ABB

Key Specifications ✔ Power Rating: 4 kW (5 HP) ✔ Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz ✔ Output Current: 9.5 A ✔ Overload Capacity: 150% for 3 seconds ✔ Control Method: Sensorless Vector Control (DTC option available) ✔ Switching Frequency: 2–16 kHz (adjustable) ✔ Efficiency: >97% Main Features 1. Advanced Motor Control Direct Torque Control (DTC) for precise speed regulation (±0.5% accuracy) Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback Torque boost & flying start – ensures smooth operation under load 2. Application Flexibility Pre-programmed macros (pump, fan, conveyor) for quick setup Built-in PID controller for process control (pressure, flow, temperature) Customizable logic via free function blocks 3. Protection & Safety Motor thermal protection (PTC/KTY input) Short-circuit, overvoltage, and ground fault protection Safe Torque Off (STO) – SIL3/PL e safety compliance 4. Connectivity & Control Standard RS485 (Modbus RTU) 2 analog inputs (0–10V/4–20mA), 4 digital inputs, 1 relay output Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen) 5. Compact & Robust Design IP20 enclosure (dust protected) Optional IP66/NEMA 4X kit for harsh environments Built-in EMC filter (Class A compliance) Physical & Environmental Specs Dimensions: 150 × 200 × 165 mm (W×H×D) Weight: 2.1 kg Cooling: Convection cooling (fanless) Ambient Temp: -10°C to +50°C (14°F to 122°F)

499

ABB

Key Specifications ✔ Power Rating: 22 kW (30 HP) ✔ Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz ✔ Output Current: 44 A ✔ Overload Capacity: 150% for 3 seconds ✔ Control Method: Direct Torque Control (DTC) ✔ Switching Frequency: 2-16 kHz (adjustable) ✔ Efficiency: >97.5% at full load Technical Features 1. Advanced Motor Control True DTC technology for precise speed (±0.1%) and torque (±2%) control Automatic Motor Adaptation (AMA) for optimal performance Torque boost and flying start functions Motor thermal protection (PTC/KTY input) 2. Industrial-Grade Design Forced air cooling with temperature monitoring Heavy-duty power components for extended service life Coated PCBs for protection against harsh environments Compact form factor (see physical specs below) 3. Application-Specific Functions 7 pre-programmed macros (pump, fan, conveyor, etc.) Enhanced PID controller with sleep/wake function Custom application programming via free function blocks Pump and fan optimization curves 4. Protection & Safety IGBT monitoring with short-circuit protection Ground fault detection Input phase monitoring Safe Torque Off (STO) - SIL3/PL e certified Overvoltage/undervoltage protection 5. Connectivity Options Standard: RS485 (Modbus RTU) Optional fieldbus: PROFIBUS DP, DeviceNet, CANopen USB service port for quick parameter transfer 2 analog inputs (0-10V/4-20mA), 4 digital inputs, 2 relay outputs Physical Specifications Dimensions: 350 × 482 × 227 mm (W×H×D) Weight: 15.2 kg Enclosure Rating: IP20 (IP66 kit available) Cooling Method: Forced air (temperature-controlled fan) Ambient Temperature: -10°C to +50°C (14°F to 122°F) Storage Temperature: -40°C to +70°C (-40°F to 158°F)

128

ABB

Key Specifications Power Rating: 22 kW (30 HP) Input Voltage: Single-phase 200-240V AC (±10%), 50/60Hz Output Current: 105 A (three-phase output) Overload Capacity: 150% for 3 seconds Control Technology: Advanced sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >96% (at full load) Technical Highlights ✔ Power Conversion System Specialized single-phase to three-phase conversion Active front-end technology for clean power input DC bus stabilization circuit ✔ Advanced Motor Control ABB's proprietary DTC (Direct Torque Control) Automatic Motor Adaptation (AMA) Torque boost (±3% accuracy) Flying start and DC braking ✔ Application-Specific Features 7 pre-programmed application macros Enhanced PID controller with sleep/wake function Customizable logic functions Pump and fan optimization curves ✔ Protection Systems Advanced thermal management Input phase monitoring Motor stall prevention Safe Torque Off (STO) - SIL3/PL e certified Physical Specifications Dimensions: 400 × 500 × 250 mm (W×H×D) Weight: 16.5 kg Enclosure Rating: IP20 (IP66 kit optional) Cooling: Forced air with temperature-controlled fan Ambient Temperature: -10°C to +50°C (14°F to 122°F)

216

ABB

Key Specifications Power Rating: 18.5 kW (25 HP) Input Voltage: Single-phase 200-240V AC (±10%), 50/60Hz Output Current: 90 A (three-phase output) Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >96% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic Motor Adaptation (AMA) Torque boost function (±3% accuracy) Flying start capability ✔ Application-Specific Functions 5 pre-programmed application macros Built-in PID controller Customizable application programs Pump and fan control curves ✔ Protection & Safety Motor thermal protection (PTC/KTY supported) Short circuit and ground fault protection Safe Torque Off (STO) option (SIL3/PL e) Input phase loss protection ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen USB service port for configuration Physical Characteristics Dimensions: 350 × 482 × 227 mm (W×H×D) Weight: 14 kg Enclosure Rating: IP20 (open type) Cooling Method: Forced air cooling Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

