak Power: 135kW (10% duty cycle) Response Time: <2ms 3. P901 Control Panel 7" high-resolution color touchscreen Multi-language interface (16 languages) Integrated web server functionality 16GB data logging capacity USB 3.0 configuration port Key System Features Performance Enhancements: ✔ Precision Control: ±0.05% speed accuracy ✔ Rapid Deceleration: 200% braking torque capacity ✔ Process Optimization: Dual PID controllers with auto-tuning ✔ Energy Recovery: Regenerative braking capability Connectivity & Integration: Standard Interfaces: PROFIBUS DP Modbus RTU Ethernet Optional Modules: PROFINET IRT EtherNet/IP OPC UA Safety Systems: Safe Torque Off (STO) - SIL3 certified Safe Stop 1 (SS1) Safe Speed Monitor (SSM) Automatic self-diagnostics Physical Specifications Enclosure Rating: IP21 (NEMA 1) Dimensions: 450 × 900 × 350mm (W×H×D) Weight: 55kg (complete system) Cooling: Smart temperature-controlled fans Noise Level: <65dB at 1m

357

ABB

Key Specifications Parameter Specification Output Current 61A Rated Power 30kW (400V, 4-pole motor) Input Voltage 3-phase 380-480V AC (±10%) Overload 150% for 60 seconds Control Method Direct Torque Control (DTC) Efficiency >98% at full load Enclosure IP21 (open chassis) Advanced Features Precision Control: ✔ Ultra-fast torque response (<5ms) ✔ Speed accuracy: ±0.01% of set value ✔ Adaptive motor tuning (AMT) ✔ Automatic energy optimization Connectivity: Standard interfaces: Dual Ethernet ports (1Gbps) PROFINET IRT Modbus RTU (RS485) Optional modules: PROFIBUS DP-V2 EtherNet/IP BACnet MS/TP Safety & Protection: Integrated safety functions (STO, SS1, SLS) SIL3/PL e certified Advanced diagnostics with predictive maintenance Motor thermal protection Mechanical Specifications Dimensions: 300 × 700 × 250mm (W×H×D) Weight: 22kg Cooling: Smart fan control Ambient Temperature: 0°C to +50°C Relative Humidity: 5-95% non-condensing

916

ABB

Core Components 1. ACS800-104-0030-3 Drive Unit Output Power: 30kW (400V) Output Current: 60A continuous Input Voltage: 3-phase 380-480V AC (±10%) Overload Capacity: 150% for 60 seconds Control Method: Direct Torque Control (DTC) Efficiency: >97% at full load 2. N664 Control Panel LCD display with backlight Multilingual interface (8 languages) USB port for parameter transfer Status LEDs for quick diagnostics IP54 protection rating (front panel) Key Features Performance: ✔ Precise Speed Control: ±0.1% speed regulation ✔ Adaptive Programming: 5 application macros ✔ Energy Optimization: Automatic motor adaptation ✔ Fast Response: <5ms torque response time Connectivity: Built-in Modbus RTU (RS485) Optional fieldbus modules: PROFIBUS DP DeviceNet CANopen Protection: Motor thermal protection Short-circuit protection Phase loss detection Ground fault monitoring Mechanical Specifications Enclosure: IP21 (main unit), IP54 (panel) Dimensions: 300 × 500 × 250mm (W×H×D) Weight: 18kg (complete system) Cooling: Temperature-controlled fan Ambient Temperature: 0°C to +40°C

465

ABB

Core Specifications Drive Module (ACS800-04-0610-7): Output Power: 610kW (400V configuration) Output Current: 1180A continuous Input Voltage: 3-phase 380-500V AC (±10%) Overload Capacity: 110% continuous 150% for 60 seconds Control Method: Direct Torque Control (DTC) Efficiency: 98.5% at full load Switching Frequency: 1-3kHz (adjustable) P901 Control Panel: 10" high-brightness industrial touchscreen Multi-language interface (20 languages) Integrated web server with secure remote access 64GB data logging capacity Dual USB 3.1 configuration ports Real-time predictive maintenance functions Key System Features Advanced Performance: ✔ Ultra-Precise Control: ±0.01% speed accuracy ✔ Adaptive Control: 20 application-specific macros ✔ Process Optimization: Quad PID controllers with AI tuning ✔ Harmonic Mitigation: <3% THD with active front end Connectivity & Integration: Standard Interfaces: 4× 1Gbps Ethernet ports (PROFINET IRT, EtherNet/IP) OPC UA over TCP/IP IEC 61850 protocol support Optional Modules: PROFIBUS DP-V2 BACnet MS/TP Wireless LAN module Safety Systems: SIL3/PL e certified safety functions: Safe Torque Off (STO) Safe Stop 1 (SS1) Safe Speed Monitor (SSM) Safe Brake Control (SBC) Redundant safety processors Continuous self-monitoring Mechanical Specifications Enclosure: IP21 (cabinet-mounted) Cooling System: Liquid-assisted forced air cooling Dimensions: 800 × 2200 × 600mm (W×H×D) Weight: 450kg (complete system) Noise Level: <70dB at 1m Cooling Airflow: 3000m³/hr

