EPRO

Key Features ✔ Wide Temp Range: -50°C to +250°C continuous operation ✔ Robust Construction: Inconel 718 housing, IP68 submersible ✔ High Accuracy: ±1% linearity, <3% transverse sensitivity ✔ IEPE Output: 2-10mA constant current, noise-resistant ✔ Military Connector: MIL-C-5015 (gold-plated, vibration-proof) Technical Specifications Measurement Range: ±50 g Sensitivity: 100 mV/g ±3% Frequency Response: 1 Hz – 5 kHz (±3 dB) Power Supply: 18-30 VDC (IEPE) Output Signal: ±5 V (AC-coupled) Mounting: M8 threaded stud Applications Gas/steam turbine casing vibration Nuclear reactor coolant pumps Refinery high-temperature compressors Cement kiln gearbox monitoring Offshore platform machinery Certifications & Options ATEX/IECEx (Zone 1) Nuclear-qualified (NQA-1) CE, SIL 2 compliant Why Choose A6140? Reliable in extreme heat/corrosion Military-grade durability Precision measurements in harsh conditions Seamless integration with EPRO monitoring systems

730

EPRO

Key Features: Dual-output design (4-20mA & IEPE options) Wide frequency range (0.5Hz-10kHz) ±50g measurement range (100mV/g sensitivity) IP68 stainless steel housing M12 quick-disconnect connector Technical Specifications: Power supply: 18-30VDC (4-20mA) / 2-10mA (IEPE) Operating temperature: -40°C to +85°C Shock resistance: 1000g (6ms) ±1% linearity across full range <5% transverse sensitivity Output Options: 4-20mA loop-powered version (A6210-01) IEPE constant current version (A6210-02) ATEX-certified models available (A6210-EX) Performance Highlights: MEMS technology for long-term stability Integrated electronics for direct PLC connection TÜV-certified for safety applications NIST-traceable calibration available Typical Applications: Pump and motor vibration monitoring Gearbox condition assessment Wind turbine structural health Compressor casing vibration Rolling mill equipment Certifications: CE compliant ATEX/IECEx options (Zone 1/21) SIL 2 capable ISO 10816/20816 compliant Installation Notes: M6 threaded or adhesive mounting 300m maximum cable run Compatible with EPRO WTS-200 wireless module

304

EPRO

Key Features: 16-64 channel modular architecture 102.4kHz/channel sampling rate (24-bit resolution) 140dB dynamic range for precise measurements <10ms protection response time 24 relay outputs (250VAC/5A) SIL 2 certified (optional ATEX Zone 1) Technical Specifications: Vibration monitoring: 0-2000µm (shaft), 0-100mm/s (casing) Position measurement: ±5mm thrust, 0-500µm eccentricity Speed monitoring: 0.1-50,000 RPM (0.01% accuracy) 8 process parameter inputs (4-20mA/RTD) Operating temperature: -30°C to +70°C Advanced Capabilities: Real-time 25,600-line FFT analysis Automated bearing/gear fault detection Web-based HMI interface PROFINET/OPC UA/PROFIBUS communication Optional Wi-Fi 6 connectivity Typical Applications: Power plant steam turbines Offshore gas compressors Critical pump trains High-speed turbo machinery Integrated plant protection systems Certifications: API 670 (4th Ed.) compliant ISO 7919-3/10816-3 certified CE marked (ATEX optional) SIL 2 safety rated System Benefits: Early mechanical fault detection Reduced unplanned downtime Predictive maintenance enablement Flexible expansion capabilities Rugged industrial design

311

EPRO

Key Features: 8mm stainless steel probe (M10×1 threading) 0.5-2.5mm measuring range (8mV/µm sensitivity) 12kHz frequency response IP65 environmental protection Standard DIN 43650 connector Technical Specifications: Power supply: -18 to -24VDC (±10%) Output signal: -2 to -18VDC Operating temperature: -25°C to +85°C ±1.5% linearity across full range 5m standard cable (extendable to 200m) Performance Highlights: ±0.3µm repeatability 30g vibration resistance Basic API 670 compliance CE and RoHS certified Typical Applications: Industrial pump monitoring Electric motor protection Fan vibration analysis Conveyor system rollers General rotating equipment Certifications: CE marked RoHS compliant Meets basic API 670 requirements Installation Notes: Requires mild steel targets (AISI 1045 recommended) 20N·m mounting torque Standard 5m PVC-jacketed cable included