571

ABB

Key Specifications ✔ Power Rating: 18.5 kW (25 HP) ✔ Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz ✔ Output Current: 38 A ✔ Overload Capacity: 150% for 3 seconds ✔ Control Method: Sensorless Vector Control (DTC option available) ✔ Switching Frequency: 2–16 kHz (adjustable) ✔ Efficiency: >97.5% Main Features 1. Advanced Motor Control Direct Torque Control (DTC) for precise speed/torque regulation (±0.5% accuracy) Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback Torque boost & flying start – ensures smooth operation under heavy loads 2. Application-Specific Functions Pre-programmed macros (pump, fan, conveyor, hoist) Built-in PID controller for process automation Customizable logic via free function blocks 3. Protection & Safety Motor thermal protection (PTC/KTY input) IGBT monitoring for short-circuit protection Ground fault detection Safe Torque Off (STO) – SIL3/PL e safety compliance 4. Connectivity & Control Standard RS485 (Modbus RTU) 2 analog inputs (0–10V/4–20mA), 4 digital inputs, 2 relay outputs Optional fieldbus adapters (PROFIBUS DP, DeviceNet, CANopen) 5. Robust Design IP20 enclosure (dust protected) Forced air cooling with temperature monitoring Built-in EMC filter (Class A compliance) Physical & Environmental Specs Dimensions: 350 × 482 × 227 mm (W×H×D) Weight: 12 kg Cooling: Forced air (fan included) Ambient Temp: -10°C to +50°C (14°F to 122°F)

475

ABB

Key Specifications Power Rating: 30 kW (40 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 60 A Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Brake Chopper: Integrated (P901 module) Switching Frequency: 1-12 kHz (adjustable) Efficiency: >98% Main Features ✔ Advanced Motor Control True DTC technology for precise speed/torque control Automatic motor adaptation Torque control mode (±1% accuracy) Flying start function ✔ Application-Specific Functions Multiple application macros Built-in PID controller Pump and fan control curves Customizable application programming ✔ Protection & Safety Motor thermal protection Short circuit protection (IGBT monitoring) Ground fault detection Safe Torque Off (STO) option ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen USB service port Physical Characteristics Dimensions: 482 × 245 × 227 mm (H×W×D) Weight: 15 kg Enclosure Rating: IP21 Cooling Method: Forced air Ambient Temperature Range: 0°C to +40°C (32°F to 104°F)Key Specifications Power Rating: 30 kW (40 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 60 A Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Brake Chopper: Integrated (P901 module) Switching Frequency: 1-12 kHz (adjustable) Efficiency: >98% Main Features ✔ Advanced Motor Control True DTC technology for precise speed/torque control Automatic motor adaptation Torque control mode (±1% accuracy) Flying start function ✔ Application-Specific Functions Multiple application macros Built-in PID controller Pump and fan control curves Customizable application programming ✔ Protection & Safety Motor thermal protection Short circuit protection (IGBT monitoring) Ground fault detection Safe Torque Off (STO) option ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen USB service port Physical Characteristics Dimensions: 482 × 245 × 227 mm (H×W×D) Weight: 15 kg Enclosure Rating: IP21 Cooling Method: Forced air Ambient Temperature Range: 0°C to +40°C (32°F to 104°F)Key Specifications Power Rating: 30 kW (40 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 60 A Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Brake Chopper: Integrated (P901 module) Switching Frequency: 1-12 kHz (adjustable) Efficiency: >98% Main Features ✔ Advanced Motor Control True DTC technology for precise speed/torque control Automatic motor adaptation Torque control mode (±1% accuracy) Flying start function ✔ Application-Specific Functions Multiple application macros Built-in PID controller Pump and fan control curves Customizable application programming ✔ Protection & Safety Motor thermal protection Short circuit protection (IGBT monitoring) Ground fault detection Safe Torque Off (STO) option ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen USB service port Physical Characteristics Dimensions: 482 × 245 × 227 mm (H×W×D) Weight: 15 kg Enclosure Rating: IP21 Cooling Method: Forced air Ambient Temperature Range: 0°C to +40°C (32°F to 104°F)Brake Chopper (P901) Details Designed for dynamic braking applications Requires external brake resistor Handles regenerative energy LED status indicator Typical Applications Centrifuges Cranes and hoists Test benches Elevators Winding machines Certifications & Compliance CE UL cULus DNV GL IEC 61800-3

