ABB

Key Specifications Power & Performance Rated Power: 200 kW (268 HP) Input Voltage: 3-phase 380-500V AC (±10%), 50/60 Hz Output Current: 430 A Overload Capacity: 110% continuous 150% for 60 seconds Control Method: Direct Torque Control (DTC) Efficiency: >98.5% Switching Frequency: 1-4 kHz (adjustable) Main Features 1. Advanced Motor Control DTC technology for precise speed (±0.1%) and torque (±1%) control Automatic motor adaptation Flying start and torque boost functions 2. Robust Design Heavy-duty power components for 24/7 operation Coated PCBs for harsh environments Modular design for easy maintenance 3. Application Flexibility 10 pre-programmed macros Customizable application programs Built-in PID controller 4. Protection & Safety Motor thermal protection (PTC/KTY) Short-circuit protection (IGBT monitoring) Ground fault detection Safe Torque Off (STO) 5. Connectivity Standard: RS485 (Modbus RTU) Ethernet Optional fieldbus: PROFIBUS DP PROFINET EtherNet/IP Physical Specifications Dimensions: 800 × 2200 × 450 mm (W×H×D) Weight: 185 kg Enclosure Rating: IP21 (IP54 kit available) Cooling: Liquid cooling (standard) Ambient Temperature: 0-40°C (32-104°F)

366

ABB

Key Specifications Power Rating: 55 kW (75 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 110 A Overload Capacity: 110% continuous, 150% for 60s Control Method: Sensorless vector control Efficiency: >98% (IE4 equivalent) THDi: <5% (with optional filter) Technical Highlights ✔ HVAC-Specific Intelligence Adaptive pump/fan control algorithms Automatic energy optimization (up to 25% savings) Built-in multi-pump controller Anti-condensation function ✔ Smart Connectivity Embedded BACnet MS/TP and Modbus RTU Cloud-ready with ABB Ability™ Optional wireless module (Wi-Fi/4G) Predictive maintenance capabilities ✔ Advanced Protection Motor thermal modeling (PTC/Pt100) Phase loss protection Surge protection (6kV/3kA) Safe Torque Off (STO) Physical Specifications Dimensions: 482 × 800 × 350 mm (H×W×D) Weight: 42 kg Enclosure: IP21 (IP55 kit available) Cooling: Forced air with ECO mode Ambient Range: -15°C to +50°C (5°F to 122°F) Certifications UL 61800-5-1 CE cULus EN 61800-3 Cat C2 ISO 13849-1 PL c

928

ABB

Key Specifications Power & Performance Rated Power: 30 kW (40 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 60 A Overload Capacity: 110% continuous 150% for 60 seconds Control Method: Sensorless Vector Control (DTC option) Efficiency: >98% (IE4 equivalent) Main Features 1. HVAC-Specific Control Adaptive programming for pumps and fans Automatic energy optimization Built-in PID controller with sleep/wake function Pump cleaning cycle program 2. Intelligent Connectivity Embedded Modbus RTU (RS485) BACnet MS/TP and Metasys N2 protocols Cloud connectivity via optional gateway ABB Ability™ enabled for remote monitoring 3. Protection & Safety Motor thermal protection (PTC/Pt100) Earth fault detection Surge protection (IEC 61000-4-5) Safe Torque Off (STO) 4. Physical Design Compact form factor (30% smaller than previous gen) IP21 enclosure (IP55 kit available) Corrosion-protected (C5-M coating) Plug-and-play installation Technical Highlights ✔ Energy Savings Features ECO mode saves up to 20% energy Automatic derating at partial loads Power factor >0.98 ✔ Application Flexibility 10 pre-programmed HVAC macros Customizable application programs Multi-pump control capability ✔ Monitoring & Diagnostics Built-in power quality monitoring 200-event fault log Predictive maintenance alerts Physical Specifications Dimensions: 350 × 482 × 227 mm (H×W×D) Weight: 15 kg Cooling: Convection (fanless) Ambient Temperature: -15°C to +50°C (5°F to 122°F) Relative Humidity: 5-95% non-condensing Certifications & Compliance CE UL 61800-5-1 cULus EN 61800-3 ISO 13849-1 (PL c)