326

ABB

Core Specifications Drive Unit (ACS800-04P-0170-3): Output Power: 170kW (400V) Output Current: 330A continuous Input Voltage: 3-phase 380-415V AC (±10%) Overload Capacity: 150% for 60 seconds 200% for 3 seconds Control Technology: Direct Torque Control (DTC) Efficiency: 98.1% at full load Switching Frequency: 1-5kHz (adjustable) P901 Control Panel: 7" high-brightness color touchscreen Multi-language HMI interface (14 languages) Integrated web server with remote monitoring 16GB non-volatile data storage USB 3.0 configuration port Real-time clock with battery backup Key System Features Advanced Performance: ✔ Precision Control: ±0.05% speed accuracy ✔ Adaptive Programming: 12 application macros ✔ Process Optimization: Dual PID controllers with fuzzy logic ✔ Energy Management: Power consumption monitoring (kWh/MWh) Connectivity: Standard Interfaces: PROFINET IRT (2 ports) EtherNet/IP OPC UA over TCP/IP Optional Modules: PROFIBUS DP-V2 BACnet MS/TP Modbus TCP Safety Systems: SIL3 certified safety functions: Safe Torque Off (STO) Safe Stop 1 (SS1) Safe Speed Monitor (SSM) Redundant safety circuits Automatic self-diagnostics Mechanical Specifications Enclosure: IP21 (NEMA 1) Cooling System: Smart cooling with temperature-controlled fans Dimensions: 450 × 850 × 350mm (W×H×D) Weight: 72kg (complete system) Noise Level: <63dB at 1m

894

ABB

Core Specifications Drive Module (ACS800-04M-0210-3): Output Power: 210kW (400V configuration) Output Current: 410A continuous Input Voltage: 3-phase 380-500V AC (±10%) Overload Capacity: 110% continuous 150% for 60 seconds Control Method: Direct Torque Control (DTC) Efficiency: 98.3% at full load P901 Control Panel: 7" high-resolution TFT touchscreen Multi-language interface (18 languages) Integrated web server with HTTPS security 32GB data logging capacity USB 3.0 configuration port Key System Features Advanced Performance: ✔ Ultra-Precise Control: ±0.02% speed accuracy ✔ Adaptive Programming: 16 application macros ✔ Process Optimization: Triple PID controllers ✔ Harmonic Mitigation: <3% THD with active front end Connectivity & Integration: Standard Interfaces: 2× PROFINET IRT (TSN-ready) OPC UA Pub/Sub EtherNet/IP Optional Modules: PROFIBUS DP-V2 BACnet MS/TP Modbus TCP Safety Systems: Integrated Safety: Safe Torque Off (STO) - SIL3/PL e Safe Stop 1 (SS1) Safe Limited Speed (SLS) Redundant Safety Circuits Automatic Self-Testing Mechanical Specifications Enclosure: IP21 (cabinet-mounted) Cooling System: Liquid/air hybrid cooling Dimensions: 500 × 1000 × 400mm (W×H×D) Weight: 85kg (complete system) Noise Level: <62dB at 1m

418

ABB

Core Components ACS800-01-0070-3 Main Drive Unit Output Power: 55kW (75HP) at 380V Output Current: 112A continuous Input Voltage: 3-phase 380-415V AC (±10%) Control Technology: Direct Torque Control (DTC) Overload Capacity: 150% for 60 seconds D150 Dynamic Braking Unit Braking Capacity: 150% of drive rating Peak Power: 110kW for 10% duty cycle Response Time: <2ms P901 Advanced Control Panel 7" color touchscreen HMI Multi-language interface (16 languages) Integrated web server functionality 16GB data logging capacity Key System Features Performance Enhancements: ✔ Precision Regulation: ±0.05% speed accuracy ✔ Rapid Deceleration: 200% braking torque capacity ✔ Process Optimization: Dual PID controllers with auto-tuning ✔ Energy Recovery: Regenerative braking capability Technical Specifications: Enclosure Rating: IP21 (NEMA 1) Communication Protocols: PROFIBUS DP (standard) PROFINET IRT (optional) OPC UA over Ethernet Safety Systems: Safe Torque Off (STO) - SIL3 certified Safe Stop 1 (SS1) Safe Speed Monitor (SSM) Physical Specifications: Dimensions: 400 × 900 × 350mm (W×H×D) Weight: 48kg (complete system) Cooling: Smart temperature-controlled fans Noise Level: <68dB at 1m

33