464

EPRO

Key Features: 4mm titanium alloy probe (M6×0.75 threading) High sensitivity (30mV/µm) for micro-measurements Ultra-wide frequency response (0-25kHz) IP67 environmental protection Gold-plated Micro-LEMO® connector Technical Specifications: Measuring range: 0.2-1.0mm Operating temperature: -20°C to +120°C Power supply: -15 to -24VDC (±5%) Output signal: -0.8 to -12VDC ±0.8% linearity across full range Performance Highlights: ±0.1µm exceptional repeatability 50g vibration resistance <8mA low current draw NIST-traceable calibration available Typical Applications: Dental drill vibration analysis Precision spindle monitoring Micro-turbine diagnostics Semiconductor manufacturing Watchmaking precision engineering Certifications: CE and RoHS compliant Partial compliance with API 670/ISO 7919 Installation Notes: Requires hardened tool steel targets (≥50 HRC) 5N·m maximum mounting torque 3m standard Teflon®-insulated cable

84

EPRO

Key Features: 8mm stainless steel probe with M10×1 threading 0.8-3.2mm measuring range (7.87mV/µm sensitivity) Wide frequency response (0-10kHz) IP67 environmental protection 100 bar pressure rating Technical Specifications: Power supply: -18 to -24VDC (±10%) Output signal: -3 to -18VDC Operating temperature: -30°C to +100°C ±1.2% linearity across full range 5m standard cable (extendable to 300m) Performance Highlights: ±0.5µm repeatability MIL-spec connector for secure connections NIST-traceable calibration available CE and RoHS compliant Typical Applications: Industrial pump monitoring Electric motor protection Paper manufacturing equipment General rotating machinery Power generation auxiliary equipment Certifications: Complies with API 670 (4th Ed.) Meets ISO 7919 standards CE marked and RoHS compliant Installation Notes: Requires carbon steel targets (AISI 4140 recommended) 25N·m mounting torque Standard 5m cable included

288

EPRO

Key Features: ATEX & IECEx Zone 1 Certified (Ex d IIC T4) 10mm explosion-proof probe with M16×1.5 threading 1.2-5.0mm extended range (4mV/µm sensitivity) Triple-redundant sealing for gas ingress protection IP69K-rated for washdown environments Technical Specifications: Frequency response: 0-6kHz (±3dB) Power supply: -24VDC ±1% (intrinsically safe) Output signal: -5 to -22VDC Operating temperature: -60°C to +150°C 300 bar (4351 psi) pressure rating Safety & Compliance: Complies with API 670 (4th Ed.) and ISO 7919 ATEX II 2G Ex d IIC T4 Gb certified IECEx IEC 60079-0/1 compliant SIL 2 capable (SIL 3 option available) Typical Applications: Oil & gas refinery compressors Petrochemical processing equipment Grain handling facilities Mining conveyor systems Pharmaceutical solvent areas Installation Notes: Requires AISI 4140 steel targets (≥40 HRC) EPRO ExSeal™ connector mandatory Intrinsic safety barrier recommended NIST-traceable calibration included

901

EPRO

Key Features: 10mm stainless steel probe (M12×1.5 threading) Extended 1.0-4.0mm measuring range (5mV/µm sensitivity) ATEX/IECEx Zone 1 certified (Ex d IIC T6) IP68 submersible to 10m depth 250 bar pressure rating (3626 psi) -50°C to +175°C operational range Technical Specifications: Frequency response: 0-8kHz (±3dB) Power supply: -18 to -24VDC (±5%) Output signal: -4 to -20VDC ±1.5% linearity across full range 10m armored cable standard (extendable to 500m) Performance Highlights: ±0.5µm repeatability 800N axial load capacity Vibration-resistant HeavyDuty™ connector NIST-traceable calibration Typical Applications: Offshore drilling equipment Heavy mining machinery Steel rolling mill stands Marine propulsion systems Hazardous area installations Certifications: Complies with API 670 (4th Ed.) and ISO 7919 ATEX, IECEx, CE, SIL 2 Optional SIL 3 version available Installation Notes: Requires hardened steel targets (≥35 HRC) 40-50N·m mounting torque recommended Special calibration available for sub-micron applications