55

ABB

Key Specifications Power & Performance Rated Power: 90 kW (125 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz Output Current: 180 A Overload Capacity: 150% for 60 seconds 110% continuous Control Method: Direct Torque Control (DTC) Braking Capacity (P901): Continuous: 90 kW Peak (60s): 135 kW Switching Frequency: 1-12 kHz (adjustable) Efficiency: >98% Main Features 1. Advanced Motor Control DTC technology for precise speed (±0.1%) and torque (±1%) control Automatic motor adaptation for optimal performance Flying start and torque boost functions 2. Brake Chopper (P901) Handles regenerative energy during deceleration Requires external brake resistor (sold separately) LED status indicator for fault monitoring 3. Application Flexibility Pre-programmed macros for: Pumps & fans Conveyors Cranes/hoists Built-in PID controller Customizable application programming 4. Protection & Safety Motor thermal protection (PTC/KTY support) Short-circuit and ground fault protection DC bus overvoltage/undervoltage protection Safe Torque Off (STO) compliant 5. Connectivity Standard: RS485 (Modbus RTU) Analog I/O (2xAI, 1xAO) Digital I/O (3xDI, 1xDO) Optional fieldbus: PROFIBUS DP DeviceNet CANopen Physical Specifications Dimensions: 482 × 800 × 350 mm (H×W×D) Weight: 65 kg Enclosure Rating: IP21 Cooling: Forced air (filtered) Ambient Temperature: 0-40°C (32-104°F)

588

ABB

Key Specifications Power Rating: 2.5 kW (3 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 6.5 A Overload Capacity: 150% for 60 seconds Control Technology: Direct Torque Control (DTC) Encoder Interface: N671 module included Main Features ✔ Precision Motion Control Closed-loop speed control (±0.005% accuracy) Torque control (±0.5% accuracy) Automatic motor adaptation Position control capability ✔ N671 Encoder Module Supports incremental encoders (5V/24V) Resolution up to 4096 ppr Differential (RS422) and single-ended inputs LED status indicators ✔ Application Flexibility Multiple pre-programmed motion profiles Electronic gearing function Built-in PID controller Customizable application programming ✔ Protection & Safety Motor thermal protection Encoder loss detection Safe Torque Off (STO) Overvoltage/undervoltage protection Physical Characteristics Drive Dimensions: 245 × 482 × 227 mm (W×H×D) Weight: 8.5 kg (complete system) Enclosure Rating: IP21 Cooling Method: Convection cooling Ambient Temperature: 0-40°C (32-104°F)

30

ABB

Key Parameters Core Specifications Power: 40kW (55HP) Input: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 80A Overload: 150% for 60s Control: DTC (Direct Torque Control) Efficiency: >98% Modules P901 Brake Chopper Braking power: 40kW cont. / 60kW peak (60s) Requires external resistor N661 Encoder Interface Supports incremental encoders Resolution: Up to 4096 ppr Protocols: RS422/TTL Performance Speed accuracy: ±0.01% (with encoder) Torque accuracy: ±1% Switching freq.: 1-12kHz (adjustable) Physical Dimensions: 482×245×227mm (H×W×D) Weight: 18kg Cooling: Forced air Ambient Temp: 0-40°C Certifications CE, UL, cUL SIL3/PL e

316

ABB

Key Parameters Core Drive Power: 30kW (40HP) Input: 3-phase 380-500V AC (±10%) Output: 60A Control: DTC (Direct Torque Control) Overload: 150% for 60s Modules E200 I/O Extension 4AI (0-10V/4-20mA) 6DI + 2RO 1AO (0-20mA) K454 Fieldbus PROFIBUS DP-V1 12Mbps speed LB03 Cooling Liquid cooling system 8L/min flow requirement Physical Dimensions: 482×245×227mm (H×W×D) Weight: 38kg (complete) IP Rating: IP21 (standard) Certifications CE, UL, cUL SIL3/PL e

244

ABB

Key Specifications ✔ Power Rating: 20 kW (25 HP) ✔ Input Voltage: 3-phase 380-480V AC (±10%), 50/60 Hz ✔ Output Current: 43 A ✔ Overload Capacity: 150% for 60 seconds 110% continuous ✔ Control Method: Direct Torque Control (DTC) ✔ Braking Capacity (P901): Continuous: 20 kW Peak (60s): 30 kW ✔ Switching Frequency: 1-12 kHz (adjustable) ✔ Efficiency: >98% Main Features 1. Advanced Motor Control DTC technology for precise speed (±0.1%) and torque (±2%) control Automatic motor adaptation for optimal performance Flying start and torque boost functions 2. Brake Chopper (P901) Handles regenerative energy during deceleration Requires external brake resistor (sold separately) LED status indicator for fault monitoring 3. Application Flexibility Pre-programmed macros for: Pumps & fans Conveyors Cranes/hoists Built-in PID controller Customizable application programming 4. Protection & Safety Motor thermal protection (PTC/KTY support) Short-circuit and ground fault protection DC bus overvoltage/undervoltage protection Safe Torque Off (STO) compliant 5. Connectivity Standard: RS485 (Modbus RTU) Analog I/O (2xAI, 1xAO) Digital I/O (3xDI, 1xDO) Optional fieldbus: PROFIBUS DP DeviceNet CANopen Physical Specifications Dimensions: 245 × 482 × 227 mm (W×H×D) Weight: 14 kg Enclosure Rating: IP21 Cooling: Forced air (filtered) Ambient Temperature: 0-40°C (32-104°F)

