Key Specifications Power Rating: 5.5 kW (7.5 HP) Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz Output Current: 12 A Overload Capacity: 110% for 60s, 150% for 3s Control Method: Scalar (V/f) & Sensorless Vector Control (optional) Switching Frequency: 1–16 kHz (adjustable) Efficiency: >97% Main Features ✔ Energy-Saving Operation Automatic Energy Optimizer reduces motor losses Sleep/Wake function for pump & fan applications ✔ Built-in Application Macros Pre-configured settings for pumps, fans, and constant torque applications PID controller for pressure/flow control ✔ Protection & Safety Motor thermal protection (PTC input) Short-circuit, overvoltage, and ground fault protection IP21 enclosure (basic dust protection) ✔ Connectivity & Control Standard RS485 (Modbus RTU) 2 analog inputs (0–10V/4–20mA), 3 digital inputs, 1 relay output Optional fieldbus adapters (Profibus, BACnet, etc.) ✔ User-Friendly Interface Integrated control panel with LED display Quick start-up wizard for easy commissioning Physical & Environmental Specifications Enclosure Rating: IP21 (open chassis) Cooling Method: Convection cooling (fanless design) Ambient Temperature: -10°C to +50°C (14°F to 122°F) Dimensions (W×H×D): 150 × 200 × 165 mm Weight: 2.1 kg

247

ABB

Key Specifications Power Rating: 500 kW (670 HP) Input Voltage: 3-phase 380–500V AC (±10%), 50/60 Hz Output Current: 850 A Overload Capacity: 110% continuous, 150% for 60s Control Method: Sensorless Vector Control (DTC option available) Efficiency: >98% Switching Frequency: Adjustable (2–8 kHz) Main Features ✔ Advanced Motor Control Sensorless vector control for precise speed regulation Automatic motor adaptation (AMA) for optimal performance Flying start and torque boost functions ✔ Built-in Application Macros Pre-programmed settings for pumps, fans, conveyors, and compressors Customizable logic with PID controller (for pressure/flow control) ✔ Protection & Safety Motor thermal protection (PTC/KTY support) Short-circuit, overvoltage, and ground fault protection Safe Torque Off (STO) for emergency stop compliance ✔ Connectivity & Communication Standard RS485 (Modbus RTU) Optional fieldbus modules (Profibus, Ethernet/IP, Modbus TCP) ABB Drive Composer software for easy configuration ✔ User-Friendly Interface Integrated keypad with LCD display Quick setup with assisted startup wizard Parameter backup via USB Physical & Environmental Specifications Enclosure Rating: IP21 (open chassis) Cooling Method: Forced air cooling (fans included) Ambient Temperature: 0–40°C (32–104°F) without derating Dimensions (W×H×D): 800 × 1800 × 400 mm Weight: Approx. 200 kg

988

ABB

Technical Specifications: Main Drive Unit (ACS880-04-725A-3): Power Rating: 725 kW (971 HP) Input Voltage: 3-phase 380-500V AC (-15%/+10%) Output Current: 1040 A Overload Capacity: 110% continuous, 150% for 60s Control Technology: DTC (Direct Torque Control) Efficiency: >98.5% Switching Frequency: 1-4 kHz (adjustable) D150 Control Panel Features: 7" color touchscreen display Multilingual interface (20+ languages) Real-time process monitoring Built-in trend recorder Password protection levels USB port for parameter transfer Key System Features: Advanced Control Capabilities: Sensorless vector control (SLVC) Encoderless speed control (±0.1% accuracy) Torque control mode (±2% accuracy) Adaptive programming capability Application-Specific Functions: Multiple application macros Customizable logic functions Built-in safety functions (STO, SS1, SLS) Advanced PID controller Protection & Monitoring: Motor thermal protection (PTC/KTY84) Ground fault detection Input phase monitoring DC link monitoring IGBT temperature monitoring Communication Interfaces: Standard: Modbus RTU (RS485) Ethernet Optional: PROFIBUS DP PROFINET EtherNet/IP CANopen Physical Specifications: Drive Dimensions: 900 × 2200 × 600 mm (W×H×D) Control Panel Dimensions: 210 × 170 × 60 mm Weight: 320 kg (drive only) Cooling: Liquid cooling system Ambient Temperature: 0-40°C (32-104°F) Certifications & Compliance: CE UL cULus DNV GL IEC 61800-3 ISO 13849-1 (PL e)