405

EPRO

Key Features ✔ 3mm titanium probe (M6×0.75 thread) – smallest in EPRO lineup ✔ 0.1–0.8mm range with 25mV/µm sensitivity (industry-leading) ✔ 20kHz frequency response – captures ultra-high-speed dynamics ✔ IP68 submersible & 100g vibration-proof ✔ ±0.15µm repeatability – for micron-level accuracy Technical Highlights Power: -18 to -24VDC Output: -0.5 to -10VDC Temp Range: -40°C to +150°C (short-term +180°C) Cable: 3m standard (200m max with extension) ATEX/IECEx versions available Designed For Aerospace fuel control systems Medical high-speed drills (FDA option) Precision robotics joint monitoring Watchmaking gear trains Micro-turbines (>100k RPM) Why Choose PR6423/003-030? 50% smaller than standard 5mm probes Titanium housing for corrosive environments Active temp compensation (±0.02%/°C) NIST-traceable calibration included

933

EPRO

Key Features: 5mm stainless steel probe with M8×1 threading High sensitivity (20mV/µm) for precise measurements Wide frequency response (0-15kHz) IP67 environmental protection MIL-spec connector for secure connections Technical Specifications: Measuring range: 0.25-1.0mm Operating temperature: -40°C to +120°C Power supply: -18 to -24VDC Output signal: -1 to -12VDC ±1% linearity across full range Performance Highlights: ±0.3µm repeatability 50 bar pressure rating ATEX-certified version available NIST-traceable calibration Typical Applications: High-speed spindle monitoring Turbocharger vibration analysis Precision gearbox protection Small motor condition monitoring Compact rotating machinery Certifications: Complies with API 670 and ISO 7919 CE and RoHS compliant ATEX/IECEx options available Installation Notes: Requires carbon steel targets (AISI 4140 recommended) 5m standard cable (extendable to 300m) 15N·m maximum mounting torque

449

EPRO

Key Features: 8-32 channel modular configuration 100kHz/channel sampling rate (24-bit resolution) 130dB dynamic range for precise measurements <10ms protection response time Dual-redundant power supply option Technical Specifications: Vibration monitoring: 0-2000µm (shaft), 0-100mm/s (casing) Position measurement: ±5mm thrust, 0-500µm eccentricity Speed monitoring: 0.1-50,000 RPM (0.01% accuracy) 8 process parameter inputs (4-20mA/RTD) Operating temperature: -30°C to +70°C Protection Capabilities: 4 alarm levels per channel 16 relay outputs (250VAC/5A) Configurable voting logic (1oo2, 2oo3) SIL 2 compliant version available Communication Options: PROFINET, Modbus TCP PROFIBUS-DP, DeviceNet Optional Wi-Fi connectivity Typical Applications: Power plant turbines Oil & gas compressors Critical pump systems Large motor monitoring Integrated plant protection Certifications: API 670 (4th Ed.) ISO 7919/10816 compliant ATEX/IECEx options available CE marked System Benefits: Early fault detection through continuous monitoring Reduced downtime with predictive maintenance Flexible expansion for growing needs Rugged design for harsh environments Easy integration with control systems

298

EPRO

Key Features ✔ 500kHz/channel sampling (32-bit resolution) ✔ 170dB dynamic range – captures ultra-fine vibration details ✔ 32-128 channels (fiber-optic expandable) ✔ <50μs latency – world's fastest protection response ✔ 64 SIL 3 relays (300VAC/15A arc-proof) ✔ AI-powered predictive analytics (EPRO CortexAI 3.0) ✔ Quantum encryption optional (QKD) Technical Superiority 0.001% speed accuracy (0.001-150,000 RPM) MIL-STD-461G EMC compliance -55°C to +85°C operation (conformal coated) 100g shock & 5km altitude capable Liquid-cooled version for extreme environments Certifications API 670 (5th Ed.) ATEX Zone 0 (explosive atmospheres) IEC 61508 SIL 3 (option for SIL 4) NRC 10CFR21 (nuclear quality assurance) NASA STD-8739.4 (space-grade option) Typical Applications Nuclear reactor primary pumps Space launch turbopumps 3000MW+ steam turbines Offshore LNG compressors Military naval propulsion Next-Gen Ready: Digital twin synchronization <1ms Quantum computing interface Blockchain secure data ledger

984