353

ABB

Key Specifications Power Rating: 11 kW (15 HP) Input Voltage: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 25 A Overload Capacity: 150% for 60 seconds Control Technology: DTC (Direct Torque Control) Brake Chopper: Integrated (P901 module) Switching Frequency: 1-12 kHz (adjustable) Efficiency: >98% Main Features ✔ Advanced Motor Control Sensorless speed control (±0.1% accuracy) Automatic motor adaptation Torque control mode (±2% accuracy) Flying start function ✔ Braking System (P901) Handles regenerative energy Requires external brake resistor LED status indicator 150% braking torque capacity ✔ Application Functions Multiple application macros Built-in PID controller Pump and fan control curves Customizable application programming ✔ Protection Features Motor thermal protection Short circuit protection Ground fault detection DC bus overvoltage protection Physical Characteristics Dimensions: 245 × 482 × 227 mm (W×H×D) Weight: 12 kg Enclosure Rating: IP21 Cooling Method: Forced air Ambient Temperature: 0-40°C (32-104°F)

969

ABB

Key Parameters Power & Performance Rated Power: 30kW (40HP) Input: 3-phase 380-480V AC (±10%), 50/60Hz Output Current: 60A Overload: 150% for 60s Control: DTC (Direct Torque Control) Efficiency: >98% Braking (P901) Chopper: Integrated Braking Power: 30kW cont. / 45kW peak (60s) Resistor: External required Control (D150) Display: 7" color touchscreen Interfaces: USB, RS485 (Modbus RTU) Fieldbus Options: PROFIBUS, PROFINET Physical Dimensions: 482×245×227mm (H×W×D) Weight: 32kg Cooling: Forced air IP Rating: IP21 Certifications CE, UL, cUL SIL3/PL e safety

904

ABB

ABB ACS800-04-0030-3+D150+P901 Technical Parameters 1. Power Specifications Rated Power: 30 kW (40 HP) Input Voltage: 3-phase 380-500V AC (-15%/+10%) Output Current: 60 A (continuous) Overload Capacity: 110% continuous 150% for 60 sec Efficiency: 98.5% (typical at full load) 2. Control Performance Control Method: Direct Torque Control (DTC) Speed Accuracy: ±0.01% of setpoint (encoderless) Torque Accuracy: ±1% of rated torque Switching Frequency: 1-4 kHz (adjustable) 3. Braking System (P901) Brake Chopper: Integrated Continuous Braking Power: 30 kW Peak Braking Power: 45 kW (60 sec) External Resistor Required: Yes 4. Control Panel (D150) Display: 7" color TFT touchscreen Languages: 20 pre-installed Data Logging: 1000 events Interface: USB for parameter transfer 5. Communication Standard: RS485 (Modbus RTU) Ethernet (TCP/IP) Optional Fieldbus: PROFIBUS DP-V1 PROFINET IRT EtherNet/IP 6. Protection Features Electrical: Short-circuit (IGBT protection) Ground fault detection DC bus monitoring Thermal: Motor thermal model Heatsink temperature control 7. Physical Parameters Dimensions (Drive): 482H × 245W × 227D mm Weight: 32 kg (complete system) Cooling: Forced air (filtered) Ambient Temperature: 0-40°C (32-104°F) 8. Compliance Standards Safety: SIL3/PL e (ISO 13849-1) EMC: IEC 61800-3 Category C3 Certifications: CE, UL, cULus, DNV GL

855

ABB

Key Specifications Power Rating: 200 kW (268 HP) Input Voltage: 3-phase 380-480V AC (-15%/+10%), 50/60Hz Output Current: 360 A Overload Capacity: 110% continuous, 150% for 60s Control Technology: Direct Torque Control (DTC) Efficiency: >98.5% at full load Braking Chopper: Integrated (requires external resistor) System Components ACS880-01-206A-3 Drive Unit: Multi-layer PCB design for enhanced reliability Heavy-duty IGBT power stage Built-in EMC filter (Class A) IP21 enclosure (IP54 kit available) D150 Control Panel: 7" full-color touchscreen display Multilingual interface (24 languages) Real-time trending and data logging USB port for parameter backup Advanced Features ✔ Precision Control Speed control accuracy: ±0.01% of setpoint Torque control accuracy: ±1% of rated torque Adaptive programming capability ✔ Application-Specific Functions Multiple application macros Customizable logic functions Built-in safety functions (STO, SS1, SLS) Advanced PID controller with feedforward ✔ Connectivity Standard interfaces: Ethernet (TCP/IP) Modbus TCP RS485 (Modbus RTU) Optional fieldbus: PROFIBUS DP-V1 PROFINET IRT EtherNet/IP CANopen Physical Specifications Drive Dimensions: 800 × 2200 × 450 mm (W×H×D) Control Panel Dimensions: 210 × 170 × 60 mm Total Weight: 185 kg Cooling: Liquid cooling system Ambient Temperature: 0-40°C (32-104°F) without derating

585