978

ABB

Key Specifications Power Rating: 5.5 kW (7.5 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 12.5 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97.5% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic Motor Adaptation (AMA) Torque boost function (±3% accuracy) Flying start capability ✔ Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable application programs Pump and fan control curves ✔ Protection & Safety Motor thermal protection (PTC/KTY supported) Short circuit and ground fault protection Safe Torque Off (STO) option (SIL3/PL e) Overvoltage/undervoltage protection ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen USB service port for configuration Physical Characteristics Dimensions: 150 × 200 × 165 mm (W×H×D) Weight: 2.3 kg Enclosure Rating: IP20 (open type) Cooling Method: Forced air cooling Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

409

ABB

Key Specifications ✔ Power Rating: 0.75 kW (1 HP) ✔ Input Voltage: 3-phase 380–480V AC (±10%), 50/60 Hz ✔ Output Current: 2.1 A ✔ Overload Capacity: 150% for 3 seconds ✔ Control Method: Sensorless Vector Control (DTC option available) ✔ Switching Frequency: 2–16 kHz (adjustable) ✔ Efficiency: >97% Main Features 1. Advanced Motor Control Sensorless vector control for precise speed regulation (±0.5% accuracy) Automatic Motor Adaptation (AMA) – optimizes performance without encoder feedback Torque boost & flying start – ensures smooth operation under load 2. Application Flexibility Pre-programmed macros (pump, fan, conveyor) for quick setup Built-in PID controller for process control (pressure, flow, temperature) Customizable logic via free function blocks 3. Protection & Safety Motor thermal protection (PTC/KTY input) Short-circuit, overvoltage, and ground fault protection Safe Torque Off (STO) – SIL3/PL e safety compliance 4. Connectivity & Control Standard RS485 (Modbus RTU) 2 analog inputs (0–10V/4–20mA), 4 digital inputs, 1 relay output Optional fieldbus adapters (Profibus DP, DeviceNet, CANopen) 5. Compact & Robust Design IP20 enclosure (dust protected) Optional IP66/NEMA 4X kit for harsh environments Built-in EMC filter (Class A compliance) Physical & Environmental Specs Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.7 kg Cooling: Convection cooling (fanless) Ambient Temp: -10°C to +50°C (14°F to 122°F)

41

ABB

Key Specifications Power Rating: 1.5 kW (2 HP) Input Voltage: 1-phase 200-240V AC (±10%), 50/60Hz Output Current: 7.8 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >96% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic Motor Adaptation (AMA) Torque boost function Flying start capability ✔ Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable application programs ✔ Protection & Safety Motor thermal protection (PTC input) Short circuit and ground fault protection Safe Torque Off (STO) option ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics Dimensions: 150 × 200 × 165 mm (W×H×D) Weight: 1.5 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

480

ABB

Key Specifications: Power Rating: 3.0 kW (4 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 7.2 A Overload Capacity: 150% for 3 seconds Control Method: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97.5% Main Features: Advanced Control Technology: ✓ ABB's Direct Torque Control (DTC) ✓ Automatic Motor Adaptation (AMA) ✓ Torque boost function ✓ Flying start capability Application Flexibility: ✓ 5 pre-programmed application macros ✓ Built-in PID controller ✓ Customizable application programs ✓ Pump and fan control curves Protection & Safety: ◆ Motor thermal protection (PTC/KTY) ◆ Short circuit and ground fault protection ◆ Safe Torque Off (STO) option ◆ Overvoltage/undervoltage protection Connectivity Options: ◉ Standard RS485 (Modbus RTU) ◉ Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen ◉ USB service port for configuration Physical Specifications: Dimensions: 150 × 200 × 165 mm (W×H×D) Weight: 1.8 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Operating Temperature: -10°C to +50°C (14°F to 122°F)

51

ABB

Key Specifications Power Rating: 1.1 kW (1.5 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 3.0 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic Motor Adaptation (AMA) Torque boost function (±3% accuracy) Flying start capability ✔ Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable application programs ✔ Protection & Safety Motor thermal protection (PTC/KTY supported) Short circuit and ground fault protection Safe Torque Off (STO) option (SIL3/PL e) ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.7 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

662

ABB

Key Specifications Power Rating: 0.55 kW (0.75 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 1.7 A Overload Capacity: 150% for 3 seconds Control Technology: Sensorless vector control Switching Frequency: 2-16 kHz (adjustable) Efficiency: >97% Main Features ✔ Advanced Motor Control Direct Torque Control (DTC) technology Automatic Motor Adaptation (AMA) Torque boost function Flying start capability ✔ Application Flexibility 5 pre-programmed application macros Built-in PID controller Customizable application programs ✔ Protection & Safety Motor thermal protection (PTC input) Short circuit and ground fault protection Safe Torque Off (STO) option ✔ Connectivity Options Standard RS485 (Modbus RTU) Optional fieldbus adapters: PROFIBUS DP DeviceNet CANopen Physical Characteristics Dimensions: 70 × 170 × 145 mm (W×H×D) Weight: 0.65 kg Enclosure Rating: IP20 (open type) Cooling Method: Natural convection Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)

544