353

ABB

Technical Specifications: Power Rating: 2.2 kW (3 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 5.2 A Overload Capacity: 150% for 60 seconds Control Technology: DTC (Direct Torque Control) Encoder Interface: N671 module for incremental encoders Key Features: Precision Control: Closed-loop vector control with encoder feedback ±0.01% speed accuracy (with encoder) 0.1 Hz speed control range Encoder Module (N671): Supports 5V/24V incremental encoders Resolution up to 4096 ppr Differential (RS422) and single-ended inputs LED status indicators

702

ABB

Technical Specifications: Power Rating: 37 kW (50 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 65 A Overload Capacity: 150% for 60 seconds Control Technology: DTC (Direct Torque Control) Frequency Range: 0-500 Hz Efficiency: >98% Key Features: Advanced Control Capabilities: Sensorless vector control Automatic motor adaptation Torque control mode Flying start function Application-Specific Functions: Built-in PID controller Pump and fan control curves Multiple preset macros Custom application programming Protection Systems: Motor thermal protection Short circuit protection Ground fault detection Input phase monitoring Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 2 relay outputs 1 analog output (0/4-20mA) Communication: RS485 (Modbus RTU standard) Optional fieldbus adapters available Physical Characteristics: Enclosure: IP21 (open chassis) Dimensions: 350 × 482 × 227 mm (W × H × D) Weight: 18.5 kg Cooling: Forced air cooling Ambient Temperature: 0-40°C (32-104°F) without derating

755

ABB

Technical Specifications: Power Rating: 7.5 kW (10 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 18 A Overload Capacity: 150% for 60 seconds Control Method: Sensorless vector control (DTC) Frequency Range: 0-500 Hz Efficiency: >97.5% Key Features: Advanced Motor Control: Automatic motor adaptation (AMA) Torque boost function Flying start capability Application Macros: Factory preset configurations (pump, fan, conveyor) Customizable application programs Built-in PID controller Protection Features: Motor thermal protection (PTC input) Short circuit protection Ground fault detection Overvoltage/undervoltage protection Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output 1 analog output (0/4-20mA) Communication: RS485 (Modbus RTU standard) Optional fieldbus adapters available Physical Characteristics: Enclosure: IP20 (open chassis) Dimensions: 198 × 245 × 195 mm (W × H × D) Weight: 4.2 kg Cooling: Convection cooling Ambient Temperature: 0-40°C (32-104°F) without derating

137

ABB

Core Parameters: Model: ACS800-104-0510-3+E205+V991 Power: 15kW/20HP Input: 3PH 380-480VAC, 50/60Hz Output: 31A, 0-480V Control: DTC technology Overload: 150% for 60s Options Included: E205: +4AI(2x0-10V/2x4-20mA), +4DI, +2RO, +1AO(0-20mA) V991: Parameter backup module Protection: IP21, built-in EMC filter Motor thermal/ground fault/short circuit protection Comms: Modbus RTU standard Fieldbus options available Dimensions: 245×482×227mm (W×H×D) Weight: 12.5kg Certifications: CE/UL/cULus/RoHS

521

ABB

Technical Specifications: Power Rating: 1.1 kW (1.5 HP) Input Voltage: 3-phase: 380-480V AC ±10% Frequency: 48-63 Hz Output Current: 3.0 A Overload Capacity: 150% for 60 seconds Brake Chopper: Integrated (P901 option) Control Technology: DTC (Direct Torque Control) Key Features: Advanced Motor Control: Sensorless vector control Automatic motor adaptation (AMA) Flying start function Application Macros: Factory preset configurations Customizable application programs PID controller with sleep/wake function Protection Features: Motor thermal protection Short circuit protection Ground fault detection Overvoltage/undervoltage protection Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output 1 analog output Communication: Modbus RTU (standard) Optional fieldbus adapters available Physical Characteristics: Enclosure: IP21 (open chassis) Cooling Method: Convection cooling Ambient Temperature: 0-40°C without derating Mounting Options: Wall or DIN rail mounting

632

ABB

Technical Specifications: Power Rating: 0.75 kW (1 HP) Input Voltage: 3-phase: 200-240V AC (-15%/+10%) 1-phase: 200-240V AC (-15%/+10%) Output Current: 3.6 A Overload Capacity: 150% for 60 seconds Brake Chopper: Integrated (P901 option) Switching Frequency: 1-12 kHz (adjustable) Key Features: ✔ Advanced Control Modes: DTC (Direct Torque Control) technology Scalar control (V/f) mode Customizable torque curves ✔ Application-Specific Features: Pump and fan control macros PID controller with sleep/wake function Flying start capability ✔ Protection Functions: Motor thermal protection Short circuit protection Ground fault detection Overvoltage/undervoltage protection Standard Interfaces: Control Terminals: 2 analog inputs (0-10V/4-20mA) 3 digital inputs 1 relay output 1 analog output Communication Options: Modbus RTU (standard) Optional fieldbus adapters (Profibus, DeviceNet) Physical Characteristics: Enclosure: IP21 (open chassis) Cooling: Convection cooling Ambient Temperature: 0-40°C (32-104°F) without derating Mounting: Wall or DIN rail mounting

844

ABB

Key Specifications: Power Rating: 6.6 kW continuous output Input Voltage: 3-phase 200-480V AC (±10%) Output Current: 26 A peak (model-specific) Control Technology: Field-oriented vector control Feedback Interface: Supports absolute/incr. encoders (20-bit+ resolution) Communication Protocols: EtherCAT (IEEE 1588 time sync) PROFINET RT/IRT CANopen DS402 Technical Features: ✓ Advanced Control Algorithms: Adaptive vibration suppression Anti-resonance filtering Torque ripple compensation ✓ Safety Functions: STO (Safe Torque Off) SIL3/PLe SS1/SS2 Safe Stop SLS Safe Limited Speed

181

ABB

Key Features: Rated Voltage: 12 kV (or as specified; confirm based on regional standards). Breaking Capacity: High short-circuit interruption (e.g., 20–25 kA). Technology: Vacuum interrupter for arc-free switching and long service life. Operation: Spring-operated or motor-driven mechanism (dependent on model). Protection Functions: Overcurrent, earth fault, and customizable relay logic (if equipped with digital controls). Standards Compliance: IEC 62271, ANSI C37.04 (global certifications).

602

ABB

Core Components ACS800-01-0025-3 Drive Unit Power: 25kW (33HP) Current: 45A Voltage: 380-480V AC (±10%) Control: Direct Torque Control (DTC) Enclosure: IP21 (NEMA 1) E200 DC Reactor Inductance: 2.5mH Current: 50A Function: Reduces harmonics & improves power factor P901 Mounting Kit Cabinet Material: Powder-coated steel Cooling: Forced ventilation Protection: IP21 when installed P915 Operator Panel Display: Backlit LCD Keypad: IP54 protection Functions: Start/stop, parameter adjustment, diagnostics Key Features ✔ Complete Plug-and-Play Solution - Ready for cabinet installation ✔ Enhanced Power Quality - With integrated DC reactor ✔ User-Friendly Operation - Full-featured control panel ✔ Space-Efficient Design - Optimized cabinet layout Technical Specifications Dimensions (installed): 600 × 400 × 300mm (H×W×D) Weight: 35kg (complete system) Ambient Temperature: 0-40°C Certifications: CE, UL, cUL, RoHS
